xxl-job学习使用

首先先介绍一下xxl-job，这是出自大众点评许雪里(xxl就是作者名字的拼音首字母)的开源项目，官网上介绍这是一个轻量级分布式任务调度框架，其核心设计目标是开发迅速、学习简单、轻量级、易扩展。跟elasticjob不同，xxl-job环境依赖于mysql，不用ZooKeeper，这也是最大的不同。

elasticjob的初衷是为了面对高并发复杂的业务，即使是在业务量大，服务器多的时候也能做好任务调度，尽可能的利用服务器的资源。使用ZooKeeper使其具有高可用、一致性的，而且还具有良好的扩展性。官网上写

elasticjob是无中心化的，通过ZooKeeper的选举机制选举出主服务器，如果主服务器挂了，会重新选举新的主服务器。因此elasticjob具有良好的扩展性和可用性，但是使用和运维有一定的复杂







对xxl-job进行配置和创建 XxlJobSpringExecutor 执行器

复制代码
@Slf4j
@Configuration
public class XxlJobConfig {

    @Value("${xxl.job.admin.addresses}")
    private String adminAddresses;
    @Value("${xxl.job.executor.appname}")
    private String appName;
    @Value("${xxl.job.executor.ip}")
    private String ip;
    @Value("${xxl.job.executor.port}")
    private int port;
    @Value("${xxl.job.accessToken}")
    private String accessToken;
    @Value("${xxl.job.executor.logpath}")
    private String logPath;
    @Value("${xxl.job.executor.logretentiondays}")
    private int logRetentionDays;

    @Bean
    public XxlJobSpringExecutor xxlJobExecutor() {
        // 创建 XxlJobSpringExecutor 执行器
        XxlJobSpringExecutor xxlJobSpringExecutor = new XxlJobSpringExecutor();
        xxlJobSpringExecutor.setAdminAddresses(adminAddresses);
        xxlJobSpringExecutor.setAppname(appName);
        xxlJobSpringExecutor.setIp(ip);
        xxlJobSpringExecutor.setPort(port);
        xxlJobSpringExecutor.setAccessToken(accessToken);
        xxlJobSpringExecutor.setLogPath(logPath);
        xxlJobSpringExecutor.setLogRetentionDays(logRetentionDays);
        // 返回
        return xxlJobSpringExecutor;
    }

}
复制代码



使用java api 通过xxl-job接口进行调度

复制代码
@Slf4j
@Service
public class CronTaskServiceImpl implements CronTaskService {

    @Value("${xxl.job.admin.username}")
    private String xxlUserName;

    @Value("${xxl.job.admin.password}")
    private String xxlPassword;

    @Value("${xxl.job.admin.addresses}")
    private String xxlAddresses;


    @Override
    public BasicResultVO saveCronTask(XxlJobInfo xxlJobInfo) {
        Map<String, Object> params = JSON.parseObject(JSON.toJSONString(xxlJobInfo), Map.class);
        String path = xxlJobInfo.getId() == null ? xxlAddresses + XxlJobConstant.INSERT_URL
                : xxlAddresses + XxlJobConstant.UPDATE_URL;

        HttpResponse response;
        ReturnT returnT = null;
        try {
　　　　　　// 调用xxl-job的接口将任务信息sava到xxl-job中；然后xxl-job会根据executorHandler 的值找到对应的Handler
　　　　　　// 比如executorHandler 的值是
            response = HttpRequest.post(path).form(params).cookie(getCookie()).execute();
            returnT = JSON.parseObject(response.body(), ReturnT.class);

            // 插入时需要返回Id，而更新时不需要
            if (response.isOk() && ReturnT.SUCCESS_CODE == returnT.getCode()) {
                if (path.contains(XxlJobConstant.INSERT_URL)) {
                    Integer taskId = Integer.parseInt(String.valueOf(returnT.getContent()));
                    return BasicResultVO.success(taskId);
                } else if (path.contains(XxlJobConstant.UPDATE_URL)) {
                    return BasicResultVO.success();
                }
            }
        } catch (Exception e) {
            log.error("CronTaskService#saveTask fail,e:{},param:{},response:{}", Throwables.getStackTraceAsString(e)
                    , JSON.toJSONString(xxlJobInfo), JSON.toJSONString(returnT));
        }
        return BasicResultVO.fail(RespStatusEnum.SERVICE_ERROR, JSON.toJSONString(returnT));
    }

    @Override
    public BasicResultVO deleteCronTask(Integer taskId) {
        String path = xxlAddresses + XxlJobConstant.DELETE_URL;

        HashMap<String, Object> params = MapUtil.newHashMap();
        params.put("id", taskId);

        HttpResponse response;
        ReturnT returnT = null;
        try {
            response = HttpRequest.post(path).form(params).cookie(getCookie()).execute();
            returnT = JSON.parseObject(response.body(), ReturnT.class);
            if (response.isOk() && ReturnT.SUCCESS_CODE == returnT.getCode()) {
                return BasicResultVO.success();
            }
        } catch (Exception e) {
            log.error("CronTaskService#deleteCronTask fail,e:{},param:{},response:{}", Throwables.getStackTraceAsString(e)
                    , JSON.toJSONString(params), JSON.toJSONString(returnT));
        }
        return BasicResultVO.fail(RespStatusEnum.SERVICE_ERROR, JSON.toJSONString(returnT));
    }

    @Override
    public BasicResultVO startCronTask(Integer taskId) {
        String path = xxlAddresses + XxlJobConstant.RUN_URL;

        HashMap<String, Object> params = MapUtil.newHashMap();
        params.put("id", taskId);

