DevExpress 技巧

LabelControl

居中显示

labelControl1.AutoSizeMode = DevExpress.XtraEditors.LabelAutoSizeMode.None;
labelControl1.Dock = DockStyle.Fill;
// 垂直居中
labelControl1.Appearance.TextOptions.VAlignment = DevExpress.Utils.VertAlignment.Center;
// 水平居中
labelControl1.Appearance.TextOptions.HAlignment = DevExpress.Utils.HorzAlignment.Center;

Html标签

labelControl1.AllowHtmlString = true;
labelControl1.Appearance.TextOptions.WordWrap = DevExpress.Utils.WordWrap.Wrap;
labelControl1.Text = "<size=18>Size=18<br>" +
                     "<b>Bold</b> <i>Italic</i> <u>Underline</u><br>" +
                     "<size=10>Size=10<br>" +
                     "<color=255,0,0>Sample Text</color></size>" +
                     "<href=www.devexpress.com>Hyperlink</href>";

TextEdit

蒙版提示

textEdit1.Properties.AllowNullInput = DevExpress.Utils.DefaultBoolean.True;
textEdit1.Properties.NullText = "请输入数据：";

textEdit1.Properties.Appearance.TextOptions.HAlignment = DevExpress.Utils.HorzAlignment.Center;
textEdit1.Properties.Appearance.TextOptions.VAlignment = DevExpress.Utils.VertAlignment.Center;

输入限定

// 限定数字
textEdit1.Properties.Mask.MaskType = DevExpress.XtraEditors.Mask.MaskType.Numeric;
// 限定表达式
textEdit1.Properties.Mask.MaskType = DevExpress.XtraEditors.Mask.MaskType.RegEx;
textEdit1.Properties.Mask.EditMask = "[0-9]*";

MemoEdit

多行编辑

memoEdit1.Properties.ScrollBars = ScrollBars.Vertical;
memoEdit1.Properties.WordWrap = true;
memoEdit1.Properties.AllowMouseWheel = true;
memoEdit1.Properties.AcceptsReturn = true;
memoEdit1.Properties.AcceptsTab = false;

ListBoxControl

可选择的项目列表。

var listInfo = GetListInfo();
listBoxControl1.DataSource = listInfo;
listBoxControl1.DisplayMember = "PropertName1";
listBoxControl1.SelectedValueChanged += ListBoxControl1_SelectedValueChanged;

private void ListBoxControl1_SelectedValueChanged(object sender, EventArgs e) {
    var listBoxControl = sender as ListBoxControl;
    if (!listBoxControl.Focused) return;
    XtraMessageBox.Show(listBoxControl.SelectedValue.ToString());
}

绑定模式会使listInfo的变化反应到控件显示，且listBoxControl1.Items是没有数据的，但不影响SelectedValueChanged等操作。

若listInfo是可通知的对象集合（BindingList、ObservableCollection），listInfo.Add(item)会自动更新listBoxControl1的内容；
若是List集合，需要手动刷新控件：listBoxControl1.Refresh();
详情查看Winform 属性值绑定、转换、实时通知

CheckedListBoxControl

带选择框的 ListBoxControl。

public static void DataSourceBinding(this CheckedListBoxControl control, List<Source> dataSource)
{
    // true 多列显示 控件高度不变
    // false 默认单例显示 控件宽度不变，有垂直滚动条
    control.MultiColumn = true;
    // 多列显示时，列宽设置；默认宽为各项最长长度
    control.ColumnWidth = 80;
    // One,单选一项，再点可勾选
    // MultiSimple, 可选多项，统一勾选
    // MultiExtended, 类似 One， 可在选择框上任意勾选多项
    control.SelectionMode = SelectionMode.One;
    // true, 点击一项即可勾选
    control.CheckOnClick = true;
    // 绑定
    control.DataSource = dataSource;
    control.DisplayMember = "Value";
    control.ValueMember = "Key";
}

checkedListBoxControl1.DataSourceBinding(list);

foreach (Source item in checkedListBoxControl1.CheckedItems)
{
    // TODO
}

ComboBoxEdit

下拉列表。可绑定任意类型的项目集合，项目显示文本取决于类型的ToString()的内容。

var list= EnumExtends.GetEnumResource<EnumType>();
comboBoxEdit1.Properties.Items.AddRange(list);
// 文本不可编辑
comboBoxEdit1.Properties.TextEditStyle = TextEditStyles.DisableTextEditor;

private void comboBoxEdit1_SelectedIndexChanged(object sender, EventArgs e)
{
	if (sender is ComboBoxEdit cbe && cbe.SelectedItem is Source item)
	{
		labelControl1.Text = item.Key + " " + item.Value;
	}
}

