使用webgl(three.js)搭建一个3D智慧园区、3D建筑，3D消防模拟，web版3D,bim管理系统——第四课

序：这段时间忙于奔波，好久没有更新了，今天更新一下，继续上节课的完善讲解，算是对前段时间的一个总结吧。披星戴月的时光也算有点应用效果了。

　　对于webgl(three.js)性能这一块我在上节课《使用webgl(three.js)搭建一个3D建筑，3D消防模拟——第三课》已经给了详细的说明比较与解决方案

　　下节课讲解了炫酷科技版本的解决方案

本节概要：

　　　　继上节课我们说的消防相关的操控模拟，本节课我们继续讲解用three.js创建大场景模拟与实现

　　　　本节课我们主要实现一个园区的消防三维模拟，3D消防监控

行业前景：

　　　　消防问题向来刻不容缓，消防监控，防患于未然，是社会财富保障的第一战，第一道有效防护线，目前的监控手段有很多，实时视频、烟感、喷淋、消防泵、消防联动是目前最主流以及最有效的消防监控手段。

　　　　但如何把这些设备直观的展现，实现全局布控，远程指挥，那就需要最直观的展示系统，所以3D消防操控系统在这里就发挥了及其重要的作用。

功能概述：

　　　　1、园区整体3D布局展示，直观掌控园区重点布局。

　　　　2、视角切换体验。第一人称巡检，切身熟悉路径通道。

　　　　3、大楼切面图消防管道消防设备布局3D展示，精准把握消防布控。

　　　　4、楼层三维展示、消防设备布局展示，逃生路径规划

　　　　5、消防局3D模拟监控室监控模拟

　　　　6、消防员以及相关动作模拟

　　　　7、消防车模拟、路径规划导航模拟、消防车喷水模拟

　　　　8、室内灭火模拟

　　　　9、消防传感器告警联动

　　　　10、设备巡检。实时检测设备状况。

　　　　11、设备远程控制与实时视频监控

技术难点：

　　　　1、浏览器大场景加载与渲染

　　　　　　解决方案：大量使用代码模型，把最终所有模型总和控制在1M以内

　　　　　　　　　　算法重构，避开浏览器绘图瓶颈

　　　　2、模型平滑切换

　　　　　　解决方案：逻辑数组+补间+按需加载

　　　　3、各主体动画

　　　　　　解决方案：js模拟多线程+逻辑自控js脚本+按需渲染

　　　　4、接口数据接入（数据对接是最耗时间的）

　　　　　　解决方案：实时数据接入与展示我采用的restFul+cache+websocket方式保障数据的完整性、实时性。

　　　　5、无插件实时视频调用

　　　　　　技术背景：当前主流的实时视频监控方式是使用客户端、或者用浏览器插件方式（flash插件或者其它），但由于各大浏览器宣布不再支持flash，adobe后期不再更新支持flash，以及其它插件也不能支持所有浏览器。

　　　　　　技术需求：无插件实时视频监控，浏览器打开就能看实时视频，不用插件

　　　　　　解决方案：

　　　　　　　　　　方案一、websocket+媒体服务

　　　　　　　　　　　　　　优点：无插件、数据实时、基本无延时

　　　　　　　　　　　　　　个人目前实现的缺点：目前只能支持硬解264的视频，但264的网络带宽占用高， 265的只能做到软解、多路视频支持效果不好。

　　　　　　　　　　方案二、HLS+媒体服务器

　　　　　　　　　　　　　　优点：无插件、数据实时

　　　　　　　　　　　　　　缺点：延时较大，目前也只能支持264硬解、265软解

　　　　　　　上述两种方案后面会写文章具体介绍技术实现。

技术交流 1203193731@qq.com

交流微信：

如果你有什么要交流的心得可邮件我

效果展示与实现：

　　　　A、整体场景

function getParkModelData() {
    var vdata = [{"show":true,"uuid":"","name":"m1_3DText_625","objType":"3DText","position":{"x":4203.118,"y":510.746,"z":-4400.494},"style":{"skinColor":16731983,"imgurl":"../img/3dImg/brick_diffuse.jpg","side":2,"opacity":0.8},"text":"119","options":{"size":90,"height":10,"weight":"normal","font":"../img/3dImg/OBJS/fonts/helvetiker_regular.typeface.json","style":"normal","bevelThickness":2,"bevelSize":4,"bevelSegments":3,"bevelEnabled":true,"curveSegments":12,"steps":1}, {"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/door_right.png","repeatx":true,"width":3,"repeaty":true,"height":1}}},"showSortNub":1,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":1.5707963267948966},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_tjc_2_door_logo_1","objType":"3DText","position":{"x":-1598.618,"y":95.509,"z":-4754.562},"style":{"skinColor":1433087,"imgurl":"../img/3dImg/brick_diffuse.jpg","side":2,"opacity":0.8},"text":"1-1","options":{"size":90,"height":10,"weight":"normal","font":"../img/3dImg/OBJS/fonts/helvetiker_regular.typeface.json","style":"normal","bevelThickness":2,"bevelSize":4,"bevelSegments":3,"bevelEnabled":true,"curveSegments":12,"steps":1},"showSortNub":1,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":-3.141592653589793},{"direction":"y","degree":0},{"direction":"z","degree":-3.141592653589793}],"scale":{"x":0.3,"y":0.3,"z":0.3},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_tjc_2_door_logo_2","objType":"3DText","position":{"x":-2177.695,"y":95.509,"z":-4754.562},"style":{"skinColor":1433087,"imgurl":"../img/3dImg/brick_diffuse.jpg","side":2,"opacity":0.8},"text":"1-2","options":{"size":90,"height":10,"weight":"normal","font":"../img/3dImg/OBJS/fonts/helvetiker_regular.typeface.json","style":"normal","bevelThickness":2,"bevelSize":4,"bevelSegments":3,"bevelEnabled":true,"curveSegments":12,"steps":1},"showSortNub":1,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":-3.141592653589793},{"direction":"y","degree":0},{"direction":"z","degree":-3.141592653589793}],"scale":{"x":0.3,"y":0.3,"z":0.3},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_tjc_2_door_logo_3","objType":"3DText","position":{"x":-2802.51,"y":95.509,"z":-4754.562},"style":{"skinColor":1433087,"imgurl":"../img/3dImg/brick_diffuse.jpg","side":2,"opacity":0.8},"text":"1-3","options":{"size":90,"height":10,"weight":"normal","font":"../img/3dImg/OBJS/fonts/helvetiker_regular.typeface.json","style":"normal","bevelThickness":2,"bevelSize":4,"bevelSegments":3,"bevelEnabled":true,"curveSegments":12,"steps":1},"showSortNub":1,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":-3.14159265 1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_11OBJCREN3","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-34.664,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null, 1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_11OBJCREN6","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":647.3,"z":159.715,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_11OBJCREN7","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":648.36,"z":90.374,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":-0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}],"showSortNub":268,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_28","objType":"GroupObj","scale":{"x":1,"y":1,"z":1},"position":{"x":-2712.443,"y":443.786,"z":2200},"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":1.5707963267948966},{"direction":"z","degree":0}],"childrens":[{"show":true,"uuid":"","name":"m1_build3_28OBJCREN0","objType":"cube2","length":150,"width":400,"height":900,"x":0,"y":200,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor2.jpg","repeatx":true,"width":16,"repeaty":true,"height":18},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_behind":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_left": {"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"}}},"showSortNub":4,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_28OBJCREN1","objType":"cube2","length":180,"width":200,"height":10,"x":0,"y":721.264,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor4.jpg"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_fore":{"skinColor":12755349,"side":1,"opacity":1},"skin_behind":{"skinColor":12755349,"side":1,"opacity":1},"skin_left":{"skinColor":12755349,"side":1,"opacity":1},"skin_right":{"skinColor":12755349,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_28OBJCREN2","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-54.759,"style":{"skinColor":16777215,"ski  l":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_28OBJCREN4","objType":"cube2","length":150,"width":400,"height":20,"x":0,"y":657.123,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":0,"opacity":1},"skin_down":{"skinColor":16777215,"side":0,"opacity":1},"skin_fore":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_behind":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_left":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1},"skin_right": },{"show":true,"uuid":"","name":"m1_build3_28OBJCREN5","objType":"cube2","length":120,"width":180,"height":80,"x":0,"y":682.537,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_28OBJCREN6","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":647.3,"z":159.715,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0 {"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}],"showSortNub":268,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_1","objType":"GroupObj","scale":{"x":1,"y":1,"z":1},"position":{"x":-385.84,"y":254.003,"z":206.384},"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"childrens":[{"show":true,"uuid":"","name":"m1_build3_1OBJCREN0","objType":"cube2","length":150,"width":400,"height":900,"x":0,"y":200,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor2.jpg","repeatx":true,"width":16,"repeaty":true,"height":18},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_behind":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_left":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"},"skin_ri {"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":-0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}],"showSortNub":268,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_21","objType":"GroupObj","scale":{"x":1,"y":1,"z":1},"position":{"x":636.611,"y":443.786,"z":2200},"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":1.5707963267948966},{"direction":"z","degree":0}],"childrens":[{"show":true,"uuid":"","name":"m1_build3_21OBJCREN0","objType":"cube2","length":150,"width":400,"height":900,"x":0,"y":200,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor2.jpg","repeatx":true,"width":16,"repeaty":true,"height":18},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_behind":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_left":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"},"skin_right":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"}}},"showSortNub":4,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_21OBJCREN1","objType":"cube2","length":180,"width":200,"height":10,"x":0,"y":721.264,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor4.jpg"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_fore":{"skinColor":12755349,"side":1,"opacity":1},"skin_behind":{"skinColor":12755349,"side":1,"opacity":1},"skin_left":{"skinColor":12755349,"side":1,"opacity":1},"skin_right":{"skinColor":12755349,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_21OBJCREN2","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-54.759,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_21OBJCREN3","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-34.664,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_21OBJCREN4","objType":"cube2","length":150,"width":400,"height":20,"x":0,"y":657.123,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":0,"opacity":1},"skin_down":{"skinColor":16777215,"side":0,"opacity":1},"skin_fore":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_behind":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_left":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1},"skin_right":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1}}},"showSortNub":100,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_21OBJCREN5","objType":"cube2","length":120,"width":180,"height":80,"x":0,"y":682.537,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_21OBJCREN6","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":647.3,"z":159.715,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_21OBJCREN7","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":648.36,"z":90.374,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":-0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}],"showSortNub":268,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_6","objType":"GroupObj","scale":{"x":1,"y":1,"z":1},"position":{"x":-2624.858,"y":254.003,"z":-541.603},"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"childrens":[{"show":true,"uuid":"","name":"m1_build3_6OBJCREN0","objType":"cube2","length":150,"width":400,"height":900,"x":0,"y":200,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor2.jpg","repeatx":true,"width":16,"repeaty":true,"height":18},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_behind":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_left":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"},"skin_right":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"}}},"showSortNub":4,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_6OBJCREN1","objType":"cube2","length":180,"width":200,"height":10,"x":0,"y":721.264,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor4.jpg"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_fore":{"skinColor":12755349,"side":1,"opacity":1},"skin_behind":{"skinColor":12755349,"side":1,"opacity":1},"skin_left":{"skinColor":12755349,"side":1,"opacity":1},"skin_right":{"skinColor":12755349,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_6OBJCREN2","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-54.759,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_6OBJCREN3","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-34.664,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_6OBJCREN4","objType":"cube2","length":150,"width":400,"height":20,"x":0,"y":657.123,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":0,"opacity":1},"skin_down":{"skinColor":16777215,"side":0,"opacity":1},"skin_fore":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_behind":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_left":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1},"skin_right":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1}}},"showSortNub":100,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_6OBJCREN5","objType":"cube2","length":120,"width":180,"height":80,"x":0,"y":682.537,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_6OBJCREN6","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":647.3,"z":159.715,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_6OBJCREN7","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":648.36,"z":90.374,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":-0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}],"showSortNub":268,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_2","objType":"GroupObj","scale":{"x":1,"y":1,"z":1},"position":{"x":-1021.257,"y":254.003,"z":-4.402},"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"childrens":[{"show":true,"uuid":"","name":"m1_build3_2OBJCREN0","objType":"cube2","length":150,"width":400,"height":900,"x":0,"y":200,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor2.jpg","repeatx":true,"width":16,"repeaty":true,"height":18},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_behind":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_left":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"},"skin_right":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"}}},"showSortNub":4,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_2OBJCREN1","objType":"cube2","length":180,"width":200,"height":10,"x":0,"y":721.264,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor4.jpg"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_fore":{"skinColor":12755349,"side":1,"opacity":1},"skin_behind":{"skinColor":12755349,"side":1,"opacity":1},"skin_left":{"skinColor":12755349,"side":1,"opacity":1},"skin_right":{"skinColor":12755349,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_2OBJCREN2","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-54.759,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_2OBJCREN3","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-34.664,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDe wSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":-0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}],"showSortNub":268,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_25","objType":"GroupObj","scale":{"x":1,"y":1,"z":1},"position":{"x":3333.997,"y":443.786,"z":2200},"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":1.5707963267948966},{"direction":"z","degree":0}],"childrens":[{"show":true,"uuid":"","name":"m1_build3_25OBJCREN0","objType":"cube2","length":150,"width":400,"height":900,"x":0,"y":200,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor2.jpg","repeatx":true,"width":16,"repeaty":true,"height":18},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_behind":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_left":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"},"skin_right":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"}}},"showSortNub":4,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_25OBJCREN1","objType":"cube2","length":180,"width":200,"height":10,"x":0,"y":721.264,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor4.jpg"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_fore":{"skinColor":12755349,"side":1,"opacity":1},"skin_behind":{"skinColor":12755349,"side":1,"opacity":1},"skin_left":{"skinColor":12755349,"side":1,"opacity":1},"skin_right":{"skinColor":12755349,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_25OBJCREN2","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-54.759,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_25OBJCREN3","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-34.664,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_25OBJCREN4","objType":"cube2","length":150,"width":400,"height":20,"x":0,"y":657.123,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":0,"opacity":1},"skin_down":{"skinColor":16777215,"side":0,"opacity":1},"skin_fore":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_behind":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_left":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1},"skin_right":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1}}},"showSortNub":100,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_25OBJCREN5","objType":"cube2","length":120,"width":180,"height":80,"x":0,"y":682.537,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_25OBJCREN6","objType":"cube2","length":100,"width":60,"height":40," ehind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_4OBJCREN7","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":648.36,"z":90.374,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":-0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}],"showSortNub":268,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_7","objType":"GroupObj","scale":{"x":1,"y":1,"z":1},"position":{"x":-523.715,"y":254.003,"z":-769.42},"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"childrens":[{"show":true,"uuid":"","name":"m1_build3_7OBJCREN0","objType":"cube2","length":150,"width":400,"height":900,"x":0,"y":200,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":1,"opacity":1,"imgurl":/"../img/3dImgfloor2.jpg","repeatx":true,"width":16,"repeaty":true,"height":18},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_behind":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/fore.jpg"},"skin_left":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"},"skin_right":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/3/left.jpg"}}},"showSortNub":4,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_7OBJCREN1","objType":"cube2","length":180,"width":200,"height":10,"x":0,"y":721.264,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/floor4.jpg"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_fore":{"skinColor":12755349,"side":1,"opacity":1},"skin_behind":{"skinColor":12755349,"side":1,"opacity":1},"skin_left":{"skinColor":12755349,"side":1,"opacity":1},"skin_right":{"skinColor":12755349,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_7OBJCREN2","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-54.759,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_7OBJCREN3","objType":"cube2","length":148,"width":5,"height":80,"x":0,"y":682.537,"z":-34.664,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_behind":{"skinColor":15918822,"side":1,"opacity":1,"imgurl":"../img/3dImg/inside_lightmap.jpg"},"skin_left":{"skinColor":15918822,"side":1,"opacity":1},"skin_right":{"skinColor":15918822,"side":1,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_7OBJCREN4","objType":"cube2","length":150,"width":400,"height":20,"x":0,"y":657.123,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16247014,"side":0,"opacity":1},"skin_down":{"skinColor":16777215,"side":0,"opacity":1},"skin_fore":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_behind":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":120,"repeaty":true,"height":1},"skin_left":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1},"skin_right":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/server3.png","repeatx":true,"width":40,"repeaty":true,"height":1}}},"showSortNub":100,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_7OBJCREN5","objType":"cube2","length":120,"width":180,"height":80,"x":0,"y":682.537,"z":-46.543,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1,"imgurl":"../img/3dImg/greenHourse2.png"},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_7OBJCREN6","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":647.3,"z":159.715,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_build3_7OBJCREN7","objType":"cube2","length":100,"width":60,"height":40,"x":0,"y":648.36,"z":90.374,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/solarBattery.png"},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":9541790,"side":1,"opacity":1},"skin_behind":{"skinColor":9541790,"side":1,"opacity":1},"skin_left":{"skinColor":15918822,"side":2,"opacity":1},"skin_right":{"skinColor":15918822,"side":2,"opacity":1}}},"showSortNub":5,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":-0.2617993877991494}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}],"showSortNub":268,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_building4_8","objType":"GroupObj","scale":{"x":1,"y":1,"z":1},"position":{"x":4612.426,"y":-6.896,"z":-2076.343},"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"childrens":[{"show":true,"uuid":"","name":"m1_building4_8OBJCREN0","objType":"cube2","length":500,"width":200,"height":50,"x":0,"y":823.003,"z":0,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":0,"opacity":1,"imgurl":"../img/3dImg/bbb.png","repeatx":true,"width":6,"repeaty":true,"height":3},"skin_down":{"skinColor":16777215,"side":1,"opacity":1},"skin_fore":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/buildings/4/fwall.jpg","repeatx":true,"width":1,"repeaty":true,"height":6},"skin_behind":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/buildings/4/fwall.jpg","repeatx":true,"width":1,"repeaty":true,"height":6},"skin_left":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/buildings/4/fwall.jpg","repeatx":true,"width":1,"repeaty":true,"height":6},"skin_right":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/buildings/4/fwall.jpg","repeatx":true,"width":1,"repeaty":true,"height":6}}},"showSortNub":4,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_building4_8OBJCREN1","objType":"cube2","length":500,"width":10,"height":1,"x":-3.703,"y":848.274,"z":99.234,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/4/wapian1112.jpg","repeatx":true,"width":10,"repeaty":true,"height":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/bbb.png"},"skin_fore":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/buildings/4/fwall.jpg","repeatx":true,"width":1,"repeaty":true,"height":6},"skin_behind":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/buildings/4/fwall.jpg","repeatx":true,"width":1,"repeaty":true,"height":6},"skin_left":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/buildings/4/fwall.jpg","repeatx":true,"width":1,"repeaty":true,"height":6},"skin_right":{"skinColor":16777215,"side":2,"opacity":1,"imgurl":"../img/3dImg/buildings/4/fwall.jpg","repeatx":true,"width":1,"repeaty":true,"height":6}}},"showSortNub":4,"customType1":"","customType2":"","animation":null,"dbclickEvents":null,"rotation":[{"direction":"x","degree":0.36981781520507845},{"direction":"y","degree":0},{"direction":"z","degree":0}],"thick":null,"scale":{"x":1,"y":1,"z":1},"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""},{"show":true,"uuid":"","name":"m1_building4_8OBJCREN2","objType":"cube2","length":500,"width":10,"height":1,"x":-3.703,"y":848.274,"z":-100.24,"style":{"skinColor":16777215,"skin":{"skin_up":{"skinColor":16777215,"side":1,"opacity":1,"imgurl":"../img/3dImg/buildings/4/wapian1112.jpg","repeatx":true,"width":10,"repeaty":true,"height":1},"skin_down":{"skinColor":16777215,"side":1,"opacity":1 degree":0}],"show":true,"name":"m1_myCar1_2","scale":{"x":0.1,"y":0.1,"z":0.1},"position":{"x":30,"y":14.536,"z":-2678.582},"uuid":"","objType":"GroupObj","animation":null,"dbclickEvents":null,"BindDevId":null,"BindDevName":null,"devInfo":null,"BindMeteId":"10001","BindMeteName":""}];  return vdata;

