Android通讯录管理(获取联系人、通话记录、短信消息)(二)
前言:上一篇博客介绍的是获取联系人的实现,本篇博客将介绍通话记录的实现。
同样的,你可以到这里下载源码:http://download.csdn.net/detail/wwj_748/6962865
界面布局:
/Contact_Demo/res/layout/contact_record_list_view.xml
- <?xml version="1.0" encoding="utf-8"?>
- <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
- android:id="@+id/contact_record_view"
- android:layout_width="match_parent"
- android:layout_height="match_parent"
- android:background="#000000">
- <ListView
- android:id="@+id/call_log_list"
- android:layout_width="fill_parent"
- android:layout_height="fill_parent"
- android:layout_alignParentTop="true"
- android:cacheColorHint="#000000"
- android:fadingEdge="none"
- android:scrollingCache="false"
- android:visibility="visible" />
- </RelativeLayout>
/Contact_Demo/res/layout/contact_record_list_item.xml
- <?xml version="1.0" encoding="utf-8"?>
- <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
- android:layout_width="fill_parent"
- android:layout_height="wrap_content"
- android:orientation="vertical" >
- <ImageView
- android:id="@+id/call_type"
- android:layout_width="wrap_content"
- android:layout_height="wrap_content"
- android:layout_centerVertical="true"
- android:layout_marginLeft="5dip"
- android:layout_marginRight="5dip"
- android:background="@drawable/ic_calllog_outgoing_nomal" />
- <LinearLayout
- android:layout_width="wrap_content"
- android:layout_height="wrap_content"
- android:layout_centerVertical="true"
- android:layout_toRightOf="@+id/call_type"
- android:orientation="vertical" >
- <TextView
- android:id="@+id/name"
- android:layout_width="wrap_content"
- android:layout_height="0dip"
- android:layout_weight="1"
- android:textAppearance="?android:textAppearanceMedium"
- android:textColor="#ffffff" />
- <TextView
- android:id="@+id/number"
- android:layout_width="wrap_content"
- android:layout_height="wrap_content"
- android:textAppearance="?android:textAppearanceSmall"
- android:textColor="#cccccc" />
- </LinearLayout>
- <TextView
- android:id="@+id/call_btn"
- android:layout_width="wrap_content"
- android:layout_height="wrap_content"
- android:layout_alignParentRight="true"
- android:layout_centerVertical="true"
- android:layout_marginLeft="10dip"
- android:layout_marginRight="10dip"
- android:background="@drawable/ic_calllog_call_btn" />
- <ImageView
- android:id="@+id/fg"
- android:layout_width="wrap_content"
- android:layout_height="75dip"
- android:layout_toLeftOf="@+id/call_btn"
- android:background="@drawable/black_bg" />
- <TextView
- android:id="@+id/time"
- android:layout_width="wrap_content"
- android:layout_height="wrap_content"
- android:layout_centerVertical="true"
- android:layout_toLeftOf="@+id/fg"
- android:textColor="#ffffff" />
- </RelativeLayout>
定义实体类:
/Contact_Demo/src/com/suntek/contact/model/CallLogBean.java
- package com.suntek.contact.model;
- /**
- * 通话记录实体类
- *
- * @author Administrator
- *
- */
- public class CallLogBean {
- private int id;
- private String name; // 名称
- private String number; // 号码
- private String date; // 日期
- private int type; // 来电:1,拨出:2,未接:3
- private int count; // 通话次数
- public int getId() {
- return id;
- }
- public void setId(int id) {
- this.id = id;
- }
- public String getName() {
- return name;
- }
- public void setName(String name) {
- this.name = name;
- }
- public String getNumber() {
- return number;
- }
- public void setNumber(String number) {
- this.number = number;
- }
- public String getDate() {
- return date;
- }
- public void setDate(String date) {
- this.date = date;
- }
- public int getType() {
- return type;
- }
- public void setType(int type) {
- this.type = type;
- }
- public int getCount() {
- return count;
- }
- public void setCount(int count) {
- this.count = count;
- }
- }
/Contact_Demo/src/com/suntek/contact/adapter/DialAdapter.java
- package com.suntek.contact.adapter;
- import java.util.List;
- import android.content.Context;
- import android.content.Intent;
- import android.net.Uri;
- import android.view.LayoutInflater;
- import android.view.View;
- import android.view.View.OnClickListener;
- import android.view.ViewGroup;
- import android.widget.BaseAdapter;
- import android.widget.ImageView;
- import android.widget.TextView;
- import com.suntek.contact.R;
- import com.suntek.contact.model.CallLogBean;
- /**
- * 电话记录适配器
- *
- * @author Administrator
- *
- */
- public class DialAdapter extends BaseAdapter {
- private Context ctx;
- private List<CallLogBean> callLogs;
- private LayoutInflater inflater;
- public DialAdapter(Context context, List<CallLogBean> callLogs) {
- this.ctx = context;
- this.callLogs = callLogs;
- this.inflater = LayoutInflater.from(context);
- }
- @Override
- public int getCount() {
- return callLogs.size();
- }
- @Override
- public Object getItem(int position) {
- return callLogs.get(position);
- }
- @Override
- public long getItemId(int position) {
- return position;
- }
- @Override
