pentaho-server

配置 MySQL

1、执行 data\mysql 下的脚本：create_jcr_mysql.sql、create_quartz_mysql.sql、create_repository_mysql.sql

执行前可将脚本中的 DEFAULT CHARACTER SET latin1 改为 DEFAULT CHARACTER SET utf8mb4

脚本默认新建 hibuser@localhost/password、jcr_user@localhost/password 和 pentaho_user@localhost/password 三个用户

2、设置 Quartz

打开 pentaho-solutions/system/scheduler-plugin/quartz/quartz.properties

找到 #_replace_jobstore_properties 部分
org.quartz.jobStore.driverDelegateClass = org.quartz.impl.jdbcjobstore.StdJDBCDelegate
找到 # Configure Datasources 部分
org.quartz.dataSource.myDS.jndiURL = Quartz

3、设置 hibernate

打开 pentaho-solutions/system/hibernate/hibernate-settings.xml

<config-file>system/hibernate/mysql5.hibernate.cfg.xml</config-file>

打开 pentaho-solutions/system/hibernate/mysql5.hibernate.cfg.xml，新的为 com.mysql.cj.jdbc.Driver

<property name="connection.driver_class">com.mysql.jdbc.Driver</property>

复制 pentaho-solutions/system/dialects/mysql5/audit_sql.xml 到 pentaho-solutions/system 目录中

4、设置 Jackrabbit

打开 pentaho-solutions/system/jackrabbit/repository.xml，注释掉原来的，放开或添加需要的

找到 Repository-FileSystem 部分
<FileSystem class="org.apache.jackrabbit.core.fs.db.DbFileSystem">
  <param name="driver" value="javax.naming.InitialContext"/>
  <param name="url" value="java:comp/env/jdbc/jackrabbit"/>
  <param name="schema" value="mysql"/>
  <param name="schemaObjectPrefix" value="fs_repos_"/>
</FileSystem>
找到 Repository-DataStore 部分
<DataStore class="org.apache.jackrabbit.core.data.db.DbDataStore">
  <param name="driver" value="javax.naming.InitialContext"/>
  <param name="url" value="java:comp/env/jdbc/jackrabbit"/>
  <param name="databaseType" value="mysql"/>
  <param name="minRecordLength" value="1024"/>
  <param name="maxConnections" value="3"/>
  <param name="copyWhenReading" value="true"/>
  <param name="tablePrefix" value=""/>
  <param name="schemaObjectPrefix" value="ds_repos_"/>
</DataStore>
找到 Repository-Workspaces-FileSystem 部分
<FileSystem class="org.apache.jackrabbit.core.fs.db.DbFileSystem">
  <param name="driver" value="javax.naming.InitialContext"/>
  <param name="url" value="java:comp/env/jdbc/jackrabbit"/>
  <param name="schema" value="mysql"/>
  <param name="schemaObjectPrefix" value="fs_ws_"/>
</FileSystem>
找到 Repository-Workspaces-PersistenceManager 部分
<PersistenceManager class="org.apache.jackrabbit.core.persistence.bundle.MySqlPersistenceManager">
  <param name="driver" value="javax.naming.InitialContext"/>
  <param name="url" value="java:comp/env/jdbc/jackrabbit"/>
  <param name="schema" value="mysql"/>
  <param name="schemaObjectPrefix" value="${wsp.name}_pm_ws_"/>
</PersistenceManager>
找到 Repository-Versioning-FileSystem 部分
<FileSystem class="org.apache.jackrabbit.core.fs.db.DbFileSystem">
  <param name="driver" value="javax.naming.InitialContext"/>
  <param name="url" value="java:comp/env/jdbc/jackrabbit"/>
  <param name="schema" value="mysql"/>
  <param name="schemaObjectPrefix" value="fs_ver_"/>
</FileSystem>
找到 Repository-Versioning-PersistenceManager 部分
<PersistenceManager class="org.apache.jackrabbit.core.persistence.bundle.MySqlPersistenceManager">
  <param name="driver" value="javax.naming.InitialContext"/>
  <param name="url" value="java:comp/env/jdbc/jackrabbit"/>
  <param name="schema" value="mysql"/>
  <param name="schemaObjectPrefix" value="pm_ver_"/>
</PersistenceManager>
找到 Repository-Cluster 部分
<Journal class="org.apache.jackrabbit.core.journal.DatabaseJournal">
  <param name="revision" value="${rep.home}/revision.log"/>
  <param name="driver" value="javax.naming.InitialContext"/>
  <param name="url" value="java:comp/env/jdbc/jackrabbit"/>
  <param name="schema" value="mysql"/>
  <param name="schemaObjectPrefix" value="J_C_"/>
  <param name="janitorEnabled" value="true"/>
  <param name="janitorSleep" value="86400"/>
  <param name="janitorFirstRunHourOfDay" value="3"/>
</Journal>