}

View Code

B、查看大楼整体布局

模型实现：

function getBuildFloorData() {
    var models = [{ "show": true, "uuid": "", "name": "m4_dtWall_1", "objType": "cube2", "length": 1000, "width": 200, "height": 195, "x": 1460, "y": 110.681, "z": 1573.243, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 0, "opacity": 1 }, "skin_down": { "skinColor": 16777215, "side": 2, "opacity": 0 }, "skin_fore": { "skinColor": 16777215, "side": 2, "opacity": 1, "imgurl": "wall/inner-wall7.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 2, "opacity": 1, "imgurl": "wall/inner-wall7.jpg" }, "skin_left": { "skinColor": 11053224, "side": 2, "opacity": 1, "imgurl": "wall/inner-wall7.jpg", "repeatx": true, "width": 4, "repeaty": true, "height": 1 }, "skin_right": { "skinColor": 16777215, "side": 2, "opacity": 1, "imgurl": "wall/inner-wall7.jpg" } } }, "showSortNub": 1, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_xftube_1", "objType": "tube", "points": [{ "x": 0, "y": 0, "z": 0 }, { "x": 0, "y": 300, "z": 0 }], "position": { "x": 1952.142, "y": 19.368, "z": 1059.789 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 12715012, "imgurl": "outside_lightmap.jpg", "side": 2, "opacity": 1 }, "segments": 1, "radialSegments": 6, "closed": false, "radius": 5, "showSortNub": 1, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_3", "objType": "GroupObj", "scale": { "x": 1, "y": 1, "z": 1 }, "position": { "x": 0, "y": 0, "z": 1489.931 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "childrens": [{ "show": true, "uuid": "", "name": "m4_house_3OBJCREN0", "objType": "cube2", "length": 1000, "width": 15, "height": 200, "x": 0, "y": 110, "z": -739.56, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, " r": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN7", "objType": "cube2", "length": 10, "width": 350, "height": 200, "x": 45, "y": 110, "z": -561.622, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN8", "objType": "cube2", "length": 450, "width": 10, "height": 20, "x": 273.246, "y": 199.838, "z": -102.362, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN9", "objType": "cube2", "length": 10, "width": 20, "height": 200, "x": 45, "y": 110, "z": -99.227, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN10", "objType": "cube2", "length": 1000, "width": 1500, "height": 20, "x": 0, "y": 0, "z": 0, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "hardwood2_diffuse.jpg", "repeatx": true, "width": 5, "repeaty": true, "height": 8 }, "skin_down": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_behind": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_left": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_right": { "skinColor": 10914934, "side": 1, "opacity": 1 } } }, "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN11", "objType": "cube2", "length": 370, "width": 15, "height": 200, "x": -316.426, "y": 110, "z": 339.76, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN12", "objType": "cube2", "length": 200, "width": 600, "height": 20, "x": -600.325, "y": 0, "z": 67.577, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16441035, "side": 1, "opacity": 1, "imgurl": "floor2.png", "repeatx": true, "width": 2, "repeaty": true, "height": 4 }, "skin_down": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_behind": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_left": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_right": { "skinColor": 10914934, "side": 1, "opacity": 1 } } }, "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN13", "objType": "cube2", "length": 370, "width": 15, "height": 200, "x": -315.471, "y": 110, "z": -132.774, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN14", "objType": "cube2", "length": 10, "width": 10, "height": 120, "x": -695.392, "y": 70.242, "z": -227.995, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN15", "objType": "cube2", "length": 10, "width": 10, "height": 120, "x": -695.392, "y": 70.242, "z": 361.754, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN16", "objType": "cube2", "length": 3, "width": 120, "height": 590, "x": -695.392, "y": 70.242, "z": 71.465, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 3 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 3 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948963 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN17", "objType": "cube2", "length": 10, "width": 3, "height": 590, "x": -695.392, "y": 128.949, "z": 71.465, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN18", "objType": "cube2", "length": 3, "width": 120, "height": 200, "x": -598.504, "y": 70.242, "z": 359.208, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 1 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 1 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN19", "objType": "cube2", "length": 3, "width": 120, "height": 200, "x": -598.504, "y": 70.242, "z": -230.897, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 1 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 1 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN20", "objType": "cube2", "length": 10, "width": 3, "height": 200, "x": -591.657, "y": 129.886, "z": -228.407, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN21", "objType": "cube2", "length": 10, "width": 3, "height": 200, "x": -591.657, "y": 129.886, "z": 361.054, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN22", "objType": "cube2", "length": 10, "width": 20, "height": 200, "x": -134.931, "y": 110, "z": 723.374, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN23", "objType": "cube2", "length": 3, "width": 200, "height": 1300, "x": -493.382, "y": 107.994, "z": 4.493, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 5 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 5 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948963 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN24", "objType": "cube2", "length": 3, "width": 180, "height": 450, "x": 267.988, "y": 100.457, "z": -99.313, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/glass-wall4.png", "repeatx": true, "width": 1, "repeaty": true, "height": 2 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/glass-wall4.png", "repeatx": true, "width": 1, "repeaty": true, "height": 2 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/glass-wall4.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/glass-wall4.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948963 }, { "direction": "y", "degree": 5.551115123125783e-17 }, { "direction": "z", "degree": 1.5707963267948963 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN25", "objType": "cube2", "length": 10, "width": 200, "height": 200, "x": -12.767, "y": 110, "z": 633.922, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN26", "objType": "cube2", "length": 450, "width": 10, "height": 200, "x": 273.781, "y": 108.982, "z": -261.797, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN27", "objType": "cube2", "length": 10, "width": 860, "height": 200, "x": 495.218, "y": 110, "z": 307.756, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 10905678, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN28", "objType": "cube2", "length": 5, "width": 130, "height": 200, "x": 495.283, "y": 110, "z": -183.827, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/houseDooor1.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/houseDooor2.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN29", "objType": "cube2", "length": 10, "width": 500, "height": 200, "x": 495.218, "y": 110, "z": -498.058, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 10905678, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN30", "objType": "cube2", "length": 5, "width": 100, "height": 200, "x": 46.436, "y": 110, "z": -337.824, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN31", "objType": "cube2", "length": 10, "width": 40, "height": 200, "x": 46, "y": 110, "z": -267.84, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN32", "objType": "cube2", "length": 5, "width": 100, "height": 200, "x": -133.006, "y": 110, "z": -297.957, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN33", "objType": "cube2", "length": 10, "width": 120, "height": 200, "x": -134.931, "y": 110, "z": -188.356, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN34", "objType": "cube2", "length": 5, "width": 100, "height": 200, "x": -135.353, "y": 110, "z": 397.19, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN35", "objType": "cube2", "length": 5, "width": 105, "height": 200, "x": -47.374, "y": 110, "z": -445.814, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 1.5707963267948966 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN36", "objType": "cube2", "length": 40, "width": 10, "height": 200, "x": 24.619, "y": 108.982, "z": -446.428, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN37", "objType": "cube2", "length": 30, "width": 10, "height": 200, "x": -114.909, "y": 108.982, "z": -446.428, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN38", "objType": "cube2", "length": 140, "width": 10, "height": 200, "x": -64.821, "y": 108.982, "z": 540.395, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN39", "objType": "cube2", "length": 5, "width": 105, "height": 200, "x": 57.635, "y": 110, "z": 539.718, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 1.5707963267948966 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN40", "objType": "cube2", "length": 380, "width": 10, "height": 200, "x": 298.797, "y": 108.982, "z": 539.709, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN41", "objType": "cube2", "length": 10, "width": 100, "height": 200, "x": -134.931, "y": 110, "z": 496.943, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_4OBJCREN42", "objType": "cube2", "length": 5, "width": 170, "height": 200, "x": -135.353, "y": 110, "z": 631.472, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/clouseDoor.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/clouseDoor.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }], "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6", "objType": "GroupObj", "scale": { "x": 1, "y": 1, "z": 1 }, "position": { "x": 1462.752, "y": 0, "z": 0 }, "rotation": [{ "direction": "x", "degree": -3.141592653589793 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": -3.141592653589793 }], "childrens": [{ "show": true, "uuid": "", "name": "m4_house_6OBJCREN0", "objType": "cube2", "length": 1000, "width": 15, "height": 200, "x": 0, "y": 110, "z": -739.56, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN1", "objType": "cube2", "length": 1000, "width": 15, "height": 200, "x": 0, "y": 110, "z": 740.99, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN2", "objType": "cube2", "length": 15, "width": 100, "height": 200, "x": -492.715, "y": 110, "z": -696.636, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN3", "objType": "cube2", "length": 15, "width": 100, "height": 200, "x": -492.715, "y": 110, "z": -186.399, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN4", "objType": "cube2", "length": 15, "width": 100, "height": 200, "x": -492.715, "y": 110, "z": 696.395, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN5", "objType": "cube2", "length": 15, "width": 20, "height": 200, "x": -492.715, "y": 110, "z": 349.9, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN6", "objType": "cube2", "length": 10, "width": 400, "height": 200, "x": -134.931, "y": 110, "z": -545.459, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN7", "objType": "cube2", "length": 10, "width": 350, "height": 200, "x": 45, "y": 110, "z": -561.622, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN8", "objType": "cube2", "length": 450, "width": 10, "height": 20, "x": 273.246, "y": 199.838, "z": -102.362, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN9", "objType": "cube2", "length": 10, "width": 20, "height": 200, "x": 45, "y": 110, "z": -99.227, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN10", "objType": "cube2", "length": 1000, "width": 1500, "height": 20, "x": 0, "y": 0, "z": 0, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "hardwood2_diffuse.jpg", "repeatx": true, "width": 5, "repeaty": true, "height": 8 }, "skin_down": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_behind": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_left": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_right": { "skinColor": 10914934, "side": 1, "opacity": 1 } } }, "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN11", "objType": "cube2", "length": 370, "width": 15, "height": 200, "x": -316.426, "y": 110, "z": 339.76, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN12", "objType": "cube2", "length": 200, "width": 600, "height": 20, "x": -600.325, "y": 0, "z": 67.577, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16441035, "side": 1, "opacity": 1, "imgurl": "floor2.png", "repeatx": true, "width": 2, "repeaty": true, "height": 4 }, "skin_down": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_behind": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_left": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_right": { "skinColor": 10914934, "side": 1, "opacity": 1 } } }, "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN13", "objType": "cube2", "length": 370, "width": 15, "height": 200, "x": -315.471, "y": 110, "z": -132.774, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN14", "objType": "cube2", "length": 10, "width": 10, "height": 120, "x": -695.392, "y": 70.242, "z": -227.995, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN15", "objType": "cube2", "length": 10, "width": 10, "height": 120, "x": -695.392, "y": 70.242, "z": 361.754, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN16", "objType": "cube2", "length": 3, "width": 120, "height": 590, "x": -695.392, "y": 70.242, "z": 71.465, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 3 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 3 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948963 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN17", "objType": "cube2", "length": 10, "width": 3, "height": 590, "x": -695.392, "y": 128.949, "z": 71.465, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN18", "objType": "cube2", "length": 3, "width": 120, "height": 200, "x": -598.504, "y": 70.242, "z": 359.208, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 1 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 1 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN19", "objType": "cube2", "length": 3, "width": 120, "height": 200, "x": -598.504, "y": 70.242, "z": -230.897, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 1 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 1 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN20", "objType": "cube2", "length": 10, "width": 3, "height": 200, "x": -591.657, "y": 129.886, "z": -228.407, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN21", "objType": "cube2", "length": 10, "width": 3, "height": 200, "x": -591.657, "y": 129.886, "z": 361.054, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN22", "objType": "cube2", "length": 10, "width": 20, "height": 200, "x": -134.931, "y": 110, "z": 723.374, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN23", "objType": "cube2", "length": 3, "width": 200, "height": 1300, "x": -493.382, "y": 107.994, "z": 4.493, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 5 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 5 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948963 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN24", "objType": "cube2", "length": 3, "width": 180, "height": 450, "x": 267.988, "y": 100.457, "z": -99.313, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/glass-wall4.png", "repeatx": true, "width": 1, "repeaty": true, "height": 2 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/glass-wall4.png", "repeatx": true, "width": 1, "repeaty": true, "height": 2 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/glass-wall4.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/glass-wall4.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948963 }, { "direction": "y", "degree": 5.551115123125783e-17 }, { "direction": "z", "degree": 1.5707963267948963 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN25", "objType": "cube2", "length": 10, "width": 200, "height": 200, "x": -12.767, "y": 110, "z": 633.922, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN26", "objType": "cube2", "length": 450, "width": 10, "height": 200, "x": 273.781, "y": 108.982, "z": -261.797, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN27", "objType": "cube2", "length": 10, "width": 860, "height": 200, "x": 495.218, "y": 110, "z": 307.756, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 10905678, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN28", "objType": "cube2", "length": 5, "width": 130, "height": 200, "x": 495.283, "y": 110, "z": -183.827, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/houseDooor1.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/houseDooor2.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN29", "objType": "cube2", "length": 10, "width": 500, "height": 200, "x": 495.218, "y": 110, "z": -498.058, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 10905678, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN30", "objType": "cube2", "length": 5, "width": 100, "height": 200, "x": 46.436, "y": 110, "z": -337.824, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN31", "objType": "cube2", "length": 10, "width": 40, "height": 200, "x": 46, "y": 110, "z": -267.84, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN32", "objType": "cube2", "length": 5, "width": 100, "height": 200, "x": -133.006, "y": 110, "z": -297.957, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN33", "objType": "cube2", "length": 10, "width": 120, "height": 200, "x": -134.931, "y": 110, "z": -188.356, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN34", "objType": "cube2", "length": 5, "width": 100, "height": 200, "x": -135.353, "y": 110, "z": 397.19, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN35", "objType": "cube2", "length": 5, "width": 105, "height": 200, "x": -47.374, "y": 110, "z": -445.814, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 1.5707963267948966 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN36", "objType": "cube2", "length": 40, "width": 10, "height": 200, "x": 24.619, "y": 108.982, "z": -446.428, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN37", "objType": "cube2", "length": 30, "width": 10, "height": 200, "x": -114.909, "y": 108.982, "z": -446.428, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN38", "objType": "cube2", "length": 140, "width": 10, "height": 200, "x": -64.821, "y": 108.982, "z": 540.395, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN39", "objType": "cube2", "length": 5, "width": 105, "height": 200, "x": 57.635, "y": 110, "z": 539.718, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor3.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/housedooor4.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 1.5707963267948966 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN40", "objType": "cube2", "length": 380, "width": 10, "height": 200, "x": 298.797, "y": 108.982, "z": 539.709, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN41", "objType": "cube2", "length": 10, "width": 100, "height": 200, "x": -134.931, "y": 110, "z": 496.943, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_6OBJCREN42", "objType": "cube2", "length": 5, "width": 170, "height": 200, "x": -135.353, "y": 110, "z": 631.472, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/clouseDoor.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/clouseDoor.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }], "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5", "objType": "GroupObj", "scale": { "x": 1, "y": 1, "z": 1 }, "position": { "x": 1462.752, "y": 0, "z": 2418.819 }, "rotation": [{ "direction": "x", "degree": -3.141592653589793 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": -3.141592653589793 }], "childrens": [{ "show": true, "uuid": "", "name": "m4_house_5OBJCREN0", "objType": "cube2", "length": 1000, "width": 15, "height": 200, "x": 0, "y": 110, "z": -739.56, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN1", "objType": "cube2", "length": 1000, "width": 15, "height": 200, "x": 0, "y": 110, "z": 740.99, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN2", "objType": "cube2", "length": 15, "width": 100, "height": 200, "x": -492.715, "y": 110, "z": -696.636, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN3", "objType": "cube2", "length": 15, "width": 100, "height": 200, "x": -492.715, "y": 110, "z": -186.399, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN4", "objType": "cube2", "length": 15, "width": 100, "height": 200, "x": -492.715, "y": 110, "z": 696.395, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN5", "objType": "cube2", "length": 15, "width": 20, "height": 200, "x": -492.715, "y": 110, "z": 349.9, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN6", "objType": "cube2", "length": 10, "width": 400, "height": 200, "x": -134.931, "y": 110, "z": -545.459, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN7", "objType": "cube2", "length": 10, "width": 350, "height": 200, "x": 45, "y": 110, "z": -561.622, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN8", "objType": "cube2", "length": 450, "width": 10, "height": 20, "x": 273.246, "y": 199.838, "z": -102.362, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN9", "objType": "cube2", "length": 10, "width": 20, "height": 200, "x": 45, "y": 110, "z": -99.227, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN10", "objType": "cube2", "length": 1000, "width": 1500, "height": 20, "x": 0, "y": 0, "z": 0, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "hardwood2_diffuse.jpg", "repeatx": true, "width": 5, "repeaty": true, "height": 8 }, "skin_down": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_behind": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_left": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_right": { "skinColor": 10914934, "side": 1, "opacity": 1 } } }, "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN11", "objType": "cube2", "length": 370, "width": 15, "height": 200, "x": -316.426, "y": 110, "z": 339.76, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN12", "objType": "cube2", "length": 200, "width": 600, "height": 20, "x": -600.325, "y": 0, "z": 67.577, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16441035, "side": 1, "opacity": 1, "imgurl": "floor2.png", "repeatx": true, "width": 2, "repeaty": true, "height": 4 }, "skin_down": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_behind": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_left": { "skinColor": 10914934, "side": 1, "opacity": 1 }, "skin_right": { "skinColor": 10914934, "side": 1, "opacity": 1 } } }, "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN13", "objType": "cube2", "length": 370, "width": 15, "height": 200, "x": -315.471, "y": 110, "z": -132.774, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN14", "objType": "cube2", "length": 10, "width": 10, "height": 120, "x": -695.392, "y": 70.242, "z": -227.995, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN15", "objType": "cube2", "length": 10, "width": 10, "height": 120, "x": -695.392, "y": 70.242, "z": 361.754, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN16", "objType": "cube2", "length": 3, "width": 120, "height": 590, "x": -695.392, "y": 70.242, "z": 71.465, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 3 }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png", "repeatx": true, "width": 1, "repeaty": true, "height": 3 }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "glass2.png" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948963 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN17", "objType": "cube2", "length": 10, "width": 3, "height": 590, "x": -695.392, "y": 128.949, "z": 71.465, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 1.5707963267948966 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_5OBJCREN18", "objType": "cube2", "length": 3, "width": 120, "height": 200, "x": -598.504, "y": 70.242, "z": 359.208, "style" opacity": 1 } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 1.5707963267948966 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_2OBJCREN36", "objType": "cube2", "length": 40, "width": 10, "height": 200, "x": 24.619, "y": 108.982, "z": -446.428, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_house_2OBJCREN37", "objType": "cube2", "length": 30, "width": 10, "height": 200, "x": -114.909, "y": 108.982, "z": -446.428, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_behind": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_left": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" }, "skin_right": { "skinColor": 16777215, "side": 1, "opacity": 1, "imgurl": "wall/wall6.jpg" } } }, "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindD e": "" }], "showSortNub": 4, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }];
    return models;
}
function openDoor1(_obj, func, _cmd) {
    var doorstate = "close";
    var tempobj = null;
    if (_obj.doorState != null && typeof (_obj.doorState) != 'undefined') {
        doorstate = _obj.doorState;
        tempobj = _obj.parent;
    } else {
        _obj.oldPosition = { x: _obj.position.x, y: _obj.position.y, z: _obj.position.z }
        _obj.doorState = "close";
        var _objparent = _obj.parent;
        tempobj = new THREE.Object3D();
        tempobj.position.set(_obj.position.x, _obj.position.y, _obj.position.z - _obj.geometry.parameters.depth / 2);
        _obj.position.set(0, 0,_obj.geometry.parameters.depth / 2);
        tempobj.add(_obj);
        _objparent.add(tempobj);
    }
    if (typeof (_cmd) == 'undefined' || _cmd == null || _cmd == "") {
        _obj.doorState = (doorstate == "close" ? "open" : "close");
    } else {
        if (_cmd == _obj.doorState) {
            if (func != null) {
                func();
            }
            return;
        } else {
            _obj.doorState = _cmd;
        }
    }
    new TWEEN.Tween(tempobj.rotation).to({
        y: (_obj.doorState == "open" ? 0.25 * 2 * Math.PI : 0 * 2 * Math.PI)
    }, 3000).easing(TWEEN.Easing.Elastic.Out).onComplete(
        function () {
            if (func != null) {
                func();
            }
        }
        ).start();
}
function openDoor2(_obj, func, _cmd) {
    var doorstate = "close";
    var tempobj = null;
    if (_obj.doorState != null && typeof (_obj.doorState) != 'undefined') {
        doorstate = _obj.doorState;
        tempobj = _obj.parent;
    } else {
        _obj.oldPosition = { x: _obj.position.x, y: _obj.position.y, z: _obj.position.z }
        _obj.doorState = "close";
        var _objparent = _obj.parent;
        tempobj = new THREE.Object3D();
        tempobj.position.set(_obj.position.x, _obj.position.y, _obj.position.z + _obj.geometry.parameters.depth / 2);
        _obj.position.set( 0, 0,-_obj.geometry.parameters.depth / 2);
        tempobj.add(_obj);
        _objparent.add(tempobj);
    }
    if (typeof (_cmd) == 'undefined' || _cmd == null || _cmd == "") {
        _obj.doorState = (doorstate == "close" ? "open" : "close");
    } else {
        if (_cmd == _obj.doorState) {
            if (func != null) {
                func();
            }
            return;
        } else {
            _obj.doorState = _cmd;
        }
    }
    new TWEEN.Tween(tempobj.rotation).to({
        y: (_obj.doorState == "open" ? -0.25 * 2 * Math.PI : 0 * 2 * Math.PI)
    }, 3000).easing(TWEEN.Easing.Elastic.Out).onComplete(function () {
        if (func != null) {
            func();
        }
    }).start();
}