LookUpEdit

下拉列表，可查找，轻量级表格。

var dic = EnumExtends.EnumToDic<EnumType>();
lookUpEdit1.DataSourceBinding(dic);
lookUpEdit1.Properties.SearchMode = DevExpress.XtraEditors.Controls.SearchMode.AutoFilter;
lookUpEdit1.Properties.TextEditStyle = DevExpress.XtraEditors.Controls.TextEditStyles.Standard;

public static void DataSourceBinding(this LookUpEdit lookUpEdit, Dictionary<int,string> dataSource)
{
	lookUpEdit.Properties.DataSource = dataSource;
	lookUpEdit.Properties.ShowHeader = false;
	lookUpEdit.Properties.ShowFooter = false;
	lookUpEdit.Properties.ValueMember = "Key";
	lookUpEdit.Properties.DisplayMember = "Value";
	lookUpEdit.Properties.NullText = "请选择";
	lookUpEdit.Properties.Columns.Add(new DevExpress.XtraEditors.Controls.LookUpColumnInfo("Value"));
	lookUpEdit.ItemIndex = -1;
        lookUpEdit.Properties.SearchMode = DevExpress.XtraEditors.Controls.SearchMode.OnlyInPopup;
        lookUpEdit.Properties.TextEditStyle = DevExpress.XtraEditors.Controls.TextEditStyles.DisableTextEditor;

	lookUpEdit.Properties.PopupSizeable = true;
	lookUpEdit.Properties.BestFitMode = DevExpress.XtraEditors.Controls.BestFitMode.BestFitResizePopup;
	lookUpEdit.Properties.BestFitWidth = 0;
	lookUpEdit.Properties.BestFit();
	lookUpEdit.Properties.PopupFormMinSize = new Size(10, 0);
	//lookUpEdit.Properties.UseDropDownRowsAsMaxCount = true;  v14.2
}

private void lookUpEdit1_EditValueChanged(object sender, EventArgs e)
{
	if (sender is LookUpEdit lue  && lue.GetSelectedDataRow() is KeyValuePair<int, string> pair)
	{
		labelControl1.Text = lue.EditValue + " " + pair.Value;
	}
}

GridLookUpEdit

可展示二维表单的LookUpEdit。

单选响应，可多项勾选。

var list = EnumExtends.GetEnumResourceEx<EnumType>();
DataSourceBinding(gridLookUpEdit1, _listLightSourceDarkField);
gridLookUpEdit1.Properties.NullText = "初始化显示";


private void DataSourceBinding(GridLookUpEdit gridLookUpEdit, List<SourceSelected> dataSource)
{
    // 数据绑定
    gridLookUpEdit.Properties.DataSource = dataSource;
    gridLookUpEdit.Properties.ValueMember = "Key";
    gridLookUpEdit.Properties.DisplayMember = "Value";
    gridLookUpEdit.Properties.NullText = "请选择";

    gridLookUpEdit.Properties.ShowFooter = false;
    gridLookUpEdit.Properties.View.OptionsBehavior.AutoPopulateColumns = false;
    // 添加列
    var column = new GridColumn() { FieldName = "Value" };
    column.VisibleIndex = 0;
    gridLookUpEdit.Properties.View.Columns.Add(column);
    column = new GridColumn() { FieldName = "IsSelected" };
    column.VisibleIndex = 1;
    column.OptionsColumn.AllowEdit = true;
    var ckb = new RepositoryItemCheckEdit();
    column.ColumnEdit = ckb;

    gridLookUpEdit.Properties.View.Columns.Add(column);
    gridLookUpEdit.Properties.View.OptionsView.ShowColumnHeaders = false;// 隐藏行首
    gridLookUpEdit.Properties.View.OptionsView.ShowIndicator = false;    // 隐藏索引
    // 不允许输入
    gridLookUpEdit.Properties.TextEditStyle = DevExpress.XtraEditors.Controls.TextEditStyles.DisableTextEditor;
    // 模糊查询
    //gridLookUpEdit.Properties.TextEditStyle = DevExpress.XtraEditors.Controls.TextEditStyles.Standard;
    //gridLookUpEdit.Properties.AutoComplete = false;
    //gridLookUpEdit.Properties.ImmediatePopup = true;
    //gridLookUpEdit.Properties.PopupFilterMode = PopupFilterMode.Contains;
    // 自由输入
    //gridLookUpEdit.ProcessNewValue -= GridLookUpEdit_ProcessNewValue;
    //gridLookUpEdit.ProcessNewValue += GridLookUpEdit_ProcessNewValue;

