bes 宏定义

config目录
该文件夹中存放基础差异化配置
target.mk文件中主要是宏定义的开关, 包含 DEBUG 信息开关、差分/单端输出、默认音量大小、音乐 EQ 开关、通话算法的开关等.
tgt_hardware.c和 tgt_hardware.h文件中存放基础配置, 如按键、LED灯、蓝牙默认信息、音量表、EQ 参数、ANC 默认参数等.

https://blog.csdn.net/ccdehuiji/article/details/131031792

target.mk：



查看代码

CHIP        ?= best1501

DEBUG       ?= 1

FPGA        ?= 0

RTOS        ?= 1

# LIBC_ROM    ?= 1

export LIBC_OVERRIDE := 1

#KERNEL      ?= RTX5

VERSION_INFO ?= best2500p_ibrt

export FREEMAN_FOR_EP ?= 0
ifeq ($(FREEMAN_FOR_EP),1)
KBUILD_CPPFLAGS += -D__FREEMAN_FOR_EP__
endif

ifeq ($(KERNEL), NUTTX)
export ALLOW_WARNING := 1
export NO_LIBC := 1
export NUTTX_BUILD :=1
export RTC_ENABLE := 1
export NUTTX_BLE_BRIDGE_MODE ?= 0
export RAMCP_SIZE := 0x0
KBUILD_CPPFLAGS += -DRAMCP_SIZE=$(RAMCP_SIZE)
KBUILD_CPPFLAGS += -DRAMCPX_SIZE=$(RAMCP_SIZE)

KBUILD_CFLAGS += -DPWR_KEY_AS_SYS_RQ_KEY -DNUTTX_SERIAL_CONSOLE

ifeq ($(RTC_ENABLE),1)
KBUILD_CPPFLAGS += -DCHIP_HAS_DIG_RTC -DRTC_BASE=0
endif
ifeq ($(NUTTX_BLE_BRIDGE_MODE),1)
KBUILD_CFLAGS += -DNUTTX_BLE_BRIDGE_MODE
endif
endif

export USER_SECURE_BOOT	?= 0
# enable:1
# disable:0

WATCHER_DOG ?= 1

DEBUG_PORT  ?= 1
# 0: usb
# 1: uart0
# 2: uart1

FLASH_CHIP	?= ALL
# GD25Q80C
# GD25Q32C
# ALL

export FUZZ_TEST_SUPPORT ?= 0

export SNYC_FOUND_CHECK_HECERROR ?= 1

export RF_INIT_XTAL_CAP_FROM_NV ?= 1

export BLE_EXT_ADV_TX_PWR_INDEPEND ?= 0

export BT_BLE_USING_SAME_TX_LEVEL ?= 0

export TX_PWR_LOWER_2DBM ?= 0

export AFH_ASSESS ?= 0

export BT_RAMRUN ?= 0

export HW_AGC ?= 0

export NEW_SWAGC_MODE ?= 1

export BLE_NEW_SWAGC_MODE ?= 0

export BT_LOG_POWEROFF ?= 0

export BT_INFO_CHECKER ?= 1

export BT_TEST_CURRENT_KEY ?= 0

export BT_UART_LOG_P16 ?= 0

export BT_UART_LOG ?= 0

export BT_SYSTEM_52M ?= 0

export BES_FA_MODE ?= 0

export LL_MONITOR ?= 0

export SOFTBIT_EN ?= 0

export ACL_DATA_CRC_TEST ?= 0

export FORCE_SIGNALINGMODE ?= 0

export FORCE_NOSIGNALINGMODE ?= 0

export BT_FA_ECC ?= 1

ifeq ($(BT_FA_ECC),1)
export BT_FA_SCO_ECC ?= 0
export BT_FA_ACL_ECC ?= 1
endif

export BT_ECC_CONFIG_BLK ?= 3

export BT_BID_ECC_EN ?= 0

export BT_FAST_LOCK_ENABLE ?= 0

export IBRT_TESTMODE ?= 0

export CONTROLLER_DUMP_ENABLE ?= 1

export CONTROLLER_MEM_LOG_ENABLE ?= 0

export INTERSYS_DEBUG ?= 1

export PROFILE_DEBUG ?= 0

export BTDUMP_ENABLE ?= 0

# this is used for SLT test only.
export SLT_TEST_ON ?= 0
ifeq ($(SLT_TEST_ON),1)
export BT_DEBUG_TPORTS ?= 1
NO_PWRKEY ?= 1
POWER_ON_ENTER_TWS_PAIRING_ENABLED ?= 1

