The Famous Double-Check Locking Technique
The "Double-Checked Locking is Broken" Declaration
Signed by: David Bacon (IBM Research) Joshua Bloch (Javasoft), Jeff Bogda, Cliff Click (Hotspot JVM project), Paul Haahr, Doug Lea, Tom May, Jan-Willem Maessen, Jeremy Manson, John D. Mitchell (jGuru)Kelvin Nilsen, Bill Pugh, Emin Gun Sirer
Double-Checked Locking is widely cited and used as an efficient method for implementing lazy initialization in a multithreaded environment.
Unfortunately, it will not work reliably in a platform independent way when implemented in Java, without additional synchronization. When implemented in other languages, such as C++, it depends on the memory model of the processor, the reorderings performed by the compiler and the interaction between the compiler and the synchronization library. Since none of these are specified in a language such as C++, little can be said about the situations in which it will work. Explicit memory barriers can be used to make it work in C++, but these barriers are not available in Java.
To first explain the desired behavior, consider the following code:
// Single threaded version class Foo { private Helper helper = null; public Helper getHelper() { if (helper == null) helper = new Helper(); return helper; } // other functions and members... } |
If this code was used in a multithreaded context, many things could go wrong. Most obviously, two or more Helper objects could be allocated. (We'll bring up other problems later). The fix to this is simply to synchronize the getHelper() method:
// Correct multithreaded version class Foo { private Helper helper = null; public synchronized Helper getHelper() { if (helper == null) helper = new Helper(); return helper; } // other functions and members... } |
The code above performs synchronization every time getHelper() is called. The double-checked locking idiom tries to avoid synchronization after the helper is allocated:
// Broken multithreaded version // "Double-Checked Locking" idiom class Foo { private Helper helper = null; public Helper getHelper() { if (helper == null) synchronized(this) { if (helper == null) helper = new Helper(); } return helper; } // other functions and members... } |
Unfortunately, that code just does not work in the presence of either optimizing compilers or shared memory multiprocessors.
It doesn't work
There are lots of reasons it doesn't work. The first couple of reasons we'll describe are more obvious. After understanding those, you may be tempted to try to devise a way to "fix" the double-checked locking idiom. Your fixes will not work: there are more subtle reasons why your fix won't work. Understand those reasons, come up with a better fix, and it still won't work, because there are even more subtle reasons.
Lots of very smart people have spent lots of time looking at this. There is no way to make it work without requiring each thread that accesses the helper object to perform synchronization.
The first reason it doesn't work
The most obvious reason it doesn't work it that the writes that initialize the Helper object and the write to the helper field can be done or perceived out of order. Thus, a thread which invokes getHelper() could see a non-null reference to a helper object, but see the default values for fields of the helper object, rather than the values set in the constructor.
If the compiler inlines the call to the constructor, then the writes that initialize the object and the write to the helper field can be freely reordered if the compiler can prove that the constructor cannot throw an exception or perform synchronization.
Even if the compiler does not reorder those writes, on a multiprocessor the processor or the memory system may reorder those writes, as perceived by a thread running on another processor.
Doug Lea has written a more detailed description of compiler-based reorderings.
A test case showing that it doesn't work
Paul Jakubik found an example of a use of double-checked locking that did not work correctly. A slightly cleaned up version of that code is available here.
When run on a system using the Symantec JIT, it doesn't work. In particular, the Symantec JIT compiles
singletons[i].reference = new Singleton();
to the following (note that the Symantec JIT using a handle-based object allocation system).
0206106A mov eax,0F97E78h 0206106F call 01F6B210 ; allocate space for ; Singleton, return result in eax 02061074 mov dword ptr [ebp],eax ; EBP is &singletons[i].reference ; store the unconstructed object here. 02061077 mov ecx,dword ptr [eax] ; dereference the handle to ; get the raw pointer 02061079 mov dword ptr [ecx],100h ; Next 4 lines are 0206107F mov dword ptr [ecx+4],200h ; Singleton's inlined constructor 02061086 mov dword ptr [ecx+8],400h 0206108D mov dword ptr [ecx+0Ch],0F84030h
As you can see, the assignment to singletons[i].reference is performed before the constructor for Singleton is called. This is completely legal under the existing Java memory model, and also legal in C and C++ (since neither of them have a memory model).
A fix that doesn't work
Given the explanation above, a number of people have suggested the following code:
// (Still) Broken multithreaded version // "Double-Checked Locking" idiom class Foo { private Helper helper = null; public Helper getHelper() { if (helper == null) { Helper h; synchronized(this) { h = helper; if (h == null) synchronized (this) { h = new Helper(); } // release inner synchronization lock helper = h; } } return helper; } // other functions and members... } |
This code puts construction of the Helper object inside an inner synchronized block. The intuitive idea here is that there should be a memory barrier at the point where synchronization is released, and that should prevent the reordering of the initialization of the Helper object and the assignment to the field helper.