- public View getView(int position, View convertView, ViewGroup parent) {
- ViewHolder holder;
- if (convertView == null) {
- convertView = inflater.inflate(R.layout.contact_record_list_item,
- null);
- holder = new ViewHolder();
- holder.call_type = (ImageView) convertView
- .findViewById(R.id.call_type);
- holder.name = (TextView) convertView.findViewById(R.id.name);
- holder.number = (TextView) convertView.findViewById(R.id.number);
- holder.time = (TextView) convertView.findViewById(R.id.time);
- holder.call_btn = (TextView) convertView
- .findViewById(R.id.call_btn);
- convertView.setTag(holder); // 缓存
- } else {
- holder = (ViewHolder) convertView.getTag();
- }
- CallLogBean callLog = callLogs.get(position);
- switch (callLog.getType()) {
- case 1:
- holder.call_type
- .setBackgroundResource(R.drawable.ic_calllog_outgoing_nomal);
- break;
- case 2:
- holder.call_type
- .setBackgroundResource(R.drawable.ic_calllog_incomming_normal);
- break;
- case 3:
- holder.call_type
- .setBackgroundResource(R.drawable.ic_calllog_missed_normal);
- break;
- }
- holder.name.setText(callLog.getName());
- holder.number.setText(callLog.getNumber());
- holder.time.setText(callLog.getDate());
- addViewListener(holder.call_btn, callLog, position);
- return convertView;
- }
- private static class ViewHolder {
- ImageView call_type;
- TextView name;
- TextView number;
- TextView time;
- TextView call_btn;
- }
- private void addViewListener(View view, final CallLogBean callLog,
- final int position) {
- view.setOnClickListener(new OnClickListener() {
- @Override
- public void onClick(View v) {
- Uri uri = Uri.parse("tel:" + callLog.getNumber());
- Intent intent = new Intent(Intent.ACTION_CALL, uri);
- ctx.startActivity(intent);
- }
- });
- }
- }
/Contact_Demo/src/com/suntek/contact/ContactRecordListActivity.java
- package com.suntek.contact;
- import java.text.SimpleDateFormat;
- import java.util.ArrayList;
- import java.util.Date;
- import java.util.List;
- import android.app.Activity;
- import android.content.AsyncQueryHandler;
- import android.content.ContentResolver;
- import android.database.Cursor;
- import android.net.Uri;
- import android.os.Bundle;
- import android.provider.CallLog;
- import android.widget.ListView;
- import com.suntek.contact.adapter.DialAdapter;
- import com.suntek.contact.model.CallLogBean;
- /**
- * 通话记录列表
- *
- * @author wwj
- *
- */
- public class ContactRecordListActivity extends Activity {
- private ListView callLogListView;
- private AsyncQueryHandler asyncQuery;
- private DialAdapter adapter;
- private List<CallLogBean> callLogs;
- @Override
- protected void onCreate(Bundle savedInstanceState) {
- super.onCreate(savedInstanceState);
- setContentView(R.layout.contact_record_list_view);
- callLogListView = (ListView) findViewById(R.id.call_log_list);
- asyncQuery = new MyAsyncQueryHandler(getContentResolver());
- init();
- }
- private void init() {
- Uri uri = android.provider.CallLog.Calls.CONTENT_URI;
- // 查询的列
- String[] projection = { CallLog.Calls.DATE, // 日期
- CallLog.Calls.NUMBER, // 号码
- CallLog.Calls.TYPE, // 类型
- CallLog.Calls.CACHED_NAME, // 名字
- CallLog.Calls._ID, // id
- };
- asyncQuery.startQuery(0, null, uri, projection, null, null,
- CallLog.Calls.DEFAULT_SORT_ORDER);
- }
- private class MyAsyncQueryHandler extends AsyncQueryHandler {
- public MyAsyncQueryHandler(ContentResolver cr) {
- super(cr);
- }
- @Override
- protected void onQueryComplete(int token, Object cookie, Cursor cursor) {
- if (cursor != null && cursor.getCount() > 0) {
- callLogs = new ArrayList<CallLogBean>();
- SimpleDateFormat sfd = new SimpleDateFormat("MM-dd hh:mm");
- Date date;
- cursor.moveToFirst(); // 游标移动到第一项
- for (int i = 0; i < cursor.getCount(); i++) {
- cursor.moveToPosition(i);
- date = new Date(cursor.getLong(cursor
- .getColumnIndex(CallLog.Calls.DATE)));
- String number = cursor.getString(cursor
- .getColumnIndex(CallLog.Calls.NUMBER));
- int type = cursor.getInt(cursor
- .getColumnIndex(CallLog.Calls.TYPE));
- String cachedName = cursor.getString(cursor
- .getColumnIndex(CallLog.Calls.CACHED_NAME));// 缓存的名称与电话号码,如果它的存在
- int id = cursor.getInt(cursor
- .getColumnIndex(CallLog.Calls._ID));
- CallLogBean callLogBean = new CallLogBean();
- callLogBean.setId(id);
- callLogBean.setNumber(number);
- callLogBean.setName(cachedName);
- if (null == cachedName || "".equals(cachedName)) {
- callLogBean.setName(number);
- }
- callLogBean.setType(type);
- callLogBean.setDate(sfd.format(date));
- callLogs.add(callLogBean);
- }
- if (callLogs.size() > 0) {
- setAdapter(callLogs);
- }
- }
- super.onQueryComplete(token, cookie, cursor);
- }
- }
- private void setAdapter(List<CallLogBean> callLogs) {
- adapter = new DialAdapter(this, callLogs);
- callLogListView.setAdapter(adapter);
- }
- }
代码是最好的解释了,这里使用的几个重要的类,一个是Uri(进行查询的通用资源标志符),一个是AsyncQueryHandler(Android提供的异步操作数据库的类),这里我们调用它的startQuery方法来查询数据库,在它onQueryComplete方法中得到数据库返回的游标cousor,通过curor来取得数据库对应表中的字段值。