KBUILD_CPPFLAGS += -DSLT_TEST_ON
KBUILD_CPPFLAGS += -D__POWERKEY_CTRL_ONOFF_ONLY__
else
export BT_DEBUG_TPORTS ?= 0
endif

export TPORTS_KEY_COEXIST ?= 0

export BT_SIGNALTEST_SLEEP_EN ?= 0

export PATCH_SYMBOL_DIR ?= $(srctree)/platform/drivers/bt/best2300a

export LD_USE_PATCH_SYMBOL ?= -Wl,--just-symbols=$(PATCH_SYMBOL_DIR)/patch_symbol_parsed.txt -Wl,--just-symbols=$(PATCH_SYMBOL_DIR)/patch_symbol_parsed_testmode.txt

export DISPLAY_PREFIX_HCI_CMD_EVT_ ?= 0

AUDIO_OUTPUT_MONO ?= 0

AUDIO_OUTPUT_DIFF ?= 0

HW_FIR_EQ_PROCESS ?= 0

SW_IIR_EQ_PROCESS ?= 0

SW_IIR_PROMPT_EQ_PROCESS ?= 0

HW_DAC_IIR_EQ_PROCESS ?= 1

HW_IIR_EQ_PROCESS ?= 0

HW_DC_FILTER_WITH_IIR ?= 0

AUDIO_DRC ?= 0

AUDIO_LIMITER ?= 0


AUDIO_HEARING_COMPSATN ?= 0
ifeq ($(AUDIO_HEARING_COMPSATN),1)
APP_TRACE_RX_ENABLE := 1
HEARING_MOD ?= HWIIR
endif
# HWFIR
# SWIIR
# HWIIR