Unfortunately, that intuition is absolutely wrong. The rules for synchronization don't work that way. The rule for a monitorexit (i.e., releasing synchronization) is that actions before the monitorexit must be performed before the monitor is released. However, there is no rule which says that actions after the monitorexit may not be done before the monitor is released. It is perfectly reasonable and legal for the compiler to move the assignment helper = h; inside the synchronized block, in which case we are back where we were previously. Many processors offer instructions that perform this kind of one-way memory barrier. Changing the semantics to require releasing a lock to be a full memory barrier would have performance penalties.
More fixes that don't work
There is something you can do to force the writer to perform a full bidirectional memory barrier. This is gross, inefficient, and is almost guaranteed not to work once the Java Memory Model is revised. Do not use this. In the interests of science, I've put a description of this technique on a separate page. Do not use it.
However, even with a full memory barrier being performed by the thread that initializes the helper object, it still doesn't work.
The problem is that on some systems, the thread which sees a non-null value for the helper field also needs to perform memory barriers.
Why? Because processors have their own locally cached copies of memory. On some processors, unless the processor performs a cache coherence instruction (e.g., a memory barrier), reads can be performed out of stale locally cached copies, even if other processors used memory barriers to force their writes into global memory.
I've created a separate web page with a discussion of how this can actually happen on an Alpha processor.
Is it worth the trouble?
For most applications, the cost of simply making the getHelper() method synchronized is not high. You should only consider this kind of detailed optimizations if you know that it is causing a substantial overhead for an application.
Very often, more high level cleverness, such as using the builtin mergesort rather than handling exchange sort (see the SPECJVM DB benchmark) will have much more impact.
Making it work for static singletons
If the singleton you are creating is static (i.e., there will only be one Helper created), as opposed to a property of another object (e.g., there will be one Helper for each Foo object, there is a simple and elegant solution.
Just define the singleton as a static field in a separate class. The semantics of Java guarantee that the field will not be initialized until the field is referenced, and that any thread which accesses the field will see all of the writes resulting from initializing that field.
class HelperSingleton { static Helper singleton = new Helper(); } |
It will work for 32-bit primitive values
Although the double-checked locking idiom cannot be used for references to objects, it can work for 32-bit primitive values (e.g., int's or float's). Note that it does not work for long's or double's, since unsynchronized reads/writes of 64-bit primitives are not guaranteed to be atomic.
// Correct Double-Checked Locking for 32-bit primitives class Foo { private int cachedHashCode = 0; public int hashCode() { int h = cachedHashCode; if (h == 0) synchronized(this) { if (cachedHashCode != 0) return cachedHashCode; h = computeHashCode(); cachedHashCode = h; } return h; } // other functions and members... } |
In fact, assuming that the computeHashCode function always returned the same result and had no side effects (i.e., idempotent), you could even get rid of all of the synchronization.
// Lazy initialization 32-bit primitives // Thread-safe if computeHashCode is idempotent class Foo { private int cachedHashCode = 0; public int hashCode() { int h = cachedHashCode; if (h == 0) { h = computeHashCode(); cachedHashCode = h; } return h; } // other functions and members... } |
Making it work with explicit memory barriers
It is possible to make the double checked locking pattern work if you have explicit memory barrier instructions. For example, if you are programming in C++, you can use the code from Doug Schmidt et al.'s book:
// C++ implementation with explicit memory barriers // Should work on any platform, including DEC Alphas // From "Patterns for Concurrent and Distributed Objects", // by Doug Schmidt template <class TYPE, class LOCK> TYPE * Singleton<TYPE, LOCK>::instance (void) { // First check TYPE* tmp = instance_; // Insert the CPU-specific memory barrier instruction // to synchronize the cache lines on multi-processor. asm ("memoryBarrier"); if (tmp == 0) { // Ensure serialization (guard // constructor acquires lock_). Guard<LOCK> guard (lock_); // Double check. tmp = instance_; if (tmp == 0) { tmp = new TYPE; // Insert the CPU-specific memory barrier instruction // to synchronize the cache lines on multi-processor. asm ("memoryBarrier"); instance_ = tmp; } return tmp; } |
Fixing Double-Checked Locking using Thread Local Storage
Alexander Terekhov (TEREKHOV@de.ibm.com) came up clever suggestion for implementing double checked locking using thread local storage. Each thread keeps a thread local flag to determine whether that thread has done the required synchronization.
class Foo { /** If perThreadInstance.get() returns a non-null value, this thread has done synchronization needed to see initialization of helper */ private final ThreadLocal perThreadInstance = new ThreadLocal(); private Helper helper = null; public Helper getHelper() { if (perThreadInstance.get() == null) createHelper(); return helper; } private final void createHelper() { synchronized(this) { if (helper == null) helper = new Helper(); } // Any non-null value would do as the argument here perThreadInstance.set(perThreadInstance); } } |
The performance of this technique depends quite a bit on which JDK implementation you have. In Sun's 1.2 implementation, ThreadLocal's were very slow. They are significantly faster in 1.3, and are expected to be faster still in 1.4. Doug Lea analyzed the performance of some techniques for implementing lazy initialization.
