递归向下解析算术表达式(三)

本例代码下载:https://files.cnblogs.com/files/heyang78/MathAnalyzer2-20200524-1.zip

较原有版本,是多了Node类和TreeBuilder类,二者用于构建表达式树:

Node类:

package com.heyang;

public class Node {
    private String text;
    private Node leftChild;
    private Node rightChild;

    public Node() {
        this("");
    }

    public Node(String text) {
        this.text=text;
    }

    public String getText() {
        return text;
    }
    public void setText(String text) {
        this.text = text;
    }
    public Node getLeftChild() {
        return leftChild;
    }
    public void setLeftChild(Node leftChild) {
        this.leftChild = leftChild;
    }
    public Node getRightChild() {
        return rightChild;
    }
    public void setRightChild(Node rightChild) {
        this.rightChild = rightChild;
    }
}

TreeBuilder类:

package com.heyang;

import java.util.List;

public class TreeBuilder {
    private List<Token> tokens;
    private int tokenIdx;
    private Node root;

    public TreeBuilder(List<Token> tokens)  throws AnalyzerExp{
        this.tokens=tokens;
        this.tokenIdx=0;

        root=parse_expression();
    }

    public Node getRoot() {
        return root;
    }

    private Token fetchToken() {
        if(tokenIdx>=tokens.size()) {
            return null;
        }else {
            Token t=tokens.get(tokenIdx);
            tokenIdx++;
            return t;
        }
    }

    private void returnToken() {
        if(tokenIdx>0) {
            tokenIdx--;
        }
    }

    private Node parse_expression() throws AnalyzerExp{
        Node left,right;
        Token currentToken;

        left=parse_term();
        for(;;) {
            currentToken=fetchToken();
            if(currentToken==null) {
                return left;
            }

            if(currentToken.getType()!=Token.TYPE_PLUS && currentToken.getType()!=Token.TYPE_MINUS) {
                returnToken();
                break;
            }

            right=parse_term();

            Node plusMinusNode=new Node(currentToken.getText());
            plusMinusNode.setLeftChild(left);
            plusMinusNode.setRightChild(right);
            left=plusMinusNode;
        }

        return left;
    }

    private Node parse_term() throws AnalyzerExp{
        Node left,right;
        Token currentToken;

        left=parse_primary_exp();
        for(;;) {
            currentToken=fetchToken();
            if(currentToken==null) {
                return left;
            }

            if(currentToken.getType()!=Token.TYPE_MULTI && currentToken.getType()!=Token.TYPE_DIVIDE) {
                returnToken();
                break;
            }

            right=parse_primary_exp();

            Node multiDivideNode=new Node(currentToken.getText());
            multiDivideNode.setLeftChild(left);
            multiDivideNode.setRightChild(right);
            left= multiDivideNode;
        }

        return left;
    }

    private Node parse_primary_exp() throws AnalyzerExp{
        Token currToken;

        currToken=fetchToken();
        if(currToken==null) {
            return null;
        }

        if(currToken.getType()==Token.TYPE_DIGITAL) {
            return new Node(currToken.getText());
        }else if(currToken.getType()==Token.TYPE_LEFT_PAREN){
            Node retval=parse_expression();

            currToken=fetchToken();
            if(currToken==null) {
                return retval;
            }

            if(currToken.getType()!=Token.TYPE_RIGHT_PAREN) {
                throw new AnalyzerExp("missing )");
            }

            return retval;
        }else {
            throw new AnalyzerExp(currToken+" should be a digital.");
        }
    }
}

解析效果:

1+2+3=6.0
      +
    /   \
  +       3
 / \
1   2
1+2+3+4=10.0
            +
         /     \
      +           4
    /   \
  +       3
 / \
1   2
1+2+3+4+5=15.0
                        +
                    /       \
                +               5
             /     \
          +           4
        /   \
      +       3
     / \
    1   2
1+(2+3)*4=21.0
            +
         /     \
      1           *
                /   \
              +       4
             / \
            2   3
1+(2+3)*4+5=26.0
                        +
                    /       \
                +               5
             /     \
          1           *
                    /   \
                  +       4
                 / \
                2   3

--2020年5月24日--
