在Foreda8中整合Apche httpd2.4.6和Tomcat7.0.42(使用tomcat-connectors-1.2.37)
本地Apche httpd2.4.6(http://pan.baidu.com/share/link?shareid=4003375081&uk=34256769)和Tomcat7.0.42是如何安装的,请参考前面的文章。
下面是具体整合的步骤。
首先需要得到mod_jk.so,它是apache到tomcat的连接器。
首先,将tomcat-connectors-1.2.37-src.tar.gz解压,可以到( http://pan.baidu.com/share/link?shareid=3998581769&uk=34256769 )下载。
#tar xvzf tomcat-connectors-1.2.37-src.tar.gz
之后得到tomcat-connectors-1.2.37-src目录,进入其中native目录,执行
[root@bogon native]# ./configure -with-apxs=/usr/local/apache2/bin/apxs
checking build system type... i686-pc-linux-gnu
checking host system type... i686-pc-linux-gnu
checking target system type... i686-pc-linux-gnu
checking for a BSD-compatible install... /usr/bin/install -c
checking whether build environment is sane... yes
checking for gawk... gawk
checking whether make sets $(MAKE)... yes
checking for test... /usr/bin/test
checking for grep... /bin/grep
checking for echo... /bin/echo
checking for sed... /bin/sed
checking for cp... /bin/cp
checking for mkdir... /bin/mkdir
need to check for Perl first, apxs depends on it...
checking for perl... /usr/bin/perl
APRINCLUDEDIR is -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1
building connector for "apache-2.0"
checking for gcc... gcc -std=gnu99
checking for C compiler default output file name... a.out
checking whether the C compiler works... yes
checking whether we are cross compiling... no
checking for suffix of executables...
checking for suffix of object files... o
checking whether we are using the GNU C compiler... yes
checking whether gcc -std=gnu99 accepts -g... yes
checking for gcc -std=gnu99 option to accept ANSI C... none needed
checking for style of include used by make... GNU
checking dependency style of gcc -std=gnu99... none
checking for a sed that does not truncate output... /bin/sed
checking for egrep... grep -E
checking for ld used by gcc -std=gnu99... /usr/bin/ld
checking if the linker (/usr/bin/ld) is GNU ld... yes
checking for /usr/bin/ld option to reload object files... -r
checking for BSD-compatible nm... /usr/bin/nm -B
checking whether ln -s works... yes
checking how to recognise dependent libraries... pass_all
checking how to run the C preprocessor... gcc -std=gnu99 -E
checking for ANSI C header files... yes
checking for sys/types.h... yes
checking for sys/stat.h... yes
checking for stdlib.h... yes
checking for string.h... yes
checking for memory.h... yes
checking for strings.h... yes
checking for inttypes.h... yes
checking for stdint.h... yes
checking for unistd.h... yes
checking dlfcn.h usability... yes
checking dlfcn.h presence... yes
checking for dlfcn.h... yes
checking for g++... g++
checking whether we are using the GNU C++ compiler... yes
checking whether g++ accepts -g... yes
checking dependency style of g++... none
checking how to run the C++ preprocessor... g++ -E
checking for g77... no
checking for f77... no
checking for xlf... no
checking for frt... no
checking for pgf77... no
checking for fort77... no
checking for fl32... no
checking for af77... no
checking for f90... no
checking for xlf90... no
checking for pgf90... no
checking for epcf90... no
checking for f95... f95
checking whether we are using the GNU Fortran 77 compiler... yes
checking whether f95 accepts -g... yes
checking the maximum length of command line arguments... 32768
checking command to parse /usr/bin/nm -B output from gcc -std=gnu99 object... ok
checking for objdir... .libs
checking for ar... ar
checking for ranlib... ranlib
checking for strip... strip
checking if gcc -std=gnu99 static flag works... yes
checking if gcc -std=gnu99 supports -fno-rtti -fno-exceptions... no
checking for gcc -std=gnu99 option to produce PIC... -fPIC
checking if gcc -std=gnu99 PIC flag -fPIC works... yes
checking if gcc -std=gnu99 supports -c -o file.o... yes
checking whether the gcc -std=gnu99 linker (/usr/bin/ld) supports shared libraries... yes
checking whether -lc should be explicitly linked in... no
checking dynamic linker characteristics... GNU/Linux ld.so
checking how to hardcode library paths into programs... immediate
checking whether stripping libraries is possible... yes
checking for shl_load... no
checking for shl_load in -ldld... no