    // 自适应各列
    gridLookUpEdit.Properties.View.OptionsView.ColumnAutoWidth = true;
    gridLookUpEdit.Properties.View.BestFitColumns();
    gridLookUpEdit.Properties.BestFitMode = DevExpress.XtraEditors.Controls.BestFitMode.BestFit;
    // 弹框大小
    gridLookUpEdit.Properties.PopupSizeable = true;
    gridLookUpEdit.Properties.PopupFormMinSize = new Size(10, 10);
    gridLookUpEdit.Properties.PopupFormSize = new Size(100, 60);
}
private static void GridLookUpEdit_ProcessNewValue(object sender, DevExpress.XtraEditors.Controls.ProcessNewValueEventArgs e)
{
    if (!string.IsNullOrWhiteSpace(e.DisplayValue?.ToString()))
    {
        var edit = sender as GridLookUpEdit;
        var dt = edit.Properties.DataSource as DataTable;
        if (dt != null)
        {
            var dr = dt.NewRow();
            dr[edit.Properties.DisplayMember] = e.DisplayValue;
            dr[edit.Properties.ValueMember] = e.DisplayValue;
            dt.Rows.Add(dr);
        }

        var list = edit.Properties.DataSource as List<Source>;
        if (list != null)
        {
            list.Add(new SourceSelected() { Key = list.Count + 1, Value = e.DisplayValue?.ToString() });
        }
    }
    e.Handled = true;
}

// 勾选标识
private bool _bCheckChanged;
private void GridLookUpEdit1_QueryCloseUp(object sender, System.ComponentModel.CancelEventArgs e)
{
    e.Cancel = _bCheckChanged;  // 勾选时弹框不关闭
    var control = (GridLookUpEdit)sender;
    var list = gridLookUpEdit1View.DataSource as List<SourceSelected>;
}

private void GridLookUpEdit1View_MouseDown(object sender, MouseEventArgs e)
{
    // 左键勾选
    var view = (GridView)sender;
    var hint = view.CalcHitInfo(e.X, e.Y);
    if (view.RowCount == 0 || !hint.InRowCell || e.Button != MouseButtons.Left || e.Clicks != 1)
    {
        return;
    }
    _bCheckChanged = false;
    // 响应勾选列
    if (hint.Column.FieldName == "IsSelected")
    {
        _bCheckChanged = true;
        view.FocusedRowHandle = -1;
        var item = view.GetRow(hint.RowHandle) as SourceSelected;
        if (item != null)
        {
            view.SetRowCellValue(hint.RowHandle, "IsSelected", !item.IsSelected);
        }
    }
}

LayoutControl

布局控件，跟随窗体变化大小，创建并维护控件的一致布局。
当SizeConStraintsType=Custom，控件Size由MinSize、MaxSize决定；
当SizeConstraintsType=SupportHorzAlignment，由ControlAlignment进行布局，且控件属性AutoSizeInLayoutControl=true；

已布局的控件，在后台不可动态调整。

DataLayoutControl

可绑定源字段的LayoutControl。与BindingSource结合使用。

GridControl

gridControl1.DataSource = demoList;

基本设置

// 内嵌导航页
gridControl1.UseEmbeddedNavigator = true;
gridControl1.EmbeddedNavigator.Buttons.PrevPage.Visible = true;
gridControl1.EmbeddedNavigator.Buttons.Prev.Visible = true;
gridControl1.EmbeddedNavigator.Buttons.NextPage.Visible = true;
gridControl1.EmbeddedNavigator.Buttons.Next.Visible = true;
gridControl1.EmbeddedNavigator.Buttons.Append.Visible = false;
gridControl1.EmbeddedNavigator.Buttons.CancelEdit.Visible = false;
gridControl1.EmbeddedNavigator.Buttons.Edit.Visible = false;
gridControl1.EmbeddedNavigator.Buttons.EndEdit.Visible = false;
gridControl1.EmbeddedNavigator.Buttons.Remove.Visible = false;
gridControl1.EmbeddedNavigator.TextStringFormat = "{0} / {1}";

// 禁用合计
gridView1.OptionsView.ShowFooter = false;
// 禁用自带的搜索功能
gridView1.OptionsFind.AlwaysVisible = false;
// 指定列的合计类型
//gridView1.Columns["列名"].SummaryItem.SummaryType = DevExpress.Data.SummaryItemType.Sum;
// 合计显示格式
//gridView1.Columns["列名"].SummaryItem.DisplayFormat = "{0:f2}";
// 禁用列头右键菜单
gridView1.OptionsMenu.EnableColumnMenu = false;
// 自适应各列
gridView1.OptionsView.ColumnAutoWidth = true;
// 隐藏主面板
gridView1.OptionsView.ShowGroupPanel = false;
gridView1.GroupPanelText = "主面板文本";
// 奇偶行
gridView1.OptionsView.EnableAppearanceEvenRow = true;
//gridView1.Appearance.EvenRow.BackColor = System.Drawing.Color.Green;
gridView1.OptionsView.EnableAppearanceOddRow = true;
//gridView1.Appearance.OddRow.BackColor = System.Drawing.Color.Red;
//gridView1.Appearance.FocusedRow.BackColor = Color.Green;

