java: swing 写一个简单的Multi Document Interface (MDI)



?

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169

/**  * encoding: utf-8  * 版权所有 2025 涂聚文有限公司  * 许可信息查看：言語成了邀功盡責的功臣，還需要行爲每日來值班嗎  * 描述：  * # Author    : geovindu,Geovin Du 涂聚文.  * # IDE       : IntelliJ IDEA 2023.1 Java 17  * # Datetime  : 2025 - 2025/2/8 - 22:36  * # User      : geovindu  * # Product   : IntelliJ IDEA  * # Project   : javaWeather  * # File      : MDIApplication.java  类  * # explain   : 学习  **/   package UI; import javax.swing.*; import java.awt.event.ActionEvent; import java.awt.event.ActionListener;   /**  *主窗口：  */ public class MDIApplication extends JFrame {       /**      * 用于承载子窗口的桌面面板      */     private JDesktopPane desktopPane; //       /**      * 设置窗口      */     public MDIApplication() {           // 设置窗口标题         setTitle("Multi Document Interface (MDI) 示例");         setSize(800, 600); // 设置窗口大小         setDefaultCloseOperation(JFrame.EXIT_ON_CLOSE); // 关闭窗口时退出程序         setLocationRelativeTo(null); // 窗口居中           // 创建桌面面板         desktopPane = new JDesktopPane();         setContentPane(desktopPane);           // 创建菜单栏         createMenuBar();           // 显示窗口         setVisible(true);     }       /**      * 创建菜单栏      */     private void createMenuBar() {         JMenuBar menuBar = new JMenuBar();           // 文件菜单         JMenu fileMenu = new JMenu("文件");         JMenuItem newWindowItem = new JMenuItem("新建子窗口");         JMenuItem exitItem = new JMenuItem("退出");           // 新建子窗口菜单项的事件监听器         newWindowItem.addActionListener(new ActionListener() {             @Override             public void actionPerformed(ActionEvent e) {                 createInternalFrame();             }         });           // 退出菜单项的事件监听器         exitItem.addActionListener(new ActionListener() {             @Override             public void actionPerformed(ActionEvent e) {                 System.exit(0);             }         });           fileMenu.add(newWindowItem);         fileMenu.addSeparator(); // 添加分隔线         fileMenu.add(exitItem);           // 窗口菜单         JMenu windowMenu = new JMenu("窗口");         JMenuItem cascadeItem = new JMenuItem("层叠");         JMenuItem tileItem = new JMenuItem("平铺");           // 层叠子窗口菜单项的事件监听器         cascadeItem.addActionListener(new ActionListener() {             @Override             public void actionPerformed(ActionEvent e) {                 cascadeInternalFrames();             }         });           // 平铺子窗口菜单项的事件监听器         tileItem.addActionListener(new ActionListener() {             @Override             public void actionPerformed(ActionEvent e) {                 tileInternalFrames();             }         });           windowMenu.add(cascadeItem);         windowMenu.add(tileItem);           // 将菜单添加到菜单栏         menuBar.add(fileMenu);         menuBar.add(windowMenu);           // 设置菜单栏         setJMenuBar(menuBar);     }       /**      * 创建子窗口      */     private void createInternalFrame() {         JInternalFrame internalFrame = new JInternalFrame("子窗口 " + (desktopPane.getAllFrames().length + 1),                 true, true, true, true);         internalFrame.setSize(300, 200);         internalFrame.setLocation(desktopPane.getAllFrames().length * 20, desktopPane.getAllFrames().length * 20);         internalFrame.setVisible(true);           // 将子窗口添加到桌面面板         desktopPane.add(internalFrame);     }       /**      * 层叠子窗口      */     private void cascadeInternalFrames() {         JInternalFrame[] frames = desktopPane.getAllFrames();         int x = 0;         int y = 0;         for (JInternalFrame frame : frames) {             frame.setLocation(x, y);             x += 20;             y += 20;         }     }       /**      * 平铺子窗口      */     private void tileInternalFrames() {         JInternalFrame[] frames = desktopPane.getAllFrames();         if (frames.length == 0) return;           int rows = (int) Math.sqrt(frames.length);         int cols = (int) Math.ceil((double) frames.length / rows);         int width = desktopPane.getWidth() / cols;         int height = desktopPane.getHeight() / rows;           int x = 0;         int y = 0;         for (JInternalFrame frame : frames) {             frame.setSize(width, height);             frame.setLocation(x, y);             x += width;             if (x >= desktopPane.getWidth()) {                 x = 0;                 y += height;             }         }     }   }

　　

调用：

?

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19

import UI.MDIApplication;; import java.awt.*; import javax.swing.*;     public class Main {     public static void main(String[] args) {             // 在事件调度线程中创建和显示 GUI         SwingUtilities.invokeLater(new Runnable() {             @Override             public void run() {                 //new TextSaverGUI();                 new MDIApplication();             }         }); } }
