|NO.Z.00028|——————————|^^ 导出 ^^|——|Hadoop&PB级数仓.V12|——|PB数仓.v12|会员活跃度分析|Datax数据导出&hdfsreader => mysqlwriter|

一、Datax 数据导出

### --- DataX数据导出

~~~     官方配置地址：https://github.com/alibaba/DataX/blob/master/introduction.md)

二、DataX从Hive下导入表到mysql下

### --- 在mysql下建表，准备导出数据的数据库
~~~     ADS有4张表需要从数据仓库的ADS层导入MySQL，即：Hive => MySQL
~~~     次实验以ads.ads_member_active_count从hdfs导出到mysql为准，
~~~     其它表中的数据参考以上案例完成。

ads.ads_member_active_count
ads.ads_member_retention_count
ads.ads_member_retention_rate
ads.ads_new_member_cnt

### --- 建表语法：MySQL 建表

~~~     # 活跃会员数
create database dwads;
drop table if exists dwads.ads_member_active_count;
create table dwads.ads_member_active_count(
`dt` varchar(10) COMMENT '统计日期',
`day_count` int COMMENT '当日会员数量',
`week_count` int COMMENT '当周会员数量',
`month_count` int COMMENT '当月会员数量',
primary key (dt)
);

~~~     # 新增会员数

drop table if exists dwads.ads_new_member_cnt;
create table dwads.ads_new_member_cnt
(
`dt` varchar(10) COMMENT '统计日期',
`cnt` int,
primary key (dt)
);

~~~     # 会员留存数

drop table if exists dwads.ads_member_retention_count;
create table dwads.ads_member_retention_count
(
`dt` varchar(10) COMMENT '统计日期',
`add_date` varchar(10) comment '新增日期',
`retention_day` int comment '截止当前日期留存天数',
`retention_count` bigint comment '留存数',
primary key (dt)
) COMMENT '会员留存情况';

~~~     # 会员留存率

drop table if exists dwads.ads_member_retention_rate;
create table dwads.ads_member_retention_rate
(
`dt` varchar(10) COMMENT '统计日期',
`add_date` varchar(10) comment '新增日期',
`retention_day` int comment '截止当前日期留存天数',
`retention_count` bigint comment '留存数',
`new_mid_count` bigint comment '当日会员新增数',
`retention_ratio` decimal(10,2) comment '留存率',
primary key (dt)
) COMMENT '会员留存率';

三、创建json文件，进行数据导入：hdfsreader => mysqlwriter

~~~     创建json文件，进行数据导入：hdfsreader => mysqlwriter
~~~     导出活跃会员数(ads_member_active_count)

export_member_active_count.json

### --- 准备资源数据
~~~     # hive库中ads.ads_member_active_count在hdfs下的数据地址；

hive (default)> desc formatted ads.ads_member_active_count;
~~~输出参数
Location:               hdfs://hadoop01:9000/user/hive/warehouse/ads.db/ads_member_active_count

### --- 创建json文件

[root@hadoop02 ~]# vim /data/yanqidw/script/member_active/export_member_active_count.json
{
  "job": {
    "setting": {
      "speed": {
        "channel": 1
      }
    },
    "content": [
      {
        "reader": {
          "name": "hdfsreader",
          "parameter": {
            "path": "/user/hive/warehouse/ads.db/ads_member_active_count/dt=$do_date/*",
            "defaultFS": "hdfs://hadoop01:9000",
            "column": [
              {
                "type": "string",
                "value": "$do_date"
              },
              {
                "index": 0,
                "type": "string"
              },
              {
                "index": 1,
                "type": "string"
              },
              {
                "index": 2,
                "type": "string"
              }
            ],
            "fileType": "text",
            "encoding": "UTF-8",
            "fieldDelimiter": ","
          }
        },
        "writer": {
          "name": "mysqlwriter",
          "parameter": {
            "writeMode": "replace",
            "username": "hive",
            "password": "12345678",
            "column": [
              "dt",
              "day_count",
              "week_count",
              "month_count"
            ],
            "preSql": [
              ""
            ],
            "connection": [
              {
                "jdbcUrl": "jdbc:mysql://hadoop05:3306/dwads?useUnicode=true&characterEncoding=utf-8",
                "table": [
                  "ads_member_active_count"
                ]
              }
            ]
          }
        }
      }
    ]
  }
}

### --- 执行该json文件

[root@hadoop02 ~]# python $DATAX_HOME/bin/datax.py -p "-Ddo_date=2021-09-29" \
/data/yanqidw/script/member_active/export_member_active_count.json
~~~输出参数
2021-10-01 13:47:30.918 [job-0] INFO  JobContainer -
任务启动时刻                    : 2021-10-01 13:47:17
任务结束时刻                    : 2021-10-01 13:47:30
任务总计耗时                    :                 13s
任务平均流量                    :                2B/s
记录写入速度                    :              0rec/s
读出记录总数                    :                   1
读写失败总数                    :                   0

四、创建传输脚本文件

### --- 创建传输脚本文件
~~~     # 配置json文件的时间传输脚本：export_member_active_count.sh

[root@hadoop02 ~]# vim /data/yanqidw/script/member_active/export_member_active_count.sh
#!/bin/bash

JSON=/data/yanqidw/script/member_active/

source /etc/profile

if [ -n "$1" ] ;
then
    do_date=$1
else
    do_date=`date -d "-1 day" +%F`
fi

python $DATAX_HOME/bin/datax.py -p "-Ddo_date=$do_date" $JSON/export_member_active_count.json

~~~     # 执行该脚本

[root@hadoop02 ~]# chmod +x /data/yanqidw/script/member_active/export_member_active_count.sh
[root@hadoop02 ~]# /data/yanqidw/script/member_active/export_member_active_count.sh
~~~输出参数
2021-10-01 14:35:44.221 [job-0] INFO  JobContainer -
任务启动时刻                    : 2021-10-01 14:35:30
任务结束时刻                    : 2021-10-01 14:35:44
任务总计耗时                    :                 13s
任务平均流量                    :                2B/s
记录写入速度                    :              0rec/s
读出记录总数                    :                   1
读写失败总数                    :                   0

~~~     # 或者指定特定时间

[root@hadoop02 ~]# /data/yanqidw/script/member_active/export_member_active_count.sh 2021-09-29
~~~输出参数
2021-10-01 14:36:54.879 [job-0] INFO  JobContainer -
任务启动时刻                    : 2021-10-01 14:36:41
任务结束时刻                    : 2021-10-01 14:36:54
任务总计耗时                    :                 13s
任务平均流量                    :                2B/s
记录写入速度                    :              0rec/s
读出记录总数                    :                   1
读写失败总数                    :                   0

四、验证数据导出

### --- 验证mysql是否从hdfs下写入数据

mysql> select * from dwads.ads_member_active_count;
+------------+-----------+------------+-------------+
| dt         | day_count | week_count | month_count |
+------------+-----------+------------+-------------+
| 2021-09-29 |     11000 |      11000 |       11000 |
| 2021-09-30 |      9999 |      18999 |       18999 |
+------------+-----------+------------+-------------+

---



















---