View Code

C、查看楼层布局

D、消防大楼监控室模拟

E、火情告警模拟

F、救援路径导航

G、火情救援

H、内部火情模拟

I、内部获取救援

J、第一人称视角切换

k、摄像机调用

代码实现：

<!DOCTYPE html>
<html style="padding:0px;margin:0px;">
<head>
    <style>

        .canvas_frame {
            border: none;
            cursor: pointer;
            width: 100%;
            height: 100%;
            background-color: rgba(0, 0, 0, 0);
            overflow: hidden;
        }

        .toolbar {
            display: block;
            position: absolute;
            left: 10px;
            top: 75px;
            width: 32px;
            height: auto;
            background: rgba(0, 77, 90, 0.66);
            border-radius: 5px;
            padding: 5px;
            box-sizing: content-box !important;
            -webkit-box-sizing: content-box !important;
        }

            .toolbar img {
                float: left;
                margin: 5px;
                width: 24px;
                height: 24px;
                pointer-events: auto;
                cursor: pointer;
            }

        .Stats_output {
            display: block;
            position: absolute;
            border-radius: 5px;
            padding: 5px;
        }

        #canvas-frame > canvas {
            border-top-left-radius: 7px;
            border-bottom-right-radius: 7px;
            border-top-right-radius: 7px;
            border-bottom-left-radius: 7px;
        }

        .layui-layer-hui {
            border-radius: 10px;
            background: rgba(18, 65, 86, 0.71) !important;
            border: 1px solid rgb(11, 185, 223) !important;
        }

        input {
            color: black !important;
        }
    </style>
    <title></title>
    <meta charset="utf-8" />
    <link href="../css/iconfont.css" rel="stylesheet" />
    <link href="../css/bootstrap.css" rel="stylesheet" />
    <link href="../plugs/layer/layui/css/layui.css" rel="stylesheet" />
    <script src="../js/jquery-2.2.2.js"></script>
    <script src="../plugs/layer/layer.js"></script>
    <script src="../plugs/layer/laydate/laydate.js"></script>
    <script src="../plugs/layer/layui/layui.js"></script>
    <script src="../js/models/buildFloorModel.js"></script>
    <script src="../js/models/buildProfileModel.js"></script>
    <script src="../js/models/monitoringRoomModel.js"></script>
    <script src="../js/models/parkModel.js"></script>
    <script src="../js/commonFunction.js"></script>
    <script src="../js/w3DShowCore.js"></script>
    <script src="../js/w3DShowBSP.js"></script>
    <script src="../js/w3DShowTween.js"></script>
    <script src="../js/sourse/Detector.js"></script>
    <script src="../js/sourse/OBJLoader.js"></script>
    <script src="../js/sourse/MTLLoader.js"></script>
    <script src="../js/sourse/ColladaLoader.js"></script>
    <script src="../js/sourse/FirstPersonControls.js"></script>
    <script src="../js/w3DShowOrbitControls.js"></script>
    <script src="../js/w3DShowTransform.js"></script>
    <script src="../js/w3DShowCanvasCore.js"></script>
    <script src="../js/w3DShowParticleEngine.js"></script>
    <script src="../js/stats.min.js"></script>
    <script src="../js/models/modelBusiness.js"></script>
    <script src="../js/data.js"></script>
</head>
<body onload="threeStart(0);" style="padding:0px;margin:0px;">
    <script>
        if (!Detector.webgl) {
            layer.alert("您的浏览器不支持3D功能,请使用支持WebGL的浏览器（例如：chrome浏览器、ie11以上浏览器等）");
        }
    </script>
    <div id="dataCanvasList" style="position:absolute;z-index:-1;display:none;width:5px;height:5px;overflow:hidden;"><div style="width:10px;height:10px;float:left;position:relative;"></div></div>
    <div id="canvas-frame" class="canvas_frame"></div>


  <script>
        $(document).ready(function () {
            var _html = '<div class="layui-progress layui-progress-big" lay-showpercent="true" lay-filter="progress">\
                          <div class="layui-progress-bar layui-bg-red" lay-percent="10%"></div>\
                         </div>';
          var layerIndex=  layer.open({
                type: 1,
                title: false,
                closeBtn: 0,
                shade: 0.6,
                area: '516px',
                skin: 'layui-layer-nobg', //没有背景色
                shadeClose: false,
                content: _html
            });
            function setProcessValue() {
                setTimeout(function () {
                    var value = Math.floor((w3DShowObj.scene.children.length+100) / w3DShowObj.objJsonList.length * 100);
                    layui.use('element', function () {
                        layui.element.progress("progress", value + "%")
                    });
                    if (value < 100) {
                        setProcessValue();
                    } else {
                        layer.closeAll();
                    }
                }, 2000);
            }
            setProcessValue();
        });
    </script>
</body>
</html>

View Code

逻辑功能实现

function WTBS() { }
WTBS.prototype.init = function () {
    var _this = this;
    _this.currentShow = "parkModel";
}

//双击事件推进后执行
WTBS.prototype.dbclickBackFunc = function (_obj, _face) {
    var _this = this;
    if (_obj && _obj.name && (w3DShowObj.camera.name != "firstPersonCamera")) {
        if (_obj.name.indexOf("model1build3_") >= 0) {
            _this.showBuilding3(_obj);
        } else if (_obj.name.indexOf("model1xfj_building") >= 0) {
            _this.showXFBuilding(_obj);
        } else if (_obj.name.indexOf("model1build2_") >= 0) {
            _this.showBuildFloor(_obj);
        }
    }
}