5、设置 tomcat

下载 JDBC 驱动，复制 jar 到 tomcat/lib 文件夹，然后删除其余不需要的 JDBC 驱动 jar

打开 tomcat/webapps/pentaho/META-INF/context.xml，删除原有的，添加以下配置

<Resource validationQuery="select 1" url="jdbc:mysql://localhost:3306/hibernate"
        driverClassName="com.mysql.jdbc.Driver" password="password" username="hibuser"
        initialSize="0" maxActive="20" maxIdle="10" maxWait="10000"
        factory="org.pentaho.di.core.database.util.DecryptingDataSourceFactory"
        type="javax.sql.DataSource" auth="Container" name="jdbc/Hibernate"/>
<Resource validationQuery="select 1" url="jdbc:mysql://localhost:3306/hibernate"
        driverClassName="com.mysql.jdbc.Driver" password="password" username="hibuser"
        initialSize="0" maxActive="20" maxIdle="10" maxWait="10000"
        factory="org.pentaho.di.core.database.util.DecryptingDataSourceFactory"
        type="javax.sql.DataSource" auth="Container" name="jdbc/Audit"/>
<Resource validationQuery="select 1" url="jdbc:mysql://localhost:3306/quartz"
        driverClassName="com.mysql.jdbc.Driver" password="password" username="pentaho_user"
        testOnBorrow="true" initialSize="0" maxActive="20" maxIdle="10" maxWait="10000"
        factory="org.pentaho.di.core.database.util.DecryptingDataSourceFactory"
        type="javax.sql.DataSource" auth="Container" name="jdbc/Quartz"/>
<Resource validationQuery="select 1" url="jdbc:mysql://localhost:3306/pentaho_operations_mart"
        driverClassName="com.mysql.jdbc.Driver" password="password" username="hibuser"
        initialSize="0" maxActive="20" maxIdle="10" maxWait="10000"
        factory="org.pentaho.di.core.database.util.DecryptingDataSourceFactory"
        type="javax.sql.DataSource" auth="Container" name="jdbc/pentaho_operations_mart"/>
<Resource validationQuery="select 1" url="jdbc:mysql://localhost:3306/pentaho_operations_mart"
        driverClassName="com.mysql.jdbc.Driver" password="password" username="hibuser"
        initialSize="0" maxActive="20" maxIdle="10" maxWait="10000"
        factory="org.pentaho.di.core.database.util.DecryptingDataSourceFactory"
        type="javax.sql.DataSource" auth="Container" name="jdbc/PDI_Operations_Mart"/>
<Resource name="jdbc/live_logging_info" auth="Container" type="javax.sql.DataSource"
        factory="org.pentaho.di.core.database.util.DecryptingDataSourceFactory"
        initialSize="0" maxActive="20" maxIdle="10" maxWait="10000"
        username="hibuser" password="password" driverClassName="com.mysql.jdbc.Driver"
        url="jdbc:mysql://localhost:3306/pentaho_dilogs" validationQuery="select 1"/>
<Resource name="jdbc/jackrabbit" auth="Container" type="javax.sql.DataSource"
        factory="org.pentaho.di.core.database.util.DecryptingDataSourceFactory"
        maxActive="20" minIdle="0" maxIdle="5" initialSize="0" maxWait="10000"
        username="jcr_user" password="password" driverClassName="com.mysql.jdbc.Driver"
        url="jdbc:mysql://localhost:3306/jackrabbit" validationQuery="select 1"/>

打开 http://127.0.0.1:8080/pentaho，默认用户名密码：admin/password

查看 kettle job trans 运行状态：http://127.0.0.1:8080/pentaho/kettle/status

日志扩展：https://www.datamensional.com/setting-up-logging-tables-for-pdi-both-locally-and-on-server