// 行首列头设置
// 显示列头
gridView1.OptionsView.ShowColumnHeaders = true;
// 自动换行
gridView1.OptionsView.RowAutoHeight = true;
// 列头居中
gridView1.Appearance.HeaderPanel.TextOptions.HAlignment = DevExpress.Utils.HorzAlignment.Center;
// 数据列居中
gridView1.Appearance.Row.TextOptions.HAlignment = DevExpress.Utils.HorzAlignment.Center;
// 显示行首
gridView1.OptionsView.ShowIndicator = true;
// 行首宽
gridView1.IndicatorWidth = 40;
// 行首序号
gridView1.CustomDrawRowIndicator += GridView1_CustomDrawRowIndicator;

// 隐藏聚焦行
// 取消点击后虚线框
gridView1.FocusRectStyle = DrawFocusRectStyle.None;
// 禁用单元格选中
gridView1.OptionsSelection.EnableAppearanceFocusedCell = false;
// 禁用选中整行
gridView1.OptionsSelection.EnableAppearanceFocusedRow = false;

// 数据列表选择模式
// 允许多行选择
gridView1.OptionsSelection.MultiSelect = true;
// 选择方式，显示复选框
gridView1.OptionsSelection.MultiSelectMode = GridMultiSelectMode.CheckBoxRowSelect;
// 直接鼠标点击
gridView1.OptionsBehavior.EditorShowMode = DevExpress.Utils.EditorShowMode.MouseDown;
// 只读
gridView1.OptionsBehavior.ReadOnly = true;
// 不可编辑，可拷贝（ReadOnly=true）
gridView1.OptionsBehavior.Editable = false;

// 禁用列头过滤
gridView1.OptionsCustomization.AllowFilter = false;
// 禁用列头排序
gridView1.OptionsCustomization.AllowSort = false;
// 禁用列头移动
gridView1.OptionsCustomization.AllowColumnMoving = false;
// 允许改变列宽
gridView1.OptionsCustomization.AllowColumnResizing = true;
// 禁用标题列分组
gridView1.OptionsCustomization.AllowGroup = false;
// Footer是否显示过滤面板
gridView1.OptionsView.ShowFilterPanelMode = DevExpress.XtraGrid.Views.Base.ShowFilterPanelMode.Never;

// 只显示一层数据
gridView1.LevelTree = 1;
gridView1.ShowOnlyPredefinedDetails = true;  // false时，显示所有和绑定数据源相关的数据
// 截断的列头显示提示信息（Caption）
gridView1.OptionsHint.ShowColumnHeaderHints = true;

private void GridView1_CustomDrawRowIndicator(object sender, RowIndicatorCustomDrawEventArgs e)
{
    // 隐藏指示图标
    e.Info.ImageIndex = -1;
    if (e.Info.Kind == DevExpress.Utils.Drawing.IndicatorKind.Header)
    {
        e.Info.DisplayText = "行号";
    }
    e.Appearance.TextOptions.HAlignment = DevExpress.Utils.HorzAlignment.Center;
    if (e.Info.IsRowIndicator && e.RowHandle >= 0)
    {
        e.Info.DisplayText = (e.RowHandle + 1).ToString();
    }
}

获取数据

// 获取指定行的数据
var rowHandle = 0;
var entitiy = gridView1.GetFocusedRowCellValue(gridView1.Columns[0]) as DemoClassA;
entitiy =  gridView1.GetRow(rowHandle) as DemoClassA;
// 获取指定列的数据
var cellValue = gridView1.GetRowCellValue(rowHandle, "FieldName")?.ToString();

基本事件

// 单行选择时改变事件
gridView1.FocusedRowChanged += GridView1_FocusedRowChanged;
// 多行选择时改变事件
gridView1.SelectionChanged += GridView1_SelectionChanged;
// 空记录提示
gridView1.CustomDrawEmptyForeground += GridView1_CustomDrawEmptyForeground;