WTBS.prototype.ParkModels = null;
WTBS.prototype.getParkModels = function () {
    var _this = this;
    var objs = [];
    if (_this.ParkModels) {
        objs= _this.ParkModels;
    } else {
        $.each(w3DShowObj.scene.children, function (_index, _obj) {
            if (_obj.name.indexOf("model1") >= 0) {
                objs.push(_obj);
            }
        });
    }
    return objs;
}
WTBS.prototype.loadParkModels = function () {
    this.loadData(getParkModelData(),"parkModels");
}
WTBS.prototype.backToParkModels=function(sucFunc){
    var _this = this;


        var hidemodels = null;
        //隐藏当前模型
        switch (_this.currentShow) {
            case "profileModel":
                hidemodels = _this.getBuildProfileModels();
                break;
            case "buildFloorModel":
                hidemodels = _this.getBuildFloorModels();
                break;
            case "monitoringRoomModels":
                hidemodels = _this.getMonitoringRoomModels();
                break;
        }
        if (hidemodels) {
            _this.vModels(hidemodels, function () {
                _this.hideModels(hidemodels, function () {
                    var parkModels = _this.getParkModels();
                    _this.eModels(parkModels, function () {
                        _this.showModels(parkModels, function () {
                            if (sucFunc) {
                                sucFunc();
                            }
                        })
                    });
                });
            });
        } else {
            if (sucFunc) {
                sucFunc();
            }
        }


}
WTBS.prototype.BuildProfileModels = null;
WTBS.prototype.getBuildProfileModels = function () {
    var _this = this;
    var objs = [];
    if (_this.BuildProfileModels) {
        objs = _this.BuildProfileModels;
    } else {
        $.each(w3DShowObj.scene.children, function (_index, _obj) {
            if (_obj.name.indexOf("m2_") >= 0) {
                objs.push(_obj);
            }
        });
    }
    return objs;
}
WTBS.prototype.loadBuildProfileModels = function (afterLoadedShow) {
    this.loadData(getbuildProfileData(), "buildProfileModels", null, null, afterLoadedShow);
}
//显示小区大楼切面
WTBS.prototype.showBuilding3 = function (_selectobj,sucFunc,showFire) {
    var _this = this;
    //隐藏园区模型
    _this.currentShow = "profileModel";
    var parkModels = _this.getParkModels();
    _this.vModels(parkModels, function () {
        _this.hideModels(parkModels, function () {
            //移动摄像机
            w3DShowObj.commonFunc.changeCameraPosition({ x: 1890.4986417114203, y: 925.7272476626204, z: -2.7744218508244103 }, { x: -71.32439584972124, y: 362.41224258427457, z: -199.41027763874382 }, 100, function () {
               // _this.loadBuildProfileModels(true);

                ///m2_fire_1 m2_smoke_1 m2_pl_water
                var models = _this.getBuildProfileModels();
                var showmodels = [];
                $.each(models, function (_index, _obj) {
                    if (showFire) {
                            showmodels.push(_obj);
                    } else {
                        if ("|m2_fire_1|m2_smoke_1|m2_pl_water|".indexOf(_obj.name) < 0) {
                            showmodels.push(_obj);
                        }
                    }
                });
                _this.eModels(showmodels, sucFunc);
            });
        });
    });
}

WTBS.prototype.BuildFloorModels = null;
WTBS.prototype.getBuildFloorModels = function () {
    var _this = this;
    var objs = [];
    if (_this.BuildFloorModels) {
        objs = _this.BuildFloorModels;
    } else {
        $.each(w3DShowObj.scene.children, function (_index, _obj) {
            if (_obj.name.indexOf("m4_") >= 0) {
                objs.push(_obj);
            }
        });
    }
    return objs;
}
WTBS.prototype.loadBuildFloorModels = function (afterLoadedShow) {
    this.loadData(getBuildFloorData(), "buildFloorData", null, null, afterLoadedShow);
}
WTBS.prototype.showBuildFloor = function (_obj,sucFunc) {
    var _this = this;
    _this.currentShow = "buildFloorModel";
    //隐藏园区模型
    var parkModels = _this.getParkModels();
    _this.vModels(parkModels, function () {
        _this.hideModels(parkModels, function () {
            //移动摄像机
            w3DShowObj.commonFunc.changeCameraPosition({ x: 5951.4764511885005, y: 6206.7741894325345, z: 1521.5680109845248 }, { x: 886.9791391436224, y: 299.4744098643677, z: 1587.278714176637 }, 100, function () {
                //_this.loadBuildFloorModels(true);
                var models = _this.getBuildFloorModels();
                _this.eModels(models, sucFunc);
            });
        });
    });
}
WTBS.prototype.MonitoringRoomModels = null;
WTBS.prototype.getMonitoringRoomModels = function () {
    var _this = this;
    var objs = [];
    if (_this.MonitoringRoomModels) {
        objs = _this.MonitoringRoomModels;
    } else {
        $.each(w3DShowObj.scene.children, function (_index, _obj) {
            if (_obj.name.indexOf("m3_") >= 0) {
                objs.push(_obj);
            }
        });
    }
    return objs;
}
WTBS.prototype.loadMonitoringRoomModels= function (afterLoadedShow) {
    this.loadData(getMoniRoomData(), "monitoringRoomModels",null,null, afterLoadedShow);
}
//双击消防大楼 显示监控室
WTBS.prototype.showXFBuilding = function (_obj) {
    var _this = this;
    _this.currentShow = "monitoringRoomModels";
    //隐藏园区模型
    var parkModels = _this.getParkModels();
    _this.vModels(parkModels, function () {
        _this.hideModels(parkModels, function () {
                //移动摄像机
            w3DShowObj.commonFunc.changeCameraPosition({ x: -6987, y: 3127, z: -3740 }, { x: 1439, y: 1159, z: 1271 }, 10, function () {
            //    _this.loadMonitoringRoomModels(true);
                var models = _this.getMonitoringRoomModels();
                _this.eModels(models);
           });
         });
    });

}

WTBS.prototype.changeCamera = function (toCamera) {
    if (w3DShowObj.camera.name == "firstPersonCamera") {
        if (toCamera && toCamera == "firstPersonCamera") {
        } else {
            w3DShowObj.changeCamera("mainCamera");
            w3DShowObj.commonFunc.changeCameraPosition({ x: -3651.9999999999995, y: 3193, z: -4190.999999999999 }, { x: -174, y: 129, z: -663 }, 1000, function () {
            w3DShowObj.commonFunc.changeCameraPosition({ x: -3651.9999999999995, y: 3193, z: -4190.999999999999 }, { x: -174, y: 129, z: -663 }, 1, function () { });
            $("#btn_camera").attr("title", "切换为第一人称摄像机");
            $("#btn_camera").attr("src", "firstCamera.png");
        });
        }
    } else {
        if (toCamera && toCamera == "mainCamera") {
        } else {
        w3DShowObj.commonFunc.changeCameraPosition({ x: -23.99693371859561, y: 74.21989687790614, z: 1436.5002934512606 }, { x: -17.041795003996086, y: 92.48205391598694, z: 1338.4282807984291 }, 1000, function () {
            w3DShowObj.changeCamera("firstPersonCamera");
            w3DShowObj.camera.position.x = -23.99693371859561;
            w3DShowObj.camera.position.y = 74.21989687790614;
            w3DShowObj.camera.position.z = 1436.5002934512606;

            w3DShowObj.controls.target.x = -17.041795003996086;
            w3DShowObj.controls.target.y=92.48205391598694;
            w3DShowObj.controls.target.z = 1338.4282807984291;

            w3DShowObj.camera.rotation.x = 0.1301414611156121;
            w3DShowObj.camera.rotation.y = 0.19002711797053154;
            w3DShowObj.camera.rotation.z = -0.024716526388785742;
            $("#btn_camera").attr("title", "切换为第三人称摄像机");
            $("#btn_camera").attr("src", "thirdCamera.png");
        });

        }
    }
}
//消防演练
WTBS.prototype.roadPathData = {
    publicPath:[{ x: 3580.7721020065833, y: 17.92388626935505, z: -3156.5926198992825 },
                {x: 3047.384634807978, y: 17.92388626935505, z: -3483.621376400016 },
                {x: 2576.395361698657, y: 17.92388626935505, z: -3666.2181322308456 },
                {x: -107.48800358032258, y: 17.92388626935505, z: -3666.2181322308456 },
                { x: -107.48800358032258, y: 17.92388626935505, z: 590.5114163569147 }],
    buildPath_1: [
        { x: -413.2702197772283, y: 17.92388626935505, z: 590.5114163569147 },
        { x: -575.6154601766582, y: 17.92388626935505, z: 472.4975088431494 }],
    buildPathPeoples_1: [
        { x: -354.92920316027744, y: -24.873, z: 686.551662500611 },
        { x: -275.625821271076, y: -24.873, z: 686.551662500611 },
        { x: -500.81870825864485, y: 72.68768761606009, z: 475.80824428017644 },
        { x: -500.81870825864485, y: 72.68768761606009, z: 207.61178352238835 }
    ],

    buildPath_2: [{ x: -413.2702197772283, y: 17.92388626935505, z: 590.5114163569147 },
    { x: -575.6154601766582, y: 17.92388626935505, z: 472.4975088431494 },
    { x: -858.6645825831624, y: 17.92388626935505, z: 29.098512979733073 }],
    buildPathPeoples_2: [
        { x: -923.1392900646454, y: -24.873, z: 325.8521239022001 },
        { x: -872.557339554651, y: -24.873, z: 325.8521239022001 },
        { x: -1170.9461298809692, y: 72.688, z: 271.47352637164516 },
        { x: -1170.9461298809692, y: 72.688, z: -77.31615737474004 }

    ],
    buildPath_3: [{ x: -1705.279061825236, y: 17.92388626935505, z: 614.229079721032 },
     { x: -2510.694014101294, y: 17.92388626935505, z: 1080.947443610195 },
     { x: -2949.5899989962563, y: 17.92388626935505, z: 1186.2022691608045 }],
    buildPathPeoples_3: [
        { x: -2760.3943614260756, y: -24.873, z: 1625.7583460432772 },
        { x: -2760.3943614260756, y: -24.873, z: 1530.0955849485265 },
        { x: -2807.2546245191566, y: 72.688, z: 1177.442473684558 },
        { x: -3121.0743823647076, y: 72.688, z: 1177.442473684558 },
        { x: -3121.0743823647076, y: 72.688, z: 1432.3379374625736 }

    ],
    buildPath_4: [{ x: -1983.869601462901, y: 17.92388626935505, z: 614.2373907022447 },
        { x: -1983.869601462901, y: 17.92388626935505, z: -111.35122052838256 }],
    buildPathPeoples_4: [
        { x: -1833.7535270750486, y: -24.873, z: 140.2049525114066 },
        { x: -1833.7535270750486, y: -24.873, z: 220.7331081380675 },
        { x: -2057.476, y: 72.688, z: 535.95537248100595 },
        { x: -2350.4365290959154, y: 72.688, z: 363.95537248100595 }
    ],

    buildPath_5: [{ x: -1983.869601462901, y: 17.92388626935505, z: 614.2373907022447 },
    { x: -1983.869601462901, y: 17.92388626935505, z: -111.35122052838256 },
    { x: -2726.0653885266493, y: 17.92388626935505, z: -111.35122052838256 }],
    buildPathPeoples_5: [ {x: -2589.0271473668204, y: -24.873, z: 311.0526178457409 },
        { x: -2589.0271473668204, y: -24.873, z: 382.4404722154801 },
        { x: -3064.450, y: 72.688, z: 475.225 },
        { x: -3064.4365290959154, y: 72.688, z: 179.939 }
    ],

    buildPath_6: [{ x: -1983.869601462901, y: 17.92388626935505, z: 614.2373907022447 },
    { x: -1983.869601462901, y: 17.92388626935505, z: -111.35122052838256 },
    { x: -2405.1932638255066, y: 17.92388626935505, z: -618.6924653066992 }],
    buildPathPeoples_6: [{ x: -2166.608, y: -24.873, z: -909.161612666987 },
        { x: -2204.038, y: -24.873, z: -965},
        { x: -2648.608, y: 72.688, z: -926.638},
        { x: -2881.774, y: 72.688, z: -601.982 }
    ],

    buildPath_7: [{ x: -694.0867159986417, y: 17.92388626935505, z: 595.8553302083877 },
        { x: -694.0867159986417, y: 17.92388626935505, z: -1107.591840054678 }],
    buildPathPeoples_7: [{ x: -858.3942967523726, y: -24.873, z: -954.7470265747439 },
        { x: -858.3942967523726, y: -24.873, z: -1046.4046275285905 },
        { x: -364.377, y: 72.688, z: -1046.4046275285905},
        { x: -364.4365290959154, y: 72.688, z: -699.307 }
    ],

    buildPath_8: [{ x: -694.0867159986417, y: 17.92388626935505, z: 595.8553302083877 },
        { x: -694.0867159986417, y: 17.92388626935505, z: -1107.591840054678 }],
    buildPathPeoples_8: [{ x: -1014.8893156392728, y: -24.873, z: -1613.6386170342057 },
        { x: -1014.8893156392728, y: -24.873, z: -1483.3266514034665 },
        { x: -587.140, y: 72.688, z: -1216.539 },
        { x: -493.897, y: 72.688, z: -1619.992 }
    ],

    buildPath_9: [{ x: -694.0867159986417, y: 17.92388626935505, z: 595.8553302083877 },
     { x: -694.0867159986417, y: 17.92388626935505, z: -1107.591840054678 },
     { x: -1410.5332835962133, y: 17.92388626935505, z: -1107.591840054678 }],
    buildPathPeoples_9: [{ x: -1436.8064286552606, y: -24.873, z: -1071.5170589907527 },
        { x: -1497.5840839697357, y: -24.873, z: -1071.5170589907527 },
        { x: -1308.352, y: 72.688, z: -1402.888},
        { x: -1597.963, y: 72.688, z: -1473.342 }
    ],

    buildPath_10: [{ x: -1410.5332835962133, y: 17.92388626935505, z: 605.9075715693755 },
        { x: -1601.1451398610843, y: 17.92388626935505, z: 1106.333646529646 }],
    buildPathPeoples_10: [{ x: -1497.5840839697357, y: -24.873, z: 1071.1933216650134 },
        { x: -1612.8938677568567, y: -24.873, z: 1071.1933216650134 },
        { x: -1683.113, y: 72.688, z: 1082.002},
        { x: -1750.712, y: 72.688, z: 1384.185 }
    ],