Under the new Java Memory Model
As of JDK5, there is a new Java Memory Model and Thread specification.
Fixing Double-Checked Locking using Volatile
JDK5 and later extends the semantics for volatile so that the system will not allow a write of a volatile to be reordered with respect to any previous read or write, and a read of a volatile cannot be reordered with respect to any following read or write. See this entry in Jeremy Manson's blog for more details.
With this change, the Double-Checked Locking idiom can be made to work by declaring the helper field to be volatile. This does not work under JDK4 and earlier.
// Works with acquire/release semantics for volatile // Broken under current semantics for volatile class Foo { private volatile Helper helper = null; public Helper getHelper() { if (helper == null) { synchronized(this) { if (helper == null) helper = new Helper(); } } return helper; } } |
Double-Checked Locking Immutable Objects
If Helper is an immutable object, such that all of the fields of Helper are final, then double-checked locking will work without having to use volatile fields. The idea is that a reference to an immutable object (such as a String or an Integer) should behave in much the same way as an int or float; reading and writing references to immutable objects are atomic.
Descriptions of double-check idiom
- Reality Check, Douglas C. Schmidt, C++ Report, SIGS, Vol. 8, No. 3, March 1996.
- Double-Checked Locking: An Optimization Pattern for Efficiently Initializing and Accessing Thread-safe Objects, Douglas Schmidt and Tim Harrison. 3rd annual Pattern Languages of Program Design conference, 1996
- Lazy instantiation, Philip Bishop and Nigel Warren, JavaWorld Magazine
- Programming Java threads in the real world, Part 7, Allen Holub, Javaworld Magazine, April 1999.
- Java 2 Performance and Idiom Guide, Craig Larman and Rhett Guthrie, p100.
- Java in Practice: Design Styles and Idioms for Effective Java, Nigel Warren and Philip Bishop, p142.
- Rule 99, The Elements of Java Style, Allan Vermeulen, Scott Ambler, Greg Bumgardner, Eldon Metz, Trvor Misfeldt, Jim Shur, Patrick Thompson, SIGS Reference library
- Global Variables in Java with the Singleton Pattern, Wiebe de Jong, Gamelan
![](http://static.blog.csdn.net/images/category_icon.jpg)
版权声明:本文为博主原创文章,未经博主允许不得转载。
JAVA 单例双重检查(double check)为什么不好用
在阅读之前,请先了解下线程并发涉及到的三个概念:原子性、可见性、有序性,可以看下这篇文章:http://www.cnblogs.com/dolphin0520/p/3920373.html
我假设你已经看过几篇double check的文章,但还是一知半解。
我们先看这种双重检查,不加volatile
public static Singleton instance;
public static Singleton getInstance()
{
if (instance == null) //1
{ //2
synchronized(Singleton.class) { //3
if (instance == null) //4
instance = new Singleton(); //5
}
}
return instance;
}
这种方式存在什么问题呢?
也许有人说存在可见性问题:线程1执行完第5步,释放锁。线程2获得锁后执行到第4步,由于可见性的原因,发现instance还是null,从而初始化了两次。
但是不会存在这种情况,因为synchronized能保证线程1在释放锁之前会讲对变量的修改刷新到主存当中,线程2拿到的值是最新的。
实际存在的问题是无序性。
第5步这个new操作是无序的,它可能会被编译成:
- a. 先分配内存,让instance指向这块内存
- b. 在内存中创建对象
然而我们需要意识到这么一个问题,synchronized虽然是互斥的,但不代表一次就把整个过程执行完,它在中间是可能释放时间片的,时间片不是锁。(我因为这里没转过来,耽误了很多时间)
也就是说可能在a执行完后,时间片被释放,线程2执行到1,这时他读到的instance是不是null呢?(标记1)
基于可见性,可能是null,也可能不是null。
非常奇葩的是,在这个例子中,如果读到的是null,反而没问题了,接下来会等待锁,然后再次判断时不为null,最后返回单例。
如果读到的不是null,那么坏了,按逻辑它就直接return instance了,这个instance还没执行构造参数,去做事情的话,很可能就崩溃了。
加volatile
public volatile static Singleton instance;
public static Singleton getInstance()
{
if (instance == null) //1
{ //2
synchronized(Singleton.class) { //3
if (instance == null) //4
instance = new Singleton(); //5
}
}
return instance;
}
唯一的区别是加了volatile关键字,那么会有什么现象?
这时要区分jdk版本了,在jdk1.4及之前,volatile并不能保证new操作的有序性,但是它能保证可见性,因此标记1处,读到的不是null,导致了问题。
从1.5开始,加了volatile关键字的引用,它的初始化就不能是:
- a. 先分配内存,让instance指向这块内存
- b. 在内存中创建对象
而应该是:
- a.在内存中创建对象
- b.让instance指向这个对象.
这种形式,也就避免了无序性问题。
public class LazyInitDemo {
private volatile Helper helper = null;
public Helper getHelper() {
if (helper == null) { synchronized(this) {
if (helper == null) { helper = new Helper();
} }
}
return helper; }
// other methods and fields...
}