private void GridView1_FocusedRowChanged(object sender, DevExpress.XtraGrid.Views.Base.FocusedRowChangedEventArgs e)
{
	Console.WriteLine("FocusedRowChanged _" + e.FocusedRowHandle);
	if (sender is GridView gridView)
	{
		if (gridView.GetFocusedRow() is KeyValuePair<int, string> item)
		{
			labelControl1.Text = item.Value;
		}
	}
}
private void GridView1_SelectionChanged(object sender, DevExpress.Data.SelectionChangedEventArgs e)
{
	Console.WriteLine("SelectionChanged " + e.ControllerRow);
}
private void GridView1_CustomDrawEmptyForeground(object sender, CustomDrawEventArgs e)
{
    if (sender is GridView gridView)
    {
        var bindingSource = gridView.DataSource as BindingSource;
        if (bindingSource == null || bindingSource.Count == 0)
        {
            string msg = "空数据!!";
            Font font = new Font("宋体", 16, FontStyle.Bold);
            // 居中显示
            var format = new StringFormat();
            format.Alignment = StringAlignment.Center;
            e.Graphics.DrawString(msg, font, Brushes.Gray, new PointF(e.Bounds.Width / 2, e.Bounds.Y + 5), format);
        }
    }
}

自定义单元格显示

gridView1.CustomColumnDisplayText += GridView1_CustomColumnDisplayText;

private void GridView1_CustomColumnDisplayText(object sender, DevExpress.XtraGrid.Views.Base.CustomColumnDisplayTextEventArgs e)
        {
            if (e.Value != null && e.Value.ToString().Length > 0)
            {
                if (e.Column.FieldName == "绑定的属性")
                {
                    e.DisplayText = e.Value.ToString().Length == 3 ? "2" : "000";
                }
            }
        }

自定义单元格颜色

gridView1.CustomDrawCell += GridView1_CustomDrawCell;

private void GridView1_CustomDrawCell(object sender, DevExpress.XtraGrid.Views.Base.RowCellCustomDrawEventArgs e)
{
	if (e.Column.FieldName.Equals("绑定属性") && e.Cell is DevExpress.XtraGrid.Views.Grid.ViewInfo.GridCellInfo cellInfo)
	{
		if (cellInfo.IsDataCell)
		{
			var value = Convert.ToDouble(cellInfo.CellValue);
			if (value < 20)
			{
				e.Appearance.BackColor = Color.Orange;
			}
			else if (value < 100)
			{
				e.Appearance.BackColor = Color.Red;
			}
		}
	}
}

类似于事件 RowCellStyle，但是更稳定。

自定义提示

1. 添加自定义控件 ToolTipController
   gridControl1.ToolTipController = toolTipController1

2. 添加控件的事件 GetActiveObjectInfo

private void toolTipController1_GetActiveObjectInfo(object sender, ToolTipControllerGetActiveObjectInfoEventArgs e)
{
    var hitInfo = gridView1.CalcHitInfo(e.ControlMousePosition);
    if (hitInfo.RowHandle < 0 || hitInfo.Column == null || hitInfo.HitTest != DevExpress.XtraGrid.Views.Grid.ViewInfo.GridHitTest.RowCell)
    {
        toolTipController1.HideHint();
        return;
    }
    if (hitInfo.Column.FieldName == "PropertyName1")
    {
        var item = gridView1.GetRow(hitInfo.RowHandle) as DemoClassA;
        if (item != null)
        {
            e.Info = new ToolTipControlInfo("指定标识符A", item.PropertyName2);
        }
    }
}

鼠标悬停颜色跟踪

_ = new GridViewHelper(gridView1, Color.Green)
{
	HoverEnable = true
};

using DevExpress.XtraEditors;
using DevExpress.XtraGrid.Columns;
using DevExpress.XtraGrid.Views.Grid;
/// <summary>
/// GridView帮助类
/// </summary>
public class GridViewHelper
{
	private bool _hoverEnable;
	/// <summary>
	/// true启用悬停效果，false不启用
	/// </summary>
	public bool HoverEnable
	{
		get { return _hoverEnable; }
		set
		{
			_hoverEnable = value;
			UnRegisterEvent();
			if (value)
			{
				RegisterEvent();
			}
			else
			{
				_gridView.RefreshData();
			}
		}
	}


	private bool _byRow;
	/// <summary>
	/// true单行悬停，false单元格悬停
	/// </summary>
	public bool ByRow
	{
		get { return _byRow; }
		set
		{
			_byRow = value;
			UnRegisterEvent();
			if (_hoverEnable)
			{
				RegisterEvent();
			}
		}
	}
	private readonly GridView _gridView;
	private readonly Color _hoverColor;
	private int _curRowHandle;
	private GridColumn _curColumn;