    buildPath_11: [{ x: -569.7525865574022, y: -924.431706161469, z: 639.2826850417543 },
        { x: -569.7525865574022, y: -924.431706161469, z: 1326.2298098226368 }],
    buildPathPeoples_11: [{ x: -407.5318857636871, y: -24.873, z: 959.9896943204546 },
        { x: -365.45995025102496, y: -24.873, z: 959.9896943204546 },
        { x: -597.188, y: 72.688, z: 1067.458 },
        { x: -597.188, y: 72.688, z: 1348.137 }],
    buildCameraPosition_1: [{ x: -24.163199142985434, y: 446.94150251372656, z: 1226.4985674399672 }, { x: -389.93700345529624, y: 343.82717937105735, z: 457.58538193335727 }],
    buildCameraPosition_2: [{ "x": -328.45969510549253, "y": 182.67290523217872, "z": 843.2096066819893 }, { "x": -1222.360151876304, "y": 301.2292885252543, "z": 10.007274175505602 }],
    buildCameraPosition_3: [{ "x": -2102.316022563398, "y": 76.30870033159925, "z": 820.2711623529518 }, { "x": -3282.845826885127, "y": 358.6158021902579, "z": 1564.788990686582 }],
    buildCameraPosition_4: [{ "x": -1144.8058794023336, "y": 462.26480387290064, "z": 1127.3972509719656 }, { "x": -2428.797829618296, "y": 313.9372721319275, "z": 222.52616787385563 }],
    buildCameraPosition_5: [{ "x": -1902.558697076418, "y": 272.2154972028064, "z": -498.5563571007863 }, { "x": -2654.1869242155026, "y": 321.9908933436772, "z": 71.53340175608369 }],
    buildCameraPosition_6: [{ "x": -872.267316305848, "y": 735.9151916423075, "z": -1243.0960115772687 }, { "x": -2777.5411868476754, "y": 309.3737056775955, "z": -106.134839266717 }],
    buildCameraPosition_7: [{ "x": -795.7414141456069, "y": 234.31891461641843, "z": 484.89291238688975 }, { "x": -762.5649106525581, "y": 324.98923235263777, "z": -670.9036868752492 }],
    buildCameraPosition_8: [{ "x": -1446.2741250545457, "y": 651.3353956133313, "z": -287.8323650787228 }, { "x": -824.3187000543771, "y": 349.9177448476733, "z": -1073.9510131595132 }],
    buildCameraPosition_9: [{ "x": -597.174138639469, "y": 314.86823345842805, "z": -478.7134844047999 }, { "x": -1081.5624695303904, "y": 302.69943840236584, "z": -976.1576226259127 }],
    buildCameraPosition_10: [{ "x": -1301.3216149121115, "y": 422.32391588930665, "z": -121.97931197560251 }, { "x": -1448.1782309945058, "y": 415.89337468191627, "z": 1222.7697958744425 }],
    buildCameraPosition_11: [{ "x": 144.45739205620396, "y": 428.80813026440933, "z": 19.23321129187684 }, { "x": -586.0816357186471, "y": 402.54215701931815, "z": 1327.7941206228331 }],
}
WTBS.prototype.doFireAnimation = function () {
    var _this = this;
    var html = "<iframe id='iframe_fireSelect' src='select.html?" + Math.random() + "' style='border:0px solid rgba(0,0,0,0);height:230px;width:300px;' ></iframe>";
    layer.msg(html, {
        title:"消防参数配置",
        shade: 0.4,
        time: 0 //不自动关闭
        , btn: ['开始演习', '取消演习']
        , yes: function (index) {
            var build = parseInt($("#iframe_fireSelect").contents().find("#select_build").val());
            var select_floor = parseInt($("#iframe_fireSelect").contents().find("#select_floor").val());
            var select_fireType = parseInt($("#iframe_fireSelect").contents().find("#select_fireType").val());
            var select_fireSize = parseInt($("#iframe_fireSelect").contents().find("#select_fireSize").val());
            var select_V = parseInt($("#iframe_fireSelect").contents().find("#select_V").val());
            console.log(build);
            console.log(select_floor);
            console.log(select_fireType);
            console.log(select_fireSize);
            console.log(select_V);
            _this.animationParam.build = build;
            _this.animationParam.select_floor = select_floor;
            _this.animationParam.select_fireType = select_fireType;
            _this.animationParam.select_fireTypeStr = $("#iframe_fireSelect").contents().find("#select_fireType option:selected").text();
            _this.animationParam.select_fireSize = select_fireSize;
            _this.animationParam.select_V = select_V;
            layer.closeAll();
            layer.msg("开始演习...");
            _this.xfylAmination(build, select_floor);
        }
    });
    setTimeout(function () {
        $("#select_build").focus();
        $("#select_build").click(function (event,obj) {
            console.log(obj);
            return false;
            event.stopPropagation();
        });
    }, 200);
}
//火
WTBS.prototype.showbuildfire1 = function (position) {
var smk = w3DShowObj.commonFunc.findObject("model1smoke_1");
    var fball =w3DShowObj.commonFunc.findObject("model1fireball_1");
    if (fball) {
        smk.position.x = position.x;
        smk.position.y = position.y;
        smk.position.z = position.z;
        fball.position.x = position.x;
        fball.position.y = position.y+80;
        fball.position.z = position.z;
        smk.visible = true;
        fball.visible = true;
    } else {
    var fires = [{ "show": true, "uuid": "", "name": "model1smoke_1", "objType": "Smoke", "positionRadius": 80, "sizeTween": [[0, 1], [32, 128]], "velocityBase": [0, 150, 0], "velocitySpread": [80, 50, 80], "accelerationBase": [0, -10, 0], "img": "smokeparticle.png", "colorBase": 1508096, "opacityTween": [[0.8, 2], [0.5, 0]], "particlesPerSecond": 1000, "particleDeathAge": 5, "emitterDeathAge": 10000, "x": position.x, "y": position.y, "z": position.z, "scale": { "x": 3, "y": 1, "z": 5 }, "rotation": { "x": 0, "y": 0, "z": 0 }, "angleBase": 0, "angleSpread": 720, "angleVelocityBase": 0, "angleVelocitySpread": 720, "showSortNub": 1584, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "model1fireball_1", "objType": "Fireball", "positionRadius": 2, "speedBase": 40, "speedSpread": 8, "sizeTween": [[0.7, 1.5], [100, 150]], "opacityTween": [[0.7, 1], [1, 0.5]], "colorBase": 16719360, "particlesPerSecond": 800, "particleDeathAge": 1.5, "emitterDeathAge": 10000, "x": position.x, "y": position.y + 80, "z": position.z, "scale": { "x": 3, "y": 1, "z": 5 }, "rotation": { "x": 0, "y": 0, "z": 0 }, "img": "smokeparticle.png", "showSortNub": 1583, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }];
    w3DShowObj.commonFunc.loadModelsByJsons(fires, {x:0,y:0,z:0});
    }

}
WTBS.prototype.showXFYXAmination = false;
WTBS.prototype.animationParam = {};
WTBS.prototype.xfylAmination = function (buildNub, floornub) {
    var _this = this;
    _this.fireBuildNub = buildNub;
    this.showXFYXAmination = true;
    //起火
    var fireBuilld = w3DShowObj.commonFunc.findObject("model1build3_" + buildNub);
    var firepx = fireBuilld.position.x;
    var firepy = 52.35 * floornub - 110;
    var firepz = fireBuilld.position.z;
    this.showbuildfire1({ x: firepx, y: firepy, z: firepz });
    setTimeout(function () {
        //推进摄像头
        _this.closeCameraToObj("model1smoke_1", function () {
            setTimeout(function () {
                //切换摄像机角度
                w3DShowObj.commonFunc.changeCameraPosition( { x: 5835.58183804604, y: 7710.995531709141, z: 2846.4241385728137 }, { x: -375.8524784787147, y: 342.05706117206597, z: 178.68548028235932 }, 1000, function () {
                    //两秒后转向消防局
                    setTimeout(function () {
                        w3DShowObj.commonFunc.changeCameraPosition( { x: 4001.25435551022, y: 1566.042612976526, z: -2504.792592069797 }, { x: 3957.7646687979313, y: 223.709476832619, z: -4054.3052522933913 }, 1000, function () {
                            //两秒后显示监控室
                            setTimeout(function () {
                                _this.showXFBuilding();
                            //5秒后继续
                                setTimeout(function () {
                                    _this.doAnimationAfterShowXFBuilding();
                                }, 5000);
                            }, 100);
                        });
                    }, 100);
                });
            }, 2000);
        });
    }, 2000);
}
//5秒后继续
WTBS.prototype.doAnimationAfterShowXFBuilding = function () {
    var _this = this;
    w3DShowObj.commonFunc.changeCameraPosition({ x: -622.3323457533243, y: 3053.6905115505274, z: -989.1041533374627 }, { x: 2151.561157560692, y: 3053.228407750961, z: -992.5893224316319 }, 1000, function () {
        //此处显示内容
        layer.msg("紧急火警！");
        setTimeout(function () {
            /*
            *   _this.animationParam.build = build;
            _this.animationParam.select_floor = select_floor;
            _this.animationParam.select_fireType = select_fireType;
            _this.animationParam.select_fireSize = select_fireSize;
            _this.animationParam.select_V = select_V;
            */
            layer.msg("林海雪原小区" + _this.animationParam.build + "号楼," + _this.animationParam.select_floor + "楼发生" + _this.animationParam.select_fireTypeStr+"火警，紧急出警！");
            setTimeout(function () {
                var parkModes = _this.getParkModels();
                var jksmodels = _this.getMonitoringRoomModels();
                _this.vModels(jksmodels, function () {
                    w3DShowObj.commonFunc.changeCameraPosition( { x: 3752.934307274166, y: 881.6086014022482, z: -3160.233871730027 }, { x: 3808.6320544878613, y: 426.8928876990193, z: -3992.478655833047 }, 10, function () {
                        _this.hideModels(jksmodels, function () {
                            //显示园区
                            _this.eModels(parkModes, function () {

                                //切换视角
                                w3DShowObj.commonFunc.changeCameraPosition({ x: 4221.393684930859, y: 8234.528743805164, z: -5349.244775971515 }, { x: 1526.3954588977656, y: 536.4464964435064, z: -1485.6791592731984 }, 1000, function () {
                                    //画路线
                                    var path = _this.roadPathData.publicPath.concat(_this.roadPathData["buildPath_" + _this.fireBuildNub]);
                                    _this.addLine(path);
                                    setTimeout(function () {
                                        _this.lineobj.position.y -= 50;
                                        //切换角度
                                        w3DShowObj.commonFunc.changeCameraPosition({ x: 3867.8066756852063, y: 310.5273809443584, z: -3901.7067131720823 }, { x: 4165.602024181351, y: 234.46056432909302, z: -3901.8248733036608 }, 1000, function () {
                                            var p1 = w3DShowObj.commonFunc.findObject("model1xfy2_8");
                                            var p2 = w3DShowObj.commonFunc.findObject("model1xfy2_9");
                                            var car = w3DShowObj.commonFunc.findObject("model1car_xfc_4");
                                            p1.oldPosition = { x: p1.position.x, y: p1.position.y, z: p1.position.z };
                                            p1.oldRotation = { x: p1.rotation.x, y: p1.rotation.y, z: p1.rotation.z };
                                            p2.oldPosition = { x: p2.position.x, y: p2.position.y, z: p2.position.z };
                                            p2.oldRotation = { x: p2.rotation.x, y: p2.rotation.y, z: p2.rotation.z };
                                            car.oldPosition = { x: car.position.x, y: car.position.y, z: car.position.z };
                                            car.oldRotation = { x: car.rotation.x, y: car.rotation.y, z: car.rotation.z };
                                            _this.MovePerson(p1, car.position, 3000, "run", function () { p1.visible = false; });
                                            setTimeout(function () {
                                                _this.MovePerson(p2, car.position, 3000, "run", function () {
                                                    p2.visible = false;
                                                    w3DShowObj.commonFunc.changeCameraPosition({ x: 4216.770891759393, y: 102.86643744339146, z: -3789.1276193286826 }, { x: 4048.41618755251, y: 84.0944641453113, z: -3587.2683941811956 }, 500, function () {
                                                        _this.moveDoors();
                                                    });

                                                });
                                            }, 1000);
                                        });
                                    }, 3000);
                                });

                            });
                        });
                    });
                });
            }, 4000);
        }, 2000);
    });
}
//移动门
WTBS.prototype.moveDoors = function () {
    var _this = this;


    var leftDoor = w3DShowObj.commonFunc.findObject("model1xf_wall_door_left");
   var rightDoor = w3DShowObj.commonFunc.findObject("model1xf_wall_door_right");
   new TWEEN.Tween(leftDoor.position).to({
       x: 3325.934, y: 83.774, z: -3439.526
   }, 1000).onComplete(function () {
       }).start();
   new TWEEN.Tween(rightDoor.position).to({
       x: 4006.172, y: 83.774, z: -2968.208
   }, 1000).onComplete(function () {
       _this.moveCars();
   }).start();
}
WTBS.prototype.fireBuildNub = 1;
//移动车
WTBS.prototype.moveCars = function () {
    var _this = this;
    var car = w3DShowObj.commonFunc.findObject("model1car_xfc_4");
    var pathRoad = this.roadPathData.publicPath;
    var path = _this.roadPathData.publicPath.concat(_this.roadPathData["buildPath_" + _this.fireBuildNub]);
    console.log(path);
    var newpath = [];
    $.each(path, function (_index,_obj) {
        if (_index == 0) {
            newpath.push({
                start: {
                    x: car.position.x,
                    y: car.position.y,
                    z: car.position.z
                },
                end: {
                    x: _obj.x,
                    y: car.position.y,
                    z: _obj.z
                }
            });
        } else {
            newpath.push({
                start: {
                    x: path[_index-1].x,
                    y: path[_index - 1].y,
                    z: path[_index - 1].z
                },
                end: {
                    x: _obj.x,
                    y: car.position.y,
                    z: _obj.z
                }
            });
        }
    });
    _this.moveCar(car, newpath, 1000, function () {
        _this.removeLine();
        _this.MovePersonFromCar();
    });

}
//移动汽车
WTBS.prototype.moveCar = function (carObj,pointpath,moveTime, callBack) {
    var _this = this;



    function move(index) {
        carObj.lookAt(pointpath[index].end);
        var unittime = Math.sqrt((pointpath[index].end.x - carObj.position.x) * (pointpath[index].end.x - carObj.position.x) + (pointpath[index].end.z - carObj.position.z) * (pointpath[index].end.z - carObj.position.z)) * 2 / _this.animationParam.select_V;

        var _startx = carObj.position.x;
        new TWEEN.Tween(carObj.position).to({
            x: pointpath[index].end.x ,
            z: pointpath[index].end.z
        }, (unittime)).onUpdate(function () {
            var _x = this.x +343;
            var _z = this.z- 170;
            w3DShowObj.camera.position.x = _x;
            w3DShowObj.camera.position.y = 1355;
            w3DShowObj.camera.position.z = _z;
            w3DShowObj.controls.target.x = carObj.position.x;
            w3DShowObj.controls.target.y = carObj.position.y ;
            w3DShowObj.controls.target.z = carObj.position.z;

        }).onComplete(function () {
            if (index < pointpath.length - 1) {
                console.log(index);
                move(index + 1);
            } else {
                if (callBack)
                    callBack(carObj);
            }
        }).start();

    }
    move(0);
}
//人从车上下来
WTBS.prototype.MovePersonFromCar = function () {
    var _this = this;
    var p1 = w3DShowObj.commonFunc.findObject("model1xfy2_8");
    var p2 = w3DShowObj.commonFunc.findObject("model1xfy2_9");
    var car = w3DShowObj.commonFunc.findObject("model1car_xfc_4");
    p1.position.x = car.position.x;
    p1.position.z = car.position.z;
    p2.position.x = car.position.x;
    p2.position.z = car.position.z;
    var pathobj = _this.roadPathData["buildPathPeoples_" + _this.fireBuildNub];
    p1.visible = true;
    p2.visible = true;
    p1.renderOrder = 1;
    p2.renderOrder = 1;
    var fball = w3DShowObj.commonFunc.findObject("model1fireball_1");
    _this.addXfyShebei(p1);
    _this.addXfyShebei(p2);
    //调整摄像机位置
    w3DShowObj.commonFunc.changeCameraPosition(_this.roadPathData["buildCameraPosition_" + _this.fireBuildNub][0], _this.roadPathData["buildCameraPosition_" + _this.fireBuildNub][1], 1000, function () {

        _this.MovePerson(p1, pathobj[0], 3000 * 2  / _this.animationParam.select_V, "run", function () {
            p1.lookAt(car.position);
            p1.rotation.y += Math.PI;
            _this.changeShebeiPR(p1);
        });
        setTimeout(function () {
            _this.MovePerson(p2, pathobj[1], 3000 * 2  / _this.animationParam.select_V, "run", function () {
                p2.lookAt(car.position);
                p2.rotation.y += Math.PI;
                _this.changeShebeiPR(p2);
        setTimeout(function () {
                    _this.psAnimation();
                }, 500);
            });
        }, 500);
    });
}
//运动的人
WTBS.prototype.MovePerson = function (person, toPosition, timeLong, action, callBackFunc) {

    var _this = this;
    person.lookAt({ x: toPosition.x, y: person.position.y, z: toPosition.z });
    person.rotation.y += Math.PI;
    _this.changeShebeiPR(person);
   if (action == "run") {
        person.animationActions[0].play();
    } else {
        person.animationActions[1].play();
    }
   var tt = 0;
   var _forePosition = { x: person.position.x, y: person.position.y, z: person.position.z};
   new TWEEN.Tween(_forePosition).to({
        x: toPosition.x,
        z: toPosition.z
   }, (timeLong)).onUpdate(function (time,pobj) {
       console.log(_forePosition);
       //person.position.x = person.position.x + tt * (_forePosition.x - person.position.x);
       //person.position.z = person.position.z + tt * (_forePosition.z- person.position.z);
        _this.changeShebeiPR(person);
        person.position.x = _forePosition.x;
       person.position.z = _forePosition.z;
        _this.changeShebeiPR(person);
       }).onComplete(function () {