checking for dlopen... no
checking for dlopen in -ldl... yes
checking whether a program can dlopen itself... yes
checking whether a statically linked program can dlopen itself... yes
checking if libtool supports shared libraries... yes
checking whether to build shared libraries... yes
checking whether to build static libraries... yes
configure: creating libtool
appending configuration tag "CXX" to libtool
checking for ld used by g++... /usr/bin/ld
checking if the linker (/usr/bin/ld) is GNU ld... yes
checking whether the g++ linker (/usr/bin/ld) supports shared libraries... yes
checking for g++ option to produce PIC... -fPIC
checking if g++ PIC flag -fPIC works... yes
checking if g++ supports -c -o file.o... yes
checking whether the g++ linker (/usr/bin/ld) supports shared libraries... yes
checking dynamic linker characteristics... GNU/Linux ld.so
checking how to hardcode library paths into programs... immediate
checking whether stripping libraries is possible... yes
checking for shl_load... (cached) no
checking for shl_load in -ldld... (cached) no
checking for dlopen... (cached) no
checking for dlopen in -ldl... (cached) yes
checking whether a program can dlopen itself... (cached) yes
checking whether a statically linked program can dlopen itself... (cached) yes
appending configuration tag "F77" to libtool
checking if libtool supports shared libraries... yes
checking whether to build shared libraries... yes
checking whether to build static libraries... yes
checking for f95 option to produce PIC... -fPIC
checking if f95 PIC flag -fPIC works... yes
checking if f95 supports -c -o file.o... yes
checking whether the f95 linker (/usr/bin/ld) supports shared libraries... yes
checking dynamic linker characteristics... GNU/Linux ld.so
checking how to hardcode library paths into programs... immediate
checking whether stripping libraries is possible... yes
LIBTOOL="/usr/local/apr/build-1/libtool --silent"
checking for char... yes
checking size of char... 1
checking for int... yes
checking size of int... 4
checking for long... yes
checking size of long... 4
checking for short... yes
checking size of short... 2
checking for long double... yes
checking size of long double... 12
checking for long long... yes
checking size of long long... 8
checking for longlong... no
checking size of longlong... 0
checking size of pid_t... 4
checking size of pthread_t... 4
checking for snprintf... yes
checking for vsnprintf... yes
checking for flock... yes
checking for setsockopt in -lsocket... no
checking sys/filio.h usability... no
checking sys/filio.h presence... no
checking for sys/filio.h... no
checking whether to use SO_RCVTIMEO with setsockopt()... yes
checking whether to use SO_SNDTIMEO with setsockopt()... yes
checking whether to use SOCK_CLOEXEC with socket()... no
checking poll.h usability... yes
checking poll.h presence... yes
checking for poll.h... yes
checking for poll... yes
checking for target platform... unix
no apache given
no netscape given
configure: creating ./config.status
config.status: creating Makefile
config.status: creating apache-1.3/Makefile
config.status: creating apache-1.3/Makefile.apxs
config.status: creating apache-2.0/Makefile
config.status: creating apache-2.0/Makefile.apxs
config.status: creating common/Makefile
config.status: creating common/list.mk
config.status: creating common/jk_types.h
config.status: creating common/config.h
config.status: executing depfiles commands
注意上面粗体部分是指向本机Apche的bin中的apxs文件的,这个参数要根据各人机器实际配置调整,不可盲目照搬。
接下来。再执行make
[root@bogon native]# make
Making all in common
make[1]: Entering directory `/home/hy/tomcat-connectors-1.2.37-src/native/common'