	/// <summary>
	///
	/// </summary>
	/// <param name="gridView"></param>
	/// <param name="hoverColor">鼠标悬停时颜色</param>
	/// <param name="byRow">true单行，false单元格</param>
	public GridViewHelper(GridView gridView, Color hoverColor, bool byRow = true)
	{
		_gridView = gridView;
		_hoverColor = hoverColor;
		_byRow = byRow;
		_curRowHandle = int.MinValue;
	}

	private void GridView_MouseLeave(object sender, EventArgs e)
	{
		_curColumn = null;
		_curRowHandle = int.MinValue;
		_gridView.RefreshData();
	}

	private void UnRegisterEvent()
	{
		_gridView.MouseLeave -= GridView_MouseLeave;
		_gridView.MouseMove -= GridView_MouseMove;
		_gridView.RowCellStyle -= GridView_RowCellStyle;
		_gridView.RowStyle -= GridView_RowStyle;
	}

	private void RegisterEvent()
	{
		_gridView.MouseLeave += GridView_MouseLeave;
		_gridView.MouseMove += GridView_MouseMove;
		if (!_byRow)
		{
			_gridView.RowCellStyle += GridView_RowCellStyle;
		}
		else
		{
			_gridView.RowStyle += GridView_RowStyle;
		}
	}

	private void GridView_RowStyle(object sender, RowStyleEventArgs e)
	{
		if (e.RowHandle == _curRowHandle)
		{
			e.Appearance.BackColor = _hoverColor;
			e.HighPriority = true;
		}
	}

	private void GridView_RowCellStyle(object sender, RowCellStyleEventArgs e)
	{
		if (e.Column == _curColumn && e.RowHandle == _curRowHandle)
		{
			e.Appearance.BackColor = _hoverColor;
		}
	}

	private void GridView_MouseMove(object sender, MouseEventArgs e)
	{
		if (sender is GridView gridView)
		{
			var info = gridView.CalcHitInfo(e.Location);
			var bRefresh = false;
			if ((_curColumn != info.Column || _curRowHandle != info.RowHandle) && info.InRow)
			{
				bRefresh = true;
			}
			//if (info.InDataRow)   v14.2
                        if (info.InRow)
			{
				_curColumn = info.Column;
				_curRowHandle = info.RowHandle;
			}
			else
			{
				_curColumn = null;
				_curRowHandle = int.MinValue;
			}
			if (bRefresh)
			{
				_gridView.RefreshData();
			}
		}
	}
}

功能扩展

/// <summary>
/// 获取列表中已选择的项
/// </summary>
/// <typeparam name="T">绑定的数据类型</typeparam>
/// <param name="gridview"></param>
/// <returns></returns>
public static IList<T> GetSelectedAllData<T>(this GridView gridview)
{
	IList<T> rslt = new List<T>();
	// 获取选择行的行号
	var rows = gridview.GetSelectedRows();
	foreach (var indx in rows)
	{
		if (gridview.GetRow(indx) is T obj)
		{
			rslt.Add(obj);
		}
	}
	return rslt;
}
/// <summary>
/// 设置列表选中行
/// </summary>
/// <param name="gridView"></param>
/// <param name="index">从0开始</param>
public static void SetSelectionIndex(this GridView gridView, int index)
{
	// 选中整行
	gridView.OptionsSelection.EnableAppearanceFocusedRow = true;
	// 多行选择模式有效
	gridView.ClearSelection();
	if (index >= 0)
	{
		// 聚焦
		gridView.FocusedRowHandle = index;
		// 选中
		gridView.SelectRow(index);
	}
	else
	{
		gridView.FocusedRowHandle = -1;
		gridView.UnselectRow(0);
	}
}

/// <summary>
/// 设置列表可编辑
/// </summary>
/// <param name="gridView"></param>
/// <param name="fieldNames">允许编辑的列的FieldName</param>
public static void CanEdit(this GridView gridView, params string[] fieldNames)
{
    gridView.OptionsBehavior.ReadOnly = false;
    gridView.OptionsBehavior.Editable = true;
    foreach (GridColumn item in gridView.Columns)
    {
        if (!fieldNames.Contains(item.FieldName))
        {
            item.OptionsColumn.ReadOnly = true;
            item.OptionsColumn.AllowEdit = false;
        }
    }
}

/// <summary>
/// 列表复选框全选
/// </summary>
/// <param name="gridView"></param>
/// <param name="fieldName">复选框的FieldName</param>
public static void CheckedAll(this GridView gridView, string fieldName)
{
    int count = gridView.DataRowCount;
    for (int i = 0; i < count; i++)
    {
        gridView.SetRowCellValue(i, gridView.Columns[fieldName], true);
    }
    gridView.GridControl.Refresh();
}

/// <summary>
/// 列表复选框全非选
/// </summary>
/// <param name="gridView"></param>
/// <param name="fieldName">复选框的FieldName</param>
public static void UnCheckedAll(this GridView gridView, string fieldName)
{
    int count = gridView.DataRowCount;
    for (int i = 0; i < count; i++)
    {
        gridView.SetRowCellValue(i, gridView.Columns[fieldName], false);
    }
    gridView.GridControl.Refresh();
}