        _this.changeShebeiPR(person);
        if (action == "run") {
                person.animationActions[0].stop();
            } else {
                person.animationActions[1].stop();
            }
        if (callBackFunc) {
            callBackFunc();
        }
    }).start();
}
//喷水
WTBS.prototype.psAnimation = function () {
    var _this = this;
    var car = w3DShowObj.commonFunc.findObject("model1car_xfc_4");
        var fball = w3DShowObj.commonFunc.findObject("model1fireball_1");
        var psModels = [{ "show": true, "uuid": "", "name": "model1ps_1", "objType": "Startunnel", "sizeBase": 10, "sizeSpread": 10, "velocityBase": [fball.position.x - car.position.x, fball.position.y - car.position.y + 100, fball.position.z - car.position.z], "velocitySpread": [20, 20, 20], "angleBase": 0, "angleSpread": 180, "angleVelocityBase": 5, "angleVelocitySpread": 0, "img": "spikey.png", "colorBase": 16774553, "opacityBase": 1, "particlesPerSecond": 1000, "particleDeathAge": 4, "emitterDeathAge": 10000, "x": car.position.x, "y": car.position.y + 50, "z": car.position.z, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": { "x": 0, "y": 0, "z": 0 }, "positionSpread": [5, 5, 5], "showSortNub": 1580, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "model1ps_2", "objType": "Startunnel", "sizeBase": 10, "sizeSpread": 10, "velocityBase": [fball.position.x - car.position.x + 10, fball.position.y - car.position.y + 100, fball.position.z - car.position.z + 20], "velocitySpread": [20, 20, 20], "angleBase": 0, "angleSpread": 180, "angleVelocityBase": 5, "angleVelocitySpread": 0, "img": "spikey.png", "colorBase": 16774553, "opacityBase": 1, "particlesPerSecond": 1000, "particleDeathAge": 4, "emitterDeathAge": 10000, "x": car.position.x + 10, "y": car.position.y + 50, "z": car.position.z+20, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": { "x": 0, "y": 0, "z": 0 }, "positionSpread": [5, 5, 5], "showSortNub": 1580, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }];
        w3DShowObj.commonFunc.loadModelsByJsons(psModels, { x: 0, y: 0, z: 0 });
        //5秒后继续
        setTimeout(function () {
            _this.jxFire();
        }, 3000 * 2  / _this.animationParam.select_V);
}
//减小火势
WTBS.prototype.jxFire = function () {
    var _this = this;
    var smk = w3DShowObj.commonFunc.findObject("model1smoke_1");
    var fball = w3DShowObj.commonFunc.findObject("model1fireball_1");
    var model1ps_1 = w3DShowObj.commonFunc.findObject("model1ps_1");
    var model1ps_2 = w3DShowObj.commonFunc.findObject("model1ps_2");
    smk.oldScale = {
        x: smk.scale.x,
        y: smk.scale.y,
        z: smk.scale.z,
    };
    fball.oldScale = {
        x: fball.scale.x,
        y: fball.scale.y,
        z: fball.scale.z,
    };
    new TWEEN.Tween(fball.scale).to({
        x:0.5,
        y:0.5,
        z: 0.5
    }, (2000 * 2  / _this.animationParam.select_V)).onUpdate(function () {
        smk.scale.x = fball.scale.x;
        smk.scale.y= fball.scale.y;
        smk.scale.z= fball.scale.z;
        }).onComplete(function () {
            setTimeout(function () {
                _this.showBuilding3(null, function () {
                    smk.visible = false;
                    fball.visible = false;
                    model1ps_1.visible = false;
                    model1ps_2.visible = false;
                    w3DShowObj.destoryObjByName("model1fireball_1");
                    w3DShowObj.destoryObjByName("model1smoke_1");
                    w3DShowObj.destoryObjByName("model1ps_1");
                    w3DShowObj.destoryObjByName("model1ps_2");
                    //smk.scale.x = smk.oldScale.x;
                    //smk.scale.y = smk.oldScale.y;
                    //smk.scale.z = smk.oldScale.z;

                    //fball.scale.x = fball.oldScale.x;
                    //fball.scale.y = fball.oldScale.y;
                    //fball.scale.z = fball.oldScale.z;
                    setTimeout(function () {
                    getWTBSInstance().backToParkModels(function () {
                        //调整摄像机位置
                        w3DShowObj.commonFunc.changeCameraPosition(_this.roadPathData["buildCameraPosition_" + _this.fireBuildNub][0], _this.roadPathData["buildCameraPosition_" + _this.fireBuildNub][1], 1000 * 2  / _this.animationParam.select_V, function () {
                            var fireBuilld = w3DShowObj.commonFunc.findObject("model1build3_" + _this.animationParam.build);
                            var p1 = w3DShowObj.commonFunc.findObject("model1xfy2_8");
                            var p2 = w3DShowObj.commonFunc.findObject("model1xfy2_9");
                        var pathobj = _this.roadPathData["buildPathPeoples_" + _this.fireBuildNub];
                        _this.MovePerson(p1, pathobj[2], 2000 * 2  / _this.animationParam.select_V, "run", function () {
                                p1.rotation.y += Math.PI;
                                _this.changeShebeiPR(p1);
                                _this.MovePerson(p1, pathobj[3], 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                    p1.rotation.y += Math.PI;
                                    _this.changeShebeiPR(p1);
                                    if (pathobj[4]) {
                                        _this.MovePerson(p1, pathobj[4], 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                            p1.rotation.y += Math.PI;
                                            _this.changeShebeiPR(p1);
                                            _this.MovePerson(p1, fireBuilld.position, 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                                p1.rotation.y += Math.PI;
                                                _this.changeShebeiPR(p1);
                                            });
                                        });
                                    } else {
                                        _this.MovePerson(p1, fireBuilld.position, 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                        p1.rotation.y += Math.PI;
                                        _this.changeShebeiPR(p1);
                                    });
                                    }
                                });

                            });
                            setTimeout(function () {
                                _this.MovePerson(p2, pathobj[2], 2000 * 2  / _this.animationParam.select_V, "run", function () {
                                    p2.rotation.y += Math.PI;
                                    _this.changeShebeiPR(p2);

                                    _this.MovePerson(p2, pathobj[3], 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                        p2.rotation.y += Math.PI;
                                        _this.changeShebeiPR(p2);
                                        if (pathobj[4]) {
                                            _this.MovePerson(p2, pathobj[4], 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                                p2.rotation.y += Math.PI;
                                                _this.changeShebeiPR(p2);
                                                _this.MovePerson(p2, fireBuilld.position, 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                                    p2.rotation.y += Math.PI;
                                                    _this.changeShebeiPR(p2);

                                                    setTimeout(function () {
                                                        _this.showBuildFloor(null, function () {
                                                            _this.roomfire();
                                                        });
                                                    }, 500 * 2 / _this.animationParam.select_V);
                                                });
                                            });
                                        } else {
                                            _this.MovePerson(p2, fireBuilld.position, 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                                p2.rotation.y += Math.PI;
                                                _this.changeShebeiPR(p2);
                                                setTimeout(function () {
                                                    _this.showBuildFloor(null, function () {
                                                        _this.roomfire();
                                                    });
                                                }, 500 * 2 / _this.animationParam.select_V);
                                            });
                                        }
                                    });

                                });
                            }, 500 * 2  / _this.animationParam.select_V);
                        });
                        });
                    }, 2000 * 2 / _this.animationParam.select_V);
                },true);
            }, 2000 * 2  / _this.animationParam.select_V);
        }).start();

}
//内部灭火
WTBS.prototype.roomfire = function () {
    var _this = this;
    var roomfires = [{ "show": true, "uuid": "", "name": "m4_smoke", "objType": "Smoke", "positionRadius": 2, "sizeTween": [[0, 1], [32, 128]], "velocityBase": [0, 150, 0], "velocitySpread": [80, 50, 80], "accelerationBase": [0, -10, 0], "img": "smokeparticle.png", "colorBase": 16777215, "opacityTween": [[0.8, 2], [0.5, 0]], "particlesPerSecond": 200, "particleDeathAge": 2, "emitterDeathAge": 10000, "x": 266.189, "y": 60.73, "z": 2394.563, "scale": { "x": 2, "y": 1, "z": 2 }, "rotation": { "x": 0, "y": 0, "z": 0 }, "angleBase": 0, "angleSpread": 720, "angleVelocityBase": 0, "angleVelocitySpread": 720, "showSortNub": 601, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_fire", "objType": "Candle", "positionRadius": 2, "sizeTween": [[0, 0.3, 1.2], [20, 150, 1]], "velocityBase": [0, 100, 0], "velocitySpread": [20, 0, 20], "img": "smokeparticle.png", "opacityTween": [[0.9, 1.5], [1, 0]], "colorBase": 16719616, "particlesPerSecond": 60, "particleDeathAge": 1.5, "emitterDeathAge": 10000, "x": 289.047, "y": 7.754, "z": 2398.477, "scale": { "x": 10, "y": 1, "z": 10 }, "rotation": { "x": 0, "y": 0, "z": 0 }, "showSortNub": 600, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }];
    _this.addnames = [];
    if (_this.animationParam.select_fireType ==2) {
        _this.addnames = ["m4_mqgd","m4_markFire"];
        roomfires=roomfires.concat([{ "show": true, "uuid": "", "name": "m4_mqgd", "objType": "tube", "points": [{ "x": 0, "y": 0, "z": 0 }, { "x": 10, "y": 0, "z": 0 }, { "x": 200, "y": 0, "z": -10 }, { "x": 200, "y": null, "z": 30 }], "position": { "x": 55.805, "y": 18.706, "z": 2332.504 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 12772607, "side": 2, "opacity": 1 }, "segments": 64, "radialSegments": 8, "closed": false, "radius": 2, "showSortNub": 606, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "name": "m4_markFire", "objType": "makeTextSprite", "textColor": { "r": 255, "g": 0, "b": 0, "a": 1 }, "message": "煤气泄漏", "fontsize": 200, "canvasWidth": 1000, "canvasHeight": 300, "position": { "x": 123.121, "y": 32.428, "z": 2344.31 }, "showSortNub": 626, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }]);
    } else if (_this.animationParam.select_fireType == 1){
        _this.addnames = ["m4_markFire", "m4_dlFire_1", "m4_dlFire_2", "m4_dlFire"];
        roomfires = roomfires.concat([{ "name": "m4_markFire", "objType": "makeTextSprite", "textColor": { "r": 255, "g": 0, "b": 0, "a": 1 }, "message": "电力火灾", "fontsize": 200, "canvasWidth": 1000, "canvasHeight": 300, "position": { "x": 123.121, "y": 32.428, "z": 2344.31 }, "showSortNub": 626, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_dlFire_1", "objType": "tube", "points": [{ "x": 0, "y": 0, "z": 0 }, { "x": 10, "y": 0, "z": 0 }, { "x": 120, "y": -30, "z": -10 }, { "x": 145, "y": -55, "z": 35 }], "position": { "x": 49.031, "y": 101.45, "z": 2349.877 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 3649469, "side": 2, "opacity": 1 }, "segments": 64, "radialSegments": 8, "closed": false, "radius": 1, "showSortNub": 606, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_dlFire_2", "objType": "tube", "points": [{ "x": 0, "y": 0, "z": 0 }, { "x": 10, "y": 0, "z": 0 }, { "x": 120, "y": -30, "z": -10 }, { "x": 135, "y": -55, "z": 35 }], "position": { "x": 49.031, "y": 101.45, "z": 2349.877 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 12411179, "side": 2, "opacity": 1 }, "segments": 64, "radialSegments": 8, "closed": false, "radius": 1, "showSortNub": 606, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_dlFire", "objType": "tube", "points": [{ "x": 0, "y": 0, "z": 0 }, { "x": 10, "y": 0, "z": 0 }, { "x": 120, "y": -30, "z": -10 }, { "x": 140, "y": -50, "z": 30 }], "position": { "x": 49.031, "y": 101.45, "z": 2349.877 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 1382684, "side": 2, "opacity": 1 }, "segments": 64, "radialSegments": 8, "closed": false, "radius": 2, "showSortNub": 606, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }]);
    } else if (_this.animationParam.select_fireType == 3) {
        _this.addnames = ["m4_markFire", "m4_fireylw"];
        roomfires = roomfires.concat([{ "name": "m4_markFire", "objType": "makeTextSprite", "textColor": { "r": 255, "g": 0, "b": 0, "a": 1 }, "message": "固体易燃物", "fontsize": 200, "canvasWidth": 1000, "canvasHeight": 300, "position": { "x": 123.121, "y": 32.428, "z": 2344.31 }, "showSortNub": 626, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "m4_fireylw", "objType": "cube2", "length": 30, "width": 30, "height": 30, "x": 265.974, "y": 24.061, "z": 2444.899, "style": { "skinColor": 16777215, "skin": { "skin_up": { "skinColor": 16741450, "side": 1, "opacity": 1 }, "skin_down": { "skinColor": 16757854, "side": 1, "opacity": 1 }, "skin_fore": { "skinColor": 16745037, "side": 1, "opacity": 1 }, "skin_behind": { "skinColor": 16745037, "side": 1, "opacity": 1 }, "skin_left": { "skinColor": 16757854, "side": 1, "opacity": 1 }, "skin_right": { "skinColor": 16757854, "side": 1, "opacity": 1 } } }, "showSortNub": 626, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "thick": null, "scale": { "x": 1, "y": 1, "z": 1 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }]);
    }


    var smk = w3DShowObj.commonFunc.findObject("m4_smoke");
    var fball = w3DShowObj.commonFunc.findObject("m4_fire");
    if (fball) {
        smk.visible = true;
        fball.visible = true;
    } else {
        w3DShowObj.commonFunc.loadModelsByJsons(roomfires, { x: 0, y: 0, z: 0 }, { x: 0, y: 0, z: 0 },true);
    }
    //移动摄像头
    setTimeout(function () {
        var hourse = w3DShowObj.commonFunc.findObject("m4_house_2");
        hourse.children[28].visible = false;
        hourse.children[30].visible = false;
        w3DShowObj.commonFunc.changeCameraPosition({ x: 1490.4858406089347, y: 809.5210489898475, z: 887.5572584428154 }, { x: 983.6185943448631, y: 103.74892211783629, z: 1390.9033551573477 }, 1000 * 2  / _this.animationParam.select_V, function () {
            var p1 = w3DShowObj.commonFunc.findObject("model1xfy2_8");
            var p2 = w3DShowObj.commonFunc.findObject("model1xfy2_9");
            p1.material.opacity = 1;
            p2.material.opacity = 1;
            p1.visible = true;
            p2.visible = true;
            p1.position.x = 1205.18;
            p1.position.y = 18.098 ;
            p1.position.z = 1077.435;
            p2.position.x = 1205.18;
            p2.position.y = 18.098;
            p2.position.z = 955.435;
            _this.addXfyShebei(p1);
            _this.addXfyShebei(p2);
            _this.MovePerson(p1, { x: 812.571, y: 18.098, z: 1463.143 }, 2000 * 2  / _this.animationParam.select_V, "run", function () {
                                    p1.rotation.y += Math.PI;
                                    _this.changeShebeiPR(p1);
                                    _this.MovePerson(p2, { x: 812.571, y: 18.098, z: 1463.143 }, 2000 * 2  / _this.animationParam.select_V, "run", function () {
                    p2.rotation.y += Math.PI;
                                    _this.changeShebeiPR(p2);
                                    w3DShowObj.commonFunc.changeCameraPosition({ x: 1538.944163580977, y: 1513.0672411139547, z: 2354.001214331798 }, { x: 617.8079964045636, y: 229.71941718943594, z: 2146.224539225422 }, 2000 * 2  / _this.animationParam.select_V, function () { });
                    //打开门一