6、其它

pentaho-solutions/system/applicationContext-spring-security-jdbc.properties

datasource.driver.classname=com.mysql.jdbc.Driver
datasource.url=jdbc:mysql://localhost:3306/hibernate
datasource.username=hibuser
datasource.password=password
datasource.validation.query=SELECT 1

View Code

pentaho-solutions/system/applicationContext-spring-security-hibernate.properties & pentaho-solutions/system/dialects/mysql5/applicationContext-spring-security-hibernate.properties

jdbc.driver=com.mysql.jdbc.Driver
jdbc.url=java:comp/env/jdbc/Hibernate
hibernate.dialect=org.hibernate.dialect.MySQL5InnoDBDialect

View Code

pentaho-solutions/system/simple-jndi/jdbc.properties

SampleData/type=javax.sql.DataSource
SampleData/driver=com.mysql.jdbc.Driver
SampleData/url=jdbc:mysql://localhost:3306/sampledata
SampleData/user=pentaho_user
SampleData/password=password
Hibernate/type=javax.sql.DataSource
Hibernate/driver=com.mysql.jdbc.Driver
Hibernate/url=jdbc:mysql://localhost:3306/hibernate
Hibernate/user=hibuser
Hibernate/password=password
Quartz/type=javax.sql.DataSource
Quartz/driver=com.mysql.jdbc.Driver
Quartz/url=jdbc:mysql://localhost:3306/quartz
Quartz/user=pentaho_user
Quartz/password=password
Shark/type=javax.sql.DataSource
Shark/driver=com.mysql.jdbc.Driver
Shark/url=jdbc:mysql://localhost:3306/shark
Shark/user=sa
Shark/password=
SampleDataAdmin/type=javax.sql.DataSource
SampleDataAdmin/driver=com.mysql.jdbc.Driver
SampleDataAdmin/url=jdbc:mysql://localhost:3306/sampledata
SampleDataAdmin/user=pentaho_admin
SampleDataAdmin/password=password

View Code

打开 pentaho-solutions/system/systemListeners.xml，注释以下配置

<!-- <bean id="pooledDataSourceSystemListener" class="org.pentaho.platform.engine.services.connection.datasource.dbcp.PooledDatasourceSystemListener"/> -->
<!-- <bean id="nonPooledDataSourceSystemListener" class="org.pentaho.platform.engine.services.connection.datasource.dbcp.NonPooledDatasourceSystemListener"/> -->
<!-- <bean id="dynamicallyPooledDataSourceSystemListener" class="org.pentaho.platform.engine.services.connection.datasource.dbcp.DynamicallyPooledDatasourceSystemListener"/> -->
<!-- <bean id="quartzSystemListener" class="org.pentaho.platform.scheduler2.quartz.EmbeddedQuartzSystemListener"/> -->

View Code

打开 tomcat/webapps/pentaho/WEB-INF/web.xml，注释以下配置

<!-- [BEGIN HSQLDB DATABASES] -->
<!-- <context-param> -->
  <!-- <param-name>hsqldb-databases</param-name> -->
  <!-- <param-value>sampledata@../../data/hsqldb/sampledata,hibernate@../../data/hsqldb/hibernate,quartz@../../data/hsqldb/quartz</param-value> -->
<!-- </context-param> -->
<!-- [END HSQLDB DATABASES] -->
<!-- [BEGIN HSQLDB STARTER] -->
<!-- <listener> -->
  <!-- <listener-class>org.pentaho.platform.web.http.context.HsqldbStartupListener</listener-class> -->
<!-- </listener> -->
<!-- [END HSQLDB STARTER] -->

View Code

打开 pentaho-solutions/system/GettingStartedDB-spring.xml & GettingStartedDB.properties，将 <bean> 标签的 init-method="start" 属性更改为 init-method=""

显式设置中文

打开 pentaho-solutions/system/server.properties

locale-language=zh
locale-country=CN

Windows 下控制台乱码，将编码改为 GBK

打开 tomcat/conf/logging.properties

java.util.logging.ConsoleHandler.encoding = GBK

打开 start-pentaho.bat

set CATALINA_OPTS=-Xms2048m -Xmx6144m -Dsun.rmi.dgc.client.gcInterval=3600000 -Dsun.rmi.dgc.server.gcInterval=3600000 -Dfile.encoding=GBK -Djava.locale.providers=COMPAT,SPI -DDI_HOME=%DI_HOME%