绑定指定字段

绑定嵌套属性

FieldName可设置为：PorpertyName1.NestedPropertyName。

添加复选框列

若GridMultiSelectMode没有CheckBoxRowSelect，可以手动添加CheckEdit。

表头合并

在设计页面，把默认的GridView转换成BandedGridView。然后在Run Designer中拖动编辑即可。

列中添加功能按钮

默认ColumnEdit为空，可选择需要的按钮，比如Button。

列中不绑定对象，可以把 TextEditStyle 设置为 HideTextEditor。
具体按钮设置如下：

按钮响应声明：

按钮响应逻辑：

private void repositoryItemButtonEdit1_ButtonClick(object sender, ButtonPressedEventArgs e)
{
    var row = (DemoClass)gridView1.GetFocusedRow();
    if (e.Button.Caption == "编辑")
    {
        // TODO
    }
    else if (e.Button.Caption == "删除")
    {
        // TODO
    }
}

TreeList

绑定数据与图标

using DevExpress.XtraEditors;
using DevExpress.XtraTreeList.Nodes;

private List<TreeNodeDto> _data;
private void Form1_Load(object sender, EventArgs e)
{
    _data = SalesDataGenerator.CreateData();
    treeList1.Columns.Clear();
    treeList1.Nodes.Clear();
    treeList1.KeyFieldName = "ID";
    treeList1.ParentFieldName = "ParentID";
    treeList1.OptionsBehavior.PopulateServiceColumns = false;
    treeList1.OptionsBehavior.AutoPopulateColumns = true;
    treeList1.OptionsBehavior.ExpandNodeOnDrag = false;
    treeList1.OptionsBehavior.Editable = false; // 不可编辑
    treeList1.DataSource = _data;
    treeList1.OptionsView.ShowColumns = false;  // 隐藏列标头
    treeList1.OptionsView.ShowHorzLines = false;// 隐藏水平表格线
    treeList1.OptionsView.ShowVertLines = false;// 隐藏垂直表格线
    treeList1.OptionsView.ShowIndicator = false;// 隐藏节点指示器面板
    treeList1.OptionsView.ShowCheckBoxes = false;   // 隐藏勾选框
    treeList1.OptionsView.ShowFocusedFrame = true;  // 焦点虚框
    treeList1.OptionsSelection.EnableAppearanceFocusedCell = false; // 禁用单元格选中
    treeList1.OptionsSelection.EnableAppearanceFocusedRow = false;  // 禁用整行选中
    treeList1.OptionsLayout.StoreAppearance = true;
    treeList1.OptionsMenu.EnableColumnMenu = false;
    treeList1.OptionsMenu.EnableFooterMenu = false;
    treeList1.OptionsMenu.ShowAutoFilterRowItem = false;
    treeList1.SelectImageList = imageList1;
    treeList1.Columns["Tag"].Visible = false;  // 设置列隐藏
    treeList1.RowHeight = 30;
    treeList1.ExpandAll();
}

同步图标索引

private void TreeList1_GetSelectImage(object sender, DevExpress.XtraTreeList.GetSelectImageEventArgs e)
{
    if (e.Node == null)
    {
        return;
    }
    var data = treeList1.GetDataRecordByNode(e.Node) as TreeNodeDto;
    if (data != null)
    {
        e.Node.ImageIndex = data.ImageIndex;
        e.Node.SelectImageIndex = data.ImageIndex;
    }
}

双击

private void TreeList1_MouseDoubleClick(object sender, MouseEventArgs e)
{
    var node = treeList1.CalcHitInfo(e.Location).Node;
    if (node == null)
    {
        return;
    }
    var data = treeList1.GetDataRecordByNode(node) as TreeNodeDto;
    node.SelectImageIndex = node.ImageIndex;
    lbMsg.Text = data.DisplayText;
}

DataSource强制更新

private void BtnAdd_Click(object sender, EventArgs e)
{
    _data.Add(new TreeNodeDto() { DisplayText = "test", ParentID = -1, ID = 100 });
    _data.Add(new TreeNodeDto() { DisplayText = "test2", ParentID = -1, ID = 101 });
    // 如果Data Source 有更改
    treeList1.RefreshDataSource();
    treeList1.Update();
}

public static List<TreeNodeDto> CreateData()
{
    List<TreeNodeDto> data = new List<TreeNodeDto>();
    data.Add(new TreeNodeDto(1, -1, TreeNodeEnum.TreeNode, typeof(Form1)));
    data.Add(new TreeNodeDto(2, -1, TreeNodeEnum.TreeNode2, typeof(Form1)));
    data.Add(new TreeNodeDto(3, -1, TreeNodeEnum.TreeNode3, typeof(Form1)));