                    _this.MovePerson(p2, { x: 593.801, y: 18.098, z: 2779.143 }, 5000 * 2 / _this.animationParam.select_V, "run", function () {

                        p2.rotation.y += Math.PI;
                        _this.changeShebeiPR(p2);
                                    _this.MovePerson(p2, { x: 147.801, y: 18.098, z: 2779.143 }, 3000 * 2  / _this.animationParam.select_V, "run", function () {

                                p2.rotation.y += Math.PI;
                                _this.changeShebeiPR(p2);
                        _this.MovePerson(p2, { x: - 35.801, y: 18.098, z: 2835.143 }, 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                    p2.rotation.y += Math.PI;
                                _this.changeShebeiPR(p2);
                                w3DShowObj.commonFunc.changeCameraPosition({ x: 180.12344356607497, y: 219.4641870178687, z: 2722.482289974749 }, { x: 198.0736517991623, y: 93.12566866374983, z: 2483.689636602677 }, 2000 * 2  / _this.animationParam.select_V, function () { });
                                _this.changeShebeiPR(p2);
                                _this.MovePerson(p2, { x: - 35.801, y: 18.098, z: 2634.143 }, 2000 * 2 / _this.animationParam.select_V, "run", function () {
                                        p2.rotation.y += Math.PI;
                                        _this.changeShebeiPR(p2);

                                        _this.MovePerson(p2, { x: 205.801, y: 18.098, z: 2534.143 }, 2000 * 2  / _this.animationParam.select_V, "run", function () {
                                            p2.rotation.y += Math.PI;
                                _this.changeShebeiPR(p2);
                                setTimeout(function () {
                                                p2.rotation.y += Math.PI / 2;
                                _this.changeShebeiPR(p2);
                                _this.over();

                                            }, 10);

                                        });
                                    });
                                });

                        });

                    });

            });
                var door1 = w3DShowObj.commonFunc.findObject("m4_door_1");

                door1.visible = true;
                _this.MovePerson(p1, { x: 593.801, y: 18.098, z: 2779.143 }, 5000 * 2 / _this.animationParam.select_V, "run", function () {
                    p1.rotation.y += Math.PI;
                                    _this.changeShebeiPR(p1);
                                    openDoor1(door1, function () {
                    _this.MovePerson(p1, { x: 147.801, y: 18.098, z: 2779.143 }, 3000 * 2  / _this.animationParam.select_V, "run", function () {
                        var door2 = w3DShowObj.commonFunc.findObject("m4_door_2");
                door2.visible = true;
                                    _this.changeShebeiPR(p1);
                                    openDoor2(door2, function () {
                        p1.rotation.y += Math.PI;
                                    _this.changeShebeiPR(p1);
                                    _this.MovePerson(p1, { x: - 35.801, y: 18.098, z: 2835.143 }, 2000 * 2  / _this.animationParam.select_V, "run", function () {
                                p1.rotation.y += Math.PI;
                                _this.changeShebeiPR(p1);

                                _this.MovePerson(p1, { x: - 35.801, y: 18.098, z: 2634.143 }, 2000 * 2  / _this.animationParam.select_V, "run", function () {
                                    p1.rotation.y += Math.PI;
                                    _this.changeShebeiPR(p1);

                                    _this.MovePerson(p1, { x: 280.801, y: 18.098, z: 2534.143 }, 2000 * 2  / _this.animationParam.select_V, "run", function () {
                                        p1.rotation.y += Math.PI;
                                    _this.changeShebeiPR(p1);
                                    setTimeout(function () {
                                            p1.rotation.y += Math.PI/2;
                                    _this.changeShebeiPR(p1);
                                    }, 10);
                                    });
                                });

                        });
                    }, "open");
                    });
            }, "open");
                });

            });
        });


    }, 1000 * 2 / _this.animationParam.select_V);



}
//完成
WTBS.prototype.over = function () {
    var _this=this;
    var mhqjson = [{ "show": true, "uuid": "", "name": "m4_mhq_611", "objType": "GroupObj", "scale": { "x": 1, "y": 1, "z": 1 }, "position": { "x": 124.52233773683379, "y": -1.6143632860718924, "z": 2503.875818066437 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "childrens": [{ "name": "mhq_611OBJCREN0", "objType": "cylinder", "radiusTop": 5, "radiusBottom": 5, "height": 30, "segmentsX": 24, "segmentsY": 0, "openEnded": false, "position": { "x": 0, "y": 162.02, "z": 0 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 16776960, "skin": { "skin_up": { "skinColor": 14895433, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 2034186, "side": 1, "opacity": 1 }, "skin_side": { "skinColor": 16722217, "opacity": 1, "imgurl": "outside_lightmap.jpg" } } }, "showSortNub": 604, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "name": "mhq_611OBJCREN1", "objType": "cylinder", "radiusTop": 2, "radiusBottom": 5, "height": 5, "segmentsX": 24, "segmentsY": 0, "openEnded": false, "position": { "x": 0, "y": 179.503, "z": 0 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 16776960, "skin": { "skin_up": { "skinColor": 14895433, "side": 1, "opacity": 1, "imgurl": "rack_inside.jpg" }, "skin_down": { "skinColor": 16777215, "side": 1, "opacity": 1 }, "skin_side": { "skinColor": 16722217, "opacity": 1, "imgurl": "outside_lightmap.jpg" } } }, "showSortNub": 604, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "mhq_611OBJCREN2", "objType": "tube", "points": [{ "x": 0, "y": 0, "z": 0 }, { "x": 10, "y": 0, "z": 0 }, { "x": 30, "y": -11, "z": -10 }], "position": { "x": 0, "y": 182.971, "z": 0 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 2032901, "opacity": 1 }, "segments": 64, "radialSegments": 8, "closed": false, "radius": 1, "showSortNub": 606, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "mhq_611OBJCREN3", "objType": "tube", "points": [{ "x": 0, "y": 0, "z": 0 }, { "x": 10, "y": 0, "z": 0 }, { "x": 30, "y": -11, "z": -10 }], "position": { "x": 0, "y": 182.971, "z": 0 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 2039583, "opacity": 1 }, "segments": 64, "radialSegments": 8, "closed": false, "radius": 1, "showSortNub": 606, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "name": "mhq_611OBJCREN4", "objType": "cylinder", "radiusTop": 1, "radiusBottom": 1, "height": 10, "segmentsX": 3, "segmentsY": 0, "openEnded": false, "position": { "x": -4.797, "y": 183.476, "z": 0 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 1.5707963267948966 }], "style": { "skinColor": 16776960, "skin": { "skin_up": { "skinColor": 2039583, "side": 1, "opacity": 1 }, "skin_down": { "skinColor": 2039583, "side": 1, "opacity": 1 }, "skin_side": { "skinColor": 855309, "opacity": 1 } } }, "showSortNub": 607, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "name": "mhq_611OBJCREN5", "objType": "cylinder", "radiusTop": 1, "radiusBottom": 1, "height": 10, "segmentsX": 3, "segmentsY": 0, "openEnded": false, "position": { "x": -4.407, "y": 181.316, "z": 0 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": -0.0019198621771937625 }, { "direction": "y", "degree": 0.08082619765985741 }, { "direction": "z", "degree": 1.8407813087858995 }], "style": { "skinColor": 16776960, "skin": { "skin_up": { "skinColor": 2039583, "side": 1, "opacity": 1 }, "skin_down": { "skinColor": 2039583, "side": 1, "opacity": 1 }, "skin_side": { "skinColor": 855309, "opacity": 1 } } }, "showSortNub": 607, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }, { "show": true, "uuid": "", "name": "mhq_611OBJCREN6", "objType": "Startunnel", "sizeBase": 4, "sizeSpread": 2, "velocityBase": [200, -150, -50], "velocitySpread": [40, 40, 80], "angleBase": 0, "angleSpread": 720, "angleVelocityBase": 10, "angleVelocitySpread": 0, "img": "spikey.png", "colorBase": 16774553, "opacityBase": 1, "particlesPerSecond": 500, "particleDeathAge": 0.8, "emitterDeathAge": 10000, "x": 26.388, "y": 175.023, "z": -8.431, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": { "x": 0, "y": 0, "z": 0 }, "positionSpread": [1, 1, 1], "showSortNub": 700, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }], "showSortNub": 611, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" }];
    var mhq = w3DShowObj.commonFunc.findObject("m4_mhq_611");
    if (mhq) {
        mhq.visible = true;
    } else {
        w3DShowObj.commonFunc.loadModelsByJsons(mhqjson, { x: 0, y: 0, z: 0 }, { x: 0, y: 0, z: 0 },true);
    }
    var smk = w3DShowObj.commonFunc.findObject("m4_smoke");
    var fball = w3DShowObj.commonFunc.findObject("m4_fire");
    smk.oldScale = { x: smk.scale.x, y: smk.scale.y, z: smk.scale.z};
    fball.oldScale = { x: fball.scale.x, y: fball.scale.y, z: fball.scale.z};
    new TWEEN.Tween(fball.scale).to({
        x: 0.1,
        y: 0.1,
        z: 0.1
    }, (3000 * 2 / _this.animationParam.select_V)).onUpdate(function () {
        smk.scale.x = fball.scale.x;
        smk.scale.y = fball.scale.y;
        smk.scale.z = fball.scale.z;
        }).onComplete(function () {
            smk.visible = false;
            fball.visible = false;
            smk.scale.x = smk.oldScale.x;
            smk.scale.y = smk.oldScale.y;
            smk.scale.z = smk.oldScale.z;
            fball.scale.x = fball.oldScale.x;
            fball.scale.y = fball.oldScale.y;
            fball.scale.z = fball.oldScale.z;
            setTimeout(function () {
                var _mhq = w3DShowObj.commonFunc.findObject("m4_mhq_611");
                _mhq.visible = false;
                w3DShowObj.destoryObjByName("m4_mhq_611");
                w3DShowObj.destoryObjByName("m4_smoke");
                w3DShowObj.destoryObjByName("m4_fire");
                $.each(_this.addnames, function (_index, _obj) {
                    w3DShowObj.destoryObjByName(_obj);

                });
                _this.resetPosition();
                var door1 = w3DShowObj.commonFunc.findObject("m4_door_1");
                var door2 = w3DShowObj.commonFunc.findObject("m4_door_2");
                door1.visible = false;
                door2.visible = false;
                openDoor1(door1, function () { }, "close");
                openDoor2(door2, function () { }, "close");
            }, 1000 * 2 / _this.animationParam.select_V);
        }).start();
}
//复位
WTBS.prototype.resetPosition = function () {
    layer.msg("演习结束");
    var p1 = w3DShowObj.commonFunc.findObject("model1xfy2_8");
    var p2 = w3DShowObj.commonFunc.findObject("model1xfy2_9");
    var car = w3DShowObj.commonFunc.findObject("model1car_xfc_4");
    p1.position.x = p1.oldPosition.x;
    p1.position.y = p1.oldPosition.y;
    p1.position.z = p1.oldPosition.z;
    p2.position.x = p2.oldPosition.x;
    p2.position.y = p2.oldPosition.y;
    p2.position.z = p2.oldPosition.z;
    car.position.x = car.oldPosition.x;
    car.position.y = car.oldPosition.y;
    car.position.z = car.oldPosition.z;
    p1.rotation.x = p1.oldRotation.x;
    p1.rotation.y = p1.oldRotation.y;
    p1.rotation.z = p1.oldRotation.z;
    p2.rotation.x = p2.oldRotation.x;
    p2.rotation.y = p2.oldRotation.y;
    p2.rotation.z = p2.oldRotation.z;
    car.rotation.x = car.oldRotation.x;
    car.rotation.y = car.oldRotation.y;
    car.rotation.z = car.oldRotation.z;
    this.changeShebeiPR(p1);
    this.changeShebeiPR(p2);
    this.backToParkModels();
    this.showXFYXAmination = false;
}

//推进摄像头
WTBS.prototype.closeCameraToObj = function (name,callBackFunc) {

    var _obj = w3DShowObj.commonFunc.findObject(name);
    var mainCamera = w3dshowstation.camera;//主场景
    var objpositionx = _obj.position.x;
    var objpositiony = _obj.position.y;
    var objpositionz = _obj.position.z;
    if (typeof (_obj.parent) != 'undefined' && _obj.parent != null && typeof (_obj.parent.position) != 'undefined' && _obj.parent.position != null) {
        objpositionx += _obj.parent.position.x;
        objpositiony += _obj.parent.position.y;
        objpositionz += _obj.parent.position.z;
    }
    if (typeof (_obj.oldPosition) != 'undefined' && _obj.oldPosition != null) {
        objpositionx = _obj.oldPosition.x;
        objpositiony = _obj.oldPosition.y;
        objpositionz = _obj.oldPosition.z;
    }
    new TWEEN.Tween(w3dshowstation.controls.target).to({
        x: objpositionx, y: objpositiony, z: objpositionz
    }, 600).onComplete(function () {
        var x_distance = mainCamera.position.x - objpositionx;
        var y_distance = mainCamera.position.y - objpositiony;
        var z_distance = mainCamera.position.z - objpositionz;
        var lv = 1000 / Math.sqrt(x_distance * x_distance + y_distance * y_distance + z_distance * z_distance);
        var runtweenTime = 1000;
        if (lv > 0.6) {
            runtweenTime = 400;
        } else if (lv > 0.3) {
            runtweenTime = 1000;
        } else if (lv > 0.1) {
            runtweenTime = 1200;
        } else if (lv > 0.05) {
            runtweenTime = 1600;
        } else if (lv > 0.01) {
            runtweenTime = 2000;
        } else {
            runtweenTime = 2500;
        }
        if (x_distance * x_distance + y_distance * y_distance + z_distance * z_distance > 300 * 300 && lv < 0.9999) {
            new TWEEN.Tween(mainCamera.position).to({
                x: objpositionx + (mainCamera.position.x - objpositionx) * lv, y: objpositiony + (mainCamera.position.y - objpositiony) * lv, z: objpositionz + (mainCamera.position.z - objpositionz) * lv
            }, runtweenTime).onComplete(function () {
                if (callBackFunc) {
                    callBackFunc(_obj);
                }
            }).start();
        } else {
            if (callBackFunc) {
                callBackFunc(_obj);
            }
        }
    }).start();
}
/*
=======================================================================
===================通用部分===================
=======================================================================
*/
//消防员设备