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_ajp12_worker.c -o jk_ajp12_worker.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_connect.c -o jk_connect.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_msg_buff.c -o jk_msg_buff.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_util.c -o jk_util.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_ajp13.c -o jk_ajp13.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_pool.c -o jk_pool.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_worker.c -o jk_worker.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_ajp13_worker.c -o jk_ajp13_worker.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_lb_worker.c -o jk_lb_worker.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_sockbuf.c -o jk_sockbuf.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_map.c -o jk_map.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_uri_worker_map.c -o jk_uri_worker_map.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_ajp14.c -o jk_ajp14.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_ajp14_worker.c -o jk_ajp14_worker.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_md5.c -o jk_md5.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_shm.c -o jk_shm.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_ajp_common.c -o jk_ajp_common.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_context.c -o jk_context.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_url.c -o jk_url.lo
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c jk_status.c -o jk_status.lo
make[1]: Leaving directory `/home/hy/tomcat-connectors-1.2.37-src/native/common'
Making all in apache-2.0
make[1]: Entering directory `/home/hy/tomcat-connectors-1.2.37-src/native/apache-2.0'
/usr/local/apr/build-1/libtool --silent --mode=compile gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -DUSE_APACHE_MD5 -I ../common -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -g -O2 -pthread -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -c mod_jk.c -o mod_jk.lo
/usr/local/apr/build-1/libtool --silent --mode=link gcc -std=gnu99 -I/usr/local/apache2/include -DHAVE_CONFIG_H -DUSE_APACHE_MD5 -I ../common -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -g -O2 -pthread -DHAVE_APR -I/usr/local/apr/include/apr-1 -I/usr/local/apr/include/apr-1 -DHAVE_CONFIG_H -g -O2 -pthread -DLINUX=2 -D_REENTRANT -D_GNU_SOURCE -D_LARGEFILE64_SOURCE -o mod_jk.la -module -rpath /usr/local/apache2/modules -avoid-version mod_jk.lo ../common/jk_ajp12_worker.lo ../common/jk_connect.lo ../common/jk_msg_buff.lo ../common/jk_util.lo ../common/jk_ajp13.lo ../common/jk_pool.lo ../common/jk_worker.lo ../common/jk_ajp13_worker.lo ../common/jk_lb_worker.lo ../common/jk_sockbuf.lo ../common/jk_map.lo ../common/jk_uri_worker_map.lo ../common/jk_ajp14.lo ../common/jk_ajp14_worker.lo ../common/jk_md5.lo ../common/jk_shm.lo ../common/jk_ajp_common.lo ../common/jk_context.lo ../common/jk_url.lo ../common/jk_status.lo
../scripts/build/instdso.sh SH_LIBTOOL='/usr/local/apr/build-1/libtool --silent' mod_jk.la `pwd`
/usr/local/apr/build-1/libtool --silent --mode=install cp mod_jk.la /home/hy/tomcat-connectors-1.2.37-src/native/apache-2.0/
libtool: install: warning: remember to run `libtool --finish /usr/local/apache2/modules'
make[1]: Leaving directory `/home/hy/tomcat-connectors-1.2.37-src/native/apache-2.0'
make[1]: Entering directory `/home/hy/tomcat-connectors-1.2.37-src/native'
make[1]: Nothing to be done for `all-am'.
make[1]: Leaving directory `/home/hy/tomcat-connectors-1.2.37-src/native'
target="all"; \
list='common apache-2.0'; \
for i in target in i" != "."; then \
(cd target) || exit 1; \
fi; \
done;
Making all in common
make[1]: Entering directory `/home/hy/tomcat-connectors-1.2.37-src/native/common'
make[1]: Nothing to be done for `all'.
make[1]: Leaving directory `/home/hy/tomcat-connectors-1.2.37-src/native/common'
Making all in apache-2.0
make[1]: Entering directory `/home/hy/tomcat-connectors-1.2.37-src/native/apache-2.0'
make[1]: Nothing to be done for `all'.
make[1]: Leaving directory `/home/hy/tomcat-connectors-1.2.37-src/native/apache-2.0'
完成以后,进入apache-2.0目录,就能发现我们需要的目标文件
[root@bogon native]# cd apache-2.0/
[root@bogon apache-2.0]# ls
bldjk54.qclsrc Makefile.apxs mod_jk.a mod_jk.lo
bldjk.qclsrc Makefile.apxs.in mod_jk.c mod_jk.o
config.m4 Makefile.in mod_jk.dsp mod_jk.so
Makefile Makefile.vc mod_jk.la NWGNUmakefile
这个文件就是Apache和Tomcat的连接器,我们需要把它拷贝到apache的modules目录去。
[root@bogon apache-2.0]# cp mod_jk.so /usr/local/apache2/modules/
cp: overwrite `/usr/local/apache2/modules/mod_jk.so'? y
上面覆写的原因是原有一个不正确的mod_jk.so,这次用生成的文件覆盖掉。如果原来没有则直接拷贝不会有输出。
再接下里,要修改apache的conf文件了。
打开/usr/local/apache2/conf/httpd.conf,在末尾增加这样一段:
...