        HttpResponse response;
        ReturnT returnT = null;
        try {
            response = HttpRequest.post(path).form(params).cookie(getCookie()).execute();
            returnT = JSON.parseObject(response.body(), ReturnT.class);
            if (response.isOk() && ReturnT.SUCCESS_CODE == returnT.getCode()) {
                return BasicResultVO.success();
            }
        } catch (Exception e) {
            log.error("CronTaskService#startCronTask fail,e:{},param:{},response:{}", Throwables.getStackTraceAsString(e)
                    , JSON.toJSONString(params), JSON.toJSONString(returnT));
        }
        return BasicResultVO.fail(RespStatusEnum.SERVICE_ERROR, JSON.toJSONString(returnT));
    }

    @Override
    public BasicResultVO stopCronTask(Integer taskId) {
        String path = xxlAddresses + XxlJobConstant.STOP_URL;

        HashMap<String, Object> params = MapUtil.newHashMap();
        params.put("id", taskId);

        HttpResponse response;
        ReturnT returnT = null;
        try {
            response = HttpRequest.post(path).form(params).cookie(getCookie()).execute();
            returnT = JSON.parseObject(response.body(), ReturnT.class);
            if (response.isOk() && ReturnT.SUCCESS_CODE == returnT.getCode()) {
                return BasicResultVO.success();
            }
        } catch (Exception e) {
            log.error("CronTaskService#stopCronTask fail,e:{},param:{},response:{}", Throwables.getStackTraceAsString(e)
                    , JSON.toJSONString(params), JSON.toJSONString(returnT));
        }
        return BasicResultVO.fail(RespStatusEnum.SERVICE_ERROR, JSON.toJSONString(returnT));
    }

    @Override
    public BasicResultVO getGroupId(String appName, String title) {
        String path = xxlAddresses + XxlJobConstant.JOB_GROUP_PAGE_LIST;

        HashMap<String, Object> params = MapUtil.newHashMap();
        params.put("appname", appName);
        params.put("title", title);

        HttpResponse response = null;
        try {
            response = HttpRequest.post(path).form(params).cookie(getCookie()).execute();
            Integer id = JSON.parseObject(response.body()).getJSONArray("data").getJSONObject(0).getInteger("id");
            if (response.isOk() && id != null) {
                return BasicResultVO.success(id);
            }
        } catch (Exception e) {
            log.error("CronTaskService#getGroupId fail,e:{},param:{},response:{}", Throwables.getStackTraceAsString(e)
                    , JSON.toJSONString(params), JSON.toJSONString(response.body()));
        }
        return BasicResultVO.fail(RespStatusEnum.SERVICE_ERROR, JSON.toJSONString(response.body()));
    }

    @Override
    public BasicResultVO createGroup(XxlJobGroup xxlJobGroup) {
        Map<String, Object> params = JSON.parseObject(JSON.toJSONString(xxlJobGroup), Map.class);
        String path = xxlAddresses + XxlJobConstant.JOB_GROUP_INSERT_URL;

        HttpResponse response;
        ReturnT returnT = null;

        try {
            response = HttpRequest.post(path).form(params).cookie(getCookie()).execute();
            returnT = JSON.parseObject(response.body(), ReturnT.class);
            if (response.isOk() && ReturnT.SUCCESS_CODE == returnT.getCode()) {
                return BasicResultVO.success();
            }
        } catch (Exception e) {
            log.error("CronTaskService#createGroup fail,e:{},param:{},response:{}", Throwables.getStackTraceAsString(e)
                    , JSON.toJSONString(params), JSON.toJSONString(returnT));
        }
        return BasicResultVO.fail(RespStatusEnum.SERVICE_ERROR, JSON.toJSONString(returnT));
    }

    /**
     * 获取xxl cookie
     *
     * @return String
     */
    private String getCookie() {
        Map<String, Object> params = MapUtil.newHashMap();
        params.put("userName", xxlUserName);
        params.put("password", xxlPassword);
        params.put("randomCode", IdUtil.fastSimpleUUID());

        String path = xxlAddresses + XxlJobConstant.LOGIN_URL;
        HttpResponse response = null;
        try {
            response = HttpRequest.post(path).form(params).execute();
            if (response.isOk()) {
                List<HttpCookie> cookies = response.getCookies();
                StringBuilder sb = new StringBuilder();
                for (HttpCookie cookie : cookies) {
                    sb.append(cookie.toString());
                }
                return sb.toString();
            }
        } catch (Exception e) {
            log.error("CronTaskService#createGroup getCookie,e:{},param:{},response:{}", Throwables.getStackTraceAsString(e)
                    , JSON.toJSONString(params), JSON.toJSONString(response));
        }
        return null;
    }
}
调度执行的handler
复制代码
@Service
@Slf4j
public class CronTaskHandler {

    @Autowired
    private TaskHandler taskHandler;

    @Autowired
    private ThreadPoolUtils threadPoolUtils;
    private DtpExecutor dtpExecutor = CronAsyncThreadPoolConfig.getXxlCronExecutor();

    /**
     * 处理后台的 austin 定时任务消息
     */
    @XxlJob("austinJob")
    public void execute() {
        log.info("CronTaskHandler#execute messageTemplateId:{} cron exec!", XxlJobHelper.getJobParam());
        threadPoolUtils.register(dtpExecutor);

        Long messageTemplateId = Long.valueOf(XxlJobHelper.getJobParam());
        dtpExecutor.execute(() -> taskHandler.handle(messageTemplateId));

    }

}
复制代码



复制代码