WTBS.prototype.addXfyShebei = function (sfyobj) {
    var _this = this;
    if (sfyobj.shebei) {
        var shebeiobj = w3DShowObj.commonFunc.findObject(sfyobj.name+"_xfyshebei");
        shebeiobj.visible = true;
        w3DShowObj.commonFunc.changeObjsOpacity(shebeiobj.children, 0.05, 1, 10, function () {
            $.each(shebeiobj.children, function (_index, _obj) {
                _obj.visible = true;
            });
        });
        _this.changeShebeiPR(sfyobj);
    } else {
        var xfySheBeiJson = { "show": true, "uuid": "", "name": "xfyshebei", "objType": "GroupObj", "scale": { "x": 1, "y": 1, "z": 1 }, "position": { "x": 0, "y": 0, "z": 0 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "childrens": [{ "name": "xfyshebei_6OBJCREN0", "objType": "sphere", "radius": 7, "widthSegments": 12, "heightSegments": 12, "phiStart": 0, "phiLength": 6.283185307179586, "thetaStart": 0, "thetaLength": 1.5707963267948966, "position": { "x": 2.086, "y": 142.6, "z": 0 }, "scale": { "x": 1.4, "y": 1.5, "z": 1.2 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 14040864, "imgurl": "alternator-top.jpg", "side": 2, "opacity": 1 }, "showSortNub": 5, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": null, "BindMeteName": null }, { "name": "xfyshebei_6OBJCREN1", "objType": "cylinder", "radiusTop": 8, "radiusBottom": 0, "height": 1, "segmentsX": 12, "segmentsY": 0, "openEnded": false, "position": { "x": 8.163, "y": 142.306, "z": 0 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 16776960, "skin": { "skin_up": { "skinColor": 11354400, "side": 2, "opacity": 1, "imgurl": "alternator-top.jpg" }, "skin_down": { "skinColor": 9868950, "side": 0, "opacity": 1 }, "skin_side": { "skinColor": 9868950, "side": 0, "opacity": 1 } } }, "showSortNub": 6, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": null, "BindMeteName": null }, { "name": "xfyshebei_6OBJCREN2", "objType": "cylinder", "radiusTop": 6, "radiusBottom": 6, "height": 50, "segmentsX": 8, "segmentsY": 0, "openEnded": false, "position": { "x": -12.753, "y": 102.993, "z": -5.934 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": -1.5707963267948966 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 16776960, "skin": { "skin_up": { "skinColor": 12072223, "side": 1, "opacity": 1 }, "skin_down": { "skinColor": 12072223, "side": 1, "opacity": 1 }, "skin_side": { "skinColor": 12105912, "opacity": 1, "imgurl": "fire_extinguisher_side.jpg" } } }, "showSortNub": 15, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": null, "BindMeteName": null }, { "name": "xfyshebei_6OBJCREN3", "objType": "cylinder", "radiusTop": 6, "radiusBottom": 6, "height": 50, "segmentsX": 8, "segmentsY": 0, "openEnded": false, "position": { "x": -12.847, "y": 103.254, "z": 5.589 }, "scale": { "x": 1, "y": 1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 16776960, "skin": { "skin_up": { "skinColor": 12072223, "side": 1, "opacity": 1 }, "skin_down": { "skinColor": 12072223, "side": 1, "opacity": 1 }, "skin_side": { "skinColor": 12105912, "opacity": 1, "imgurl": "fire_extinguisher_side.jpg" } } }, "showSortNub": 15, "show": true, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": null, "BindMeteName": null }, { "show": true, "uuid": "", "name": "xfyshebei_6OBJCREN4", "objType": "Lathe", "position": { "x": 0, "y": 125.204, "z": 0 }, "points": [{ "x": 17, "y": 0, "z": 0 }, { "x": 15, "y": 8, "z": 0 }, { "x": 11, "y": 18, "z": 0 }], "style": { "skinColor": 14040864, "imgurl": "alternator-top.jpg", "repeatx": true, "width": 0.1, "repeaty": true, "height": 0.1, "side": 2, "opacity": 1 }, "segments": 6, "radialSegments": 6, "closed": true, "phiStart": 0, "phiLength": 6.283185307179586, "showSortNub": 14, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "radius": null, "scale": { "x": 0.7, "y": 1, "z": 0.7 }, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": null, "BindMeteName": null }], "showSortNub": 6, "customType1": "", "customType2": "", "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": null, "BindMeteName": null };

        var shebeiobj = w3DShowObj.createObjByJson(xfySheBeiJson);
        shebeiobj.visible = true;
        shebeiobj.name = sfyobj.name + "_xfyshebei";
        w3DShowObj.addObject(shebeiobj);
        sfyobj.shebei = shebeiobj;
        _this.changeShebeiPR(sfyobj);
    }
}
WTBS.prototype.changeShebeiPR = function (sfyobj) {
    if (sfyobj.shebei) {
        sfyobj.shebei.visible = true;
        sfyobj.shebei.scale.x = sfyobj.scale.x / 0.8;
        sfyobj.shebei.scale.y = sfyobj.scale.y / 0.8;
        sfyobj.shebei.scale.z = sfyobj.scale.z / 0.8;
        sfyobj.shebei.position.x = sfyobj.position.x ;
        sfyobj.shebei.position.y = sfyobj.position.y;
        sfyobj.shebei.position.z = sfyobj.position.z ;

        sfyobj.shebei.rotation.y = sfyobj.rotation.y -Math.PI / 2;
        sfyobj.shebei.rotation.x = sfyobj.rotation.x;
        sfyobj.shebei.rotation.z = sfyobj.rotation.z;
    }
}
WTBS.prototype.lineobj = null;
//画路线
WTBS.prototype.addLine = function (points) {
    this.removeLine();
    var lineName = "mAuto_drawLine" + Math.floor(Math.random() * 100000);
    var _linejsonobj = { "show": true, "uuid": "", "name": lineName, "objType": "tube", "points": points, "position": { "x": 0, "y":0, "z": 0 }, "scale": { "x":1, "y":1, "z": 1 }, "rotation": [{ "direction": "x", "degree": 0 }, { "direction": "y", "degree": 0 }, { "direction": "z", "degree": 0 }], "style": { "skinColor": 1048357, "side": 2, "opacity": 1 }, "segments": (points.length - 1), "radialSegments":6, "closed": false, "radius": 40, "showSortNub": 1, "animation": null, "dbclickEvents": null, "BindDevId": null, "BindDevName": null, "devInfo": null, "BindMeteId": "10001", "BindMeteName": "" };
    var _lineobj = w3DShowObj.createObjByJson(_linejsonobj);
    this.lineobj = _lineobj;
    w3DShowObj.commonFunc.flashObjs([_lineobj], lineName + "_animation", 0xffff00, 10, 400, 0);
    w3DShowObj.addObject(_lineobj);
}
WTBS.prototype.removeLine = function () {
    if (this.lineobj) {
        this.lineobj.visible = false;
        w3DShowObj.destoryObj(this.lineobj);
        this.lineobj = null;
    }
}
//加载模型
WTBS.prototype.loadData = function (models, modelname, position, rotation, afterLoadedShow) {
    var _this = this;
    if (!_this[modelname + "HasLoaded"]) {
        if (position == undefined) {
            position = { x: 0, y: 0, z: 0 };
        }
        if (rotation == undefined) {
            rotation = { x: 0, y: 0, z: 0 };
        }
        var show = false;
        if (afterLoadedShow) {
            show = true;
        }
        if (models) {
            w3DShowObj.commonFunc.loadModelsByJsons(models, position, rotation, show);
            _this[modelname + "HasLoaded"] = true;
        }
    }
}

//虚化场景
WTBS.prototype.vModels = function (models,sucFunc) {
    var _this = this;
    if (models) {
        w3DShowObj.commonFunc.changeObjsOpacity(models, 1, 0.05, 1000, function () {
            if (sucFunc) {
                sucFunc();
            }
        });
    }

}
//实体场景
WTBS.prototype.eModels = function (models, sucFunc) {
    var _this = this;
    if (models) {
        $.each(models, function (_index, _obj) {
                _obj.visible = true;
        });
        w3DShowObj.commonFunc.changeObjsOpacity(models, 0.05, 1, 1000, function () {
            if (sucFunc) {
                sucFunc();
            }
        });
    }
}
//隐藏模型
WTBS.prototype.hideModels = function (models, sucFunc) {
    setTimeout(function () {
        $.each(models, function (_index, _obj) {
                _obj.visible = false;
        });
        if (sucFunc) {
            sucFunc();
        }
    }, 50);
}
//显示模型
WTBS.prototype.showModels = function (models, sucFunc) {
    setTimeout(function () {
        $.each(models, function (_index, _obj) {
            _obj.visible = true;
        });
        if (sucFunc) {
            sucFunc();
        }
    }, 50);
}

var WTBS = null;
function getWTBSInstance() {
    if (WTBS == null) {
        WTBS = new WTBS();
        WTBS.init();
    }
    return WTBS;
}
//两秒后自动创建对象
setTimeout(function () { getWTBSInstance() }, 2000);

View Code

第一人称视角


THREE.FirstPersonControls = function ( object, domElement ) {

    this.object =
    this.domElement = ( domElement !== undefined ) ? domElement : document;

    this.enabled = true;

    this.movementSpeed = 1.0;
    this.lookSpeed = 0.005;

    this.lookVertical = true;
    this.autoForward = false;

    this.activeLook = true;

    this.heightSpeed = false;
    this.heightCoef = 1.0;
    this.heightMin =

    this.mouseX = 0;
    this.mouseY = 0;

    this.lat = 0;
    this.lon = 0;
    this.phi = 0;
    this.theta = 0;

    this.moveForward = false;
    this.moveBackward = false;
    this.moveLeft = false;
    this.moveRight = false;

    this.mouseDragOn = false;

    this.viewHalfX = 0;
    this.viewHalfY = 0;

    if ( this.domElement !== document ) {

        this.domElement.setAttribute( 'tabindex', - 1 );

    }

    //
 .innerHeight / 2;

        } else {

            this.viewHalfX = this.domElement.offsetWidth / 2;
            this.viewHalfY = this.domElement.offsetHeight / 2;

        }

    };

    this.onMouseDown = function ( event ) {

        if ( this.domElement !== document ) {

            this.domElement.focus();

        }

        event.preventDefault();
        event.stopPropagation();

        //if ( this.activeLook ) {

        //

        //}

        this.mouseDragOn = true;

    };

    this.onMouseUp = function ( event ) {

        event.preventDefault();
        event.stopPropagation();

        //if ( this.activeLook ) {

        //    switch ( event.button ) {

        //        case 0: this.moveForward = false; break;
        //        case 2: this.moveBackward = false; break;

        //    }

        //}

    this.onMouseMove = function ( event ) {
        if (this.mouseDragOn) {
            if (this.domElement === document) {

                this.mouseX = event.pageX - this.viewHalfX;
                this.mouseY = event.pageY - this.viewHalfY;

            } else {

                this.mouseX = event.pageX - this.domElement.offsetLeft - this.viewHalfX;
                this.mouseY = event.pageY - this.domElement.offsetTop - this.viewHalfY;

            }
        } else {
            this.mouseX = 0;
            this.mouseY =
    this.stopMoveInterval = null;
    this.onMouseWheel = function (event) {
        if ( this.activeLook ) {
            console.log(event);
            if (event.wheelDeltaY > 0) {
                var _this = this;
                _this.moveBackward = false;
                this.moveForward = true;
                if (_this.stopMoveInterval) {
                    clearTimeout(_this.stopMoveInterval);
                    _this.stopMoveInterval = null;
                }
                _this.stopMoveInterval = setTimeout(function () {
                    _this.moveForward = false;
                }, 300);
            } else {
                var _this = this;
                _this.moveForward = false;
                this.moveBackward = true;
                if (_this.stopMoveInterval) {
                    clearTimeout(_this.stopMoveInterval);
                    _this.stopMoveInterval = null;
                }
        }
    }
    this.onKeyDown = function ( event ) {

        //event.preventDefault();

        switch ( event.keyCode ) {

            case 38: /*up*/
            case 87: /*W*/ this.moveForward = true; break;

            case 37: /*left*/
            case 65: /*A*/ this.moveLeft = true; break;

            case 40: /*down*/
            case 83: /*S*/ this.moveBackward = true; break;

            case 39: /*right*/
            case 68: /*D*/ this.moveRight = true; break;

            case 82: /*R
    this.onKeyUp = function ( event ) {

        switch ( event.keyCode ) {

            case 38: /*up*/
            case 87: /*W*/ this.moveForward = false; break;

            case 37: /*left*/
            case 65: /*A*/ this.moveLeft = false; break;

            case 40: /*down*/
            case 83: /*S
            case 68: /*D*/ this.moveRight = false; break;

            case 82: /*R*/ this.moveUp = false; break;
            case 70: /*F*/ this.moveDown = false; break;

        }

    };

    this.update = function( delta ) {

        if ( this.enabled === false ) return;

        if ( this.heightSpeed ) {

            var y = THREE.Math.clamp( this.object.position.y, this.heightMin, this.heightMax );
            var heightDelta = y - this.heightMin;

            this.autoSpeedFactor = delta * ( heightDelta * this.heightCoef );

        } else {

            this.autoSpeedFactor = 0.0;

        }
  = delta * this.movementSpeed;

        if ( this.moveForward || ( this.autoForward && ! this.moveBackward ) ) this.object.translateZ( - ( actualMoveSpeed + this.autoSpeedFactor ) );
        if ( this.moveBackward ) this.object.translateZ( actualMoveSpeed );

        if ( this.moveLeft ) this.object.translateX( - actualMoveSpeed );
        if ( this.moveRight ) this.object.translateX( actualMoveSpeed );

        if ( this.moveUp ) this.object.translateY( actualMoveSpeed );
        if ( this.moveDown ) this.object.translateY( - actualMoveSpeed );

        var actualLookSpeed = delta * this.lookSpeed;

        if ( ! this.activeLook ) {

            actualLookSpeed = 0;

        } tical ) {

            verticalLookRatio = Math.PI / ( this.verticalMax - this.verticalMin );

        }

        this.lon += this.mouseX * actualLookSpeed;
        if ( this.lookVertical ) this.lat -= this.mouseY * actualLookSpeed * verticalLookRatio;

        this.lat = Math.max( - 85, Math.min( 85, this.lat ) );
        this.phi = THREE.Math.degToRad( 90 - this.lat );

        this.theta = THREE.Math.degToRad( this.lon );

        if ( this.constrainVertical ) {

            this.phi = THREE.Math.mapLinear( this.phi, 0, Math.PI, this.verticalMin, this.verticalMax );

        } object.position;

        targetPosition.x = position.x + 100 * Math.sin( this.phi ) * Math.cos( this.theta );
        targetPosition.y = position.y + 100 * Math.cos( this.phi );
        targetPosition.z = position.z + 100 * Math.sin( this.phi ) * Math.sin( this.theta );

        this.object.lookAt( targetPosition );

    };

    function contextmenu( event ) {

        event.preventDefault();

    }

    this.dispose = function() {

        this.domElement.removeEventListener( 'mousemove', _onMouseMove, false );
        this.domElement.removeEventListener( 'mouseup', _onMouseUp, false );

        window.removeEventListener('keydown', w3dShow_onKeyDown, false);
        window.removeEventListener('keyup', w3dShow_onKeyUp, false);

        if (parent && parent.window && parent.window.removeEventListener) {
            parent.window.removeEventListener('keydown', w3dShow_onKeyDown, false);
            parent.window.removeEventListener('keyup', w3dShow_onKeyUp, false);
        }
    };

    var _onMouseMove = bind( this, this.onMouseMove );
    var _onMouseDown = bind( t  bind(this, this.onKeyDown);
    var w3dShow_onKeyUp = bind(this, this.onKeyUp);
    var _onMouseWheel = bind(this, this.onMouseWheel);
    this.domElement.addEventListener( 'contextmenu', contextmenu, false );
    this.domElement.addEventListener( 'mousemove', _onMouseMove, false );
    this.domElement.addEventListener( 'mousedown', _onMouseDown, false );
    this.domElement.addEventListener( 'mouseup', _onMouseUp, false );
    this.domElement.addEventListener('wheel', _onMouseWheel, false);

    window.addEventListener('keydown', w3dShow_onKeyDown, false);
    window.addEventListener('keyup', w3dShow_onKeyUp, false);
    if (parent && parent.window && parent.window.addEventListener) {
        parent.window.addEventListener('keydown', w3dShow_onKeyDown, false);
        parent.window.addEventListener('keyup', w3dShow_onKeyUp, false);
    }
    function bind( scope, fn ) {

        return function () {

            fn.apply( scope, arguments );

        };

    }

    this.handleResize();

};

View Code

这一课先介绍到这里

后面我将继续讲解用webgl 建立 3D机房 3D园区 3D智慧小区 3D工程等等

技术交流 1203193731@qq.com

交流微信：

如果你有什么要交流的心得可邮件我

posted @ 2018-09-30 14:45 魂断蓝桥666 阅读(47242) 评论(23) 编辑收藏举报

刷新页面返回顶部

webGL 3D ThreeJS

使用webgl(three.js)搭建一个3D智慧园区、3D建筑，3D消防模拟，web版3D,bim管理系统——第四课

公告