LoadModule jk_module modules/mod_jk.so
JkWorkersFile conf/workers.properties
JkLogFile logs/mod_jk.log
JkLogLevel debug
JkMount /*.jsp worker1
保存退出后,在同一目录下新增文件workers.properties,其内容如下:
worker.list=worker1
worker.worker1.port=8009
worker.worker1.host=localhost
worker.worker1.type=ajp13
worker.worker1.lbfactor=1
之后执行拷贝文件,之所以要这样做是因为将/usr/local/httpd/conf/httpd.conf和/usr/local/apache2/conf/httpd.conf保持一致。
[root@bogon conf]# cp httpd.conf /usr/local/httpd/conf/
cp: overwrite `/usr/local/httpd/conf/httpd.conf'? y
到这里,配置工作就完成了,我们需要重启httpd服务和启动Tomcat
重启httpd
[root@bogon conf]# service httpd stop
AH00557: httpd: apr_sockaddr_info_get() failed for bogon
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 127.0.0.1. Set the 'ServerName' directive globally to suppress this message
[root@bogon conf]# service httpd start
AH00557: httpd: apr_sockaddr_info_get() failed for bogon
AH00558: httpd: Could not reliably determine the server's fully qualified domain name, using 127.0.0.1. Set the 'ServerName' directive globally to suppress this message
启动Tomcat
[root@bogon apache-2.0]# cd /usr/local/tomcat7.0.42/
[root@bogon tomcat7.0.42]# ls
bin lib logs RELEASE-NOTES temp work
conf LICENSE NOTICE RUNNING.txt webapps
[root@bogon tomcat7.0.42]# cd bin
[root@bogon bin]# ls
bootstrap.jar cpappend.bat startup.bat
catalina.bat daemon.sh startup.sh
catalina.sh digest.bat tomcat-juli.jar
catalina-tasks.xml digest.sh tomcat-native.tar.gz
commons-daemon.jar setclasspath.bat tool-wrapper.bat
commons-daemon-native.tar.gz setclasspath.sh tool-wrapper.sh
configtest.bat shutdown.bat version.bat
configtest.sh shutdown.sh version.sh
[root@bogon bin]# ./startup.sh
Using CATALINA_BASE: /usr/local/tomcat7.0.42
Using CATALINA_HOME: /usr/local/tomcat7.0.42
Using CATALINA_TMPDIR: /usr/local/tomcat7.0.42/temp
Using JRE_HOME: /usr/java/jdk1.7.0_25
Using CLASSPATH: /usr/local/tomcat7.0.42/bin/bootstrap.jar:/usr/local/tomcat7.0.42/bin/tomcat-juli.jar
[root@bogon bin]#
最后来检验一下,首先看Tomcat自带的网页,网址是:http://192.168.0.104:8080/examples/jsp/jsp2/el/basic-arithmetic.jsp
再让我们访问80端口看看,网址是:http://192.168.0.104/examples/jsp/jsp2/el/basic-arithmetic.jsp
两个URL中,端口一个是8080,一个是80,但结果是一致的,这说明Apache到Tomcat的连接完全成功了。
<全文完,有问题请指出,谢谢!>
【推荐】国内首个AI IDE,深度理解中文开发场景,立即下载体验Trae
【推荐】编程新体验,更懂你的AI,立即体验豆包MarsCode编程助手
【推荐】抖音旗下AI助手豆包,你的智能百科全书,全免费不限次数
【推荐】轻量又高性能的 SSH 工具 IShell:AI 加持,快人一步
· Linux系列:如何用heaptrack跟踪.NET程序的非托管内存泄露
· 开发者必知的日志记录最佳实践
· SQL Server 2025 AI相关能力初探
· Linux系列:如何用 C#调用 C方法造成内存泄露
· AI与.NET技术实操系列(二):开始使用ML.NET
· 无需6万激活码!GitHub神秘组织3小时极速复刻Manus,手把手教你使用OpenManus搭建本
· C#/.NET/.NET Core优秀项目和框架2025年2月简报
· Manus爆火,是硬核还是营销?
· 终于写完轮子一部分:tcp代理 了,记录一下
· 【杭电多校比赛记录】2025“钉耙编程”中国大学生算法设计春季联赛(1)