    data.Add(new TreeNodeDto(4, 3, TreeNodeEnum.SubNode1, typeof(Form1)));
    data.Add(new TreeNodeDto(5, 4, TreeNodeEnum.ChildNode, typeof(Form1)));
    data.Add(new TreeNodeDto(6, 4, TreeNodeEnum.ChildNode2, typeof(Form1)));
    data.Add(new TreeNodeDto(7, 4, TreeNodeEnum.ChildNode3, typeof(Form1)));
    return data;
}

public class TreeNodeDto
{
    /// <summary>
    /// 节点唯一ID
    /// </summary>
    public int ID { get; set; }
    /// <summary>
    /// 父节点ID
    /// </summary>
    public int ParentID { get; set; }
    /// <summary>
    /// 节点名称
    /// </summary>
    public string DisplayText { get; set; }
    /// <summary>
    /// 节点标签
    /// </summary>
    public object Tag { get; set; }
    /// <summary>
    /// 节点图标索引
    /// </summary>
    public int ImageIndex { get; set; }
    public TreeNodeDto() {}
    public TreeNodeDto(int id, int parentId, TreeNodeEnum nodeEnum, Type ucType, int imageIndex = 1) : this(id, parentId, nodeEnum.GetEnumDescription(), ucType, imageIndex)
    {
    }
    public TreeNodeDto(int id, int parentId, string name, Type ucType, int imageIndex = 1)
    {
        ID = id;
        ParentID = parentId;
        DisplayText = name;
        if (ucType == typeof(Nullable))
        {
            Tag = null;
        }
        else
        {
            Tag = ucType;
        }
        ImageIndex = imageIndex;
    }
}
public enum TreeNodeEnum
{
    [Description("Node1")]
    TreeNode,
    [Description("Node2")]
    TreeNode2,
    [Description("Node3")]
    TreeNode3,
    [Description("SubNode1")]
    SubNode1,
    [Description("ChildNode1")]
    ChildNode,
    [Description("ChildNode2")]
    ChildNode2,
    [Description("ChildNode3")]
    ChildNode3,
}

PropertyGridControl

public DemoClass MyDemo { get; set; }
public Form1()
{
	InitializeComponent();
	MyDemo = new DemoClass();
}
private void Form1_Load(object sender, EventArgs e)
{
	propertyDescriptionControl1.PropertyGrid = propertyGridControl1;
	propertyGridControl1.SelectedObject = MyDemo;

}

public class DemoClass
{
	private int _myVar = 90;
	[Category("Category1")]
	[DisplayName("整数")]
	public int P_Integer
	{
		get { return _myVar; }
		set { _myVar = value; }
	}

	private bool _bValue;

	[Category("Category1")]
	public bool P_Boolean
	{
		get { return _bValue; }
		set { _bValue = value; }
	}

	private string _strValue;

	[DisplayName("字符串")]
	[Description("字符串描述")]
	public string P_String
	{
		get { return _strValue; }
		set { _strValue = value; }
	}

}

DXValidationProvider

验证控件。
dxValidatationProvider作为一个验证控件，可以同时对多个控件进行数据验证。
但是对同一个控件的验证，则需要分别写在不同的dxValidatationProvider中，防止被覆盖。

XtraMessageBox

#region ShowInfo
public static void ShowInfo(this XtraForm form, string message)
{
    XtraMessageBox.Show(message, "Info", System.Windows.Forms.MessageBoxButtons.OK, System.Windows.Forms.MessageBoxIcon.Information);
}
public static void ShowDebug(this XtraForm form, string message)
{
    XtraMessageBox.Show(message, "Debug", System.Windows.Forms.MessageBoxButtons.YesNo);
}
public static bool ShowConfirm(this XtraForm form, string message)
{
    var dlg = XtraMessageBox.Show(message, "Confirm", System.Windows.Forms.MessageBoxButtons.OKCancel);
    return dlg == System.Windows.Forms.DialogResult.OK;
}
public static void ShowInfo(this XtraUserControl control, string message)
{
    XtraMessageBox.Show(message, "Info", System.Windows.Forms.MessageBoxButtons.OK, System.Windows.Forms.MessageBoxIcon.Information);
}
public static void ShowDebug(this XtraUserControl control, string message)
{
    XtraMessageBox.Show(message, "Debug", System.Windows.Forms.MessageBoxButtons.YesNo);
}
public static bool ShowConfirm(this XtraUserControl control, string message)
{
    var dlg = XtraMessageBox.Show(message, "Confirm", System.Windows.Forms.MessageBoxButtons.OKCancel);
    return dlg == System.Windows.Forms.DialogResult.OK;
}
#endregion

XtraScrollableControl

有内置滚动条的面板。
其中控件不能设置 Dock=Fill。

END