PC_CMD_UART ?= 0

TOTA_EQ_TUNING ?= 0

AUDIO_SECTION_ENABLE ?= 0

AUDIO_RESAMPLE ?= 1

RESAMPLE_ANY_SAMPLE_RATE ?= 1

OSC_26M_X4_AUD2BB ?= 1

SYSTEM_FREQ_208M ?= 208
#SKYWALKER_CALL_SYSFREQ_208M ?= 208
#SKYWALKER_MUSIC_SYSFREQ_208M ?= 147

export CP_CPU_USAGE_INTVL_MS ?= 10000

AUDIO_OUTPUT_VOLUME_DEFAULT ?= 16
# range:1~16

CODEC_DAC_MULTI_VOLUME_TABLE ?= 0

AUDIO_INPUT_CAPLESSMODE ?= 0

AUDIO_INPUT_LARGEGAIN ?= 0

AUDIO_CODEC_ASYNC_CLOSE ?= 0

AUDIO_SCO_BTPCM_CHANNEL ?= 1

export A2DP_CP_ACCEL ?= 1

export SCO_CP_ACCEL ?= 1

export SCO_TRACE_CP_ACCEL ?= 0

# For TWS SCO DMA snapshot and low delay
export PCM_FAST_MODE ?= 1

export PCM_PRIVATE_DATA_FLAG ?= 0

export CVSD_BYPASS ?= 1

export LOW_DELAY_SCO ?= 0

export SPEECH_TX_24BIT ?= 0

SPEECH_BONE_SENSOR ?= 0

SPEECH_TX_DC_FILTER ?= 1

SPEECH_TX_AEC2FLOAT ?= 1

SPEECH_TX_NS3 ?= 0

SPEECH_TX_2MIC_NS2 ?= 0

SPEECH_TX_COMPEXP ?= 1

SPEECH_TX_EQ ?= 0

SPEECH_TX_POST_GAIN ?= 0

SPEECH_RX_NS2FLOAT ?= 0

SPEECH_RX_EQ ?= 0

SPEECH_RX_POST_GAIN ?= 0

LARGE_RAM ?= 1

HSP_ENABLE ?= 0

SBC_FUNC_IN_ROM ?= 0

ROM_UTILS_ON ?= 0

APP_LINEIN_A2DP_SOURCE ?= 0

APP_I2S_A2DP_SOURCE ?= 0

VOICE_PROMPT ?= 1

TWS_PROMPT_SYNC ?= 1

REPORT_CONNECTIVITY_LOG ?= 0

# TOTA1: old tota, TOTA2: new tota(debuging)
export TOTA ?= 0
export TOTA_v2 ?= 0

ifeq ($(TOTA_v2),1)
export TOTA := 0
endif

export APP_RSSI ?=0
ifeq ($(APP_RSSI),1)
export TOTA_v2 := 1
KBUILD_CPPFLAGS += -DGET_PEER_RSSI_ENABLE
endif

GATT_OVER_BR_EDR ?= 0

BES_OTA ?= 0

TILE_DATAPATH_ENABLED ?= 0

CUSTOM_INFORMATION_TILE_ENABLE ?= 0

INTERCONNECTION ?= 0

INTERACTION ?= 0

INTERACTION_FASTPAIR ?= 0

SWIFT_ENABLE ?= 0

BT_ONE_BRING_TWO ?= 1

DSD_SUPPORT ?= 0

A2DP_EQ_24BIT ?= 1

A2DP_AAC_ON ?= 1

A2DP_SCALABLE_ON ?= 0

A2DP_LHDC_ON ?= 0

ifeq ($(A2DP_LHDC_ON),1)
A2DP_LHDC_V3 ?= 1
export FLASH_UNIQUE_ID ?= 1
endif

A2DP_LDAC_ON ?= 0

export A2DP_LC3_ON ?= 0

export TX_RX_PCM_MASK ?= 0

FACTORY_MODE ?= 1

ENGINEER_MODE ?= 1

ULTRA_LOW_POWER	?= 1

DAC_CLASSG_ENABLE ?= 1

NO_SLEEP ?= 0

CORE_DUMP ?= 1

CORE_DUMP_TO_FLASH ?= 0

RAM_DUMP_TO_FLASH ?= 0

export SYNC_BT_CTLR_PROFILE ?= 0

export A2DP_AVDTP_CP ?= 0

export A2DP_DECODER_VER := 2

export IS_USE_MIXING_FRQ_FOR_A2DP_STREAMING ?=0
export HIGH_EFFICIENCY_TX_PWR_CTRL ?=0
export DCDC_HIGH_EFFICIENCY_CTRL ?=0
export BT_SBC_PLAY_DEFAULT_FREQ ?= 0

ifeq ($(BT_SBC_PLAY_DEFAULT_FREQ),2)
export HIGH_EFFICIENCY_TX_PWR_CTRL :=1
export DCDC_HIGH_EFFICIENCY_CTRL :=1
endif
ifneq ($(BT_SBC_PLAY_DEFAULT_FREQ), )
    KBUILD_CPPFLAGS += -DBT_SBC_PLAY_DEFAULT_FREQ=$(BT_SBC_PLAY_DEFAULT_FREQ)
endif


export IBRT ?= 1

export SEARCH_UI_COMPATIBLE_UI_V2 ?= 0

export IBRT_UI_V1 ?= 0
ifeq ($(IBRT_UI_V1),1)
KBUILD_CPPFLAGS += -DIBRT_UI_V1
endif

export IBRT_CORE_V2 ?= 1
ifeq ($(IBRT_CORE_V2),1)
KBUILD_CPPFLAGS += -DIBRT_CORE_V2_ENABLE
endif

export IBRT_UI_V2 ?= 1
ifeq ($(IBRT_UI_V2),1)
KBUILD_CPPFLAGS += -DIBRT_UI_V2
endif

export BES_AUD ?= 1

export POWER_MODE   ?= DIG_DCDC

export BT_RF_PREFER ?= 2M

export SPEECH_CODEC ?= 1

export MIX_AUDIO_PROMPT_WITH_A2DP_MEDIA_ENABLED ?= 1
export IOS_MFI ?= 0

export FLASH_SIZE ?= 0x400000
export FLASH_SUSPEND ?= 1

export HOST_GEN_ECDH_KEY ?= 0

export SW_TRIG ?= 1

USE_THIRDPARTY ?= 0
export USE_KNOWLES ?= 0

export LAURENT_ALGORITHM ?= 1

export RX_IQ_CAL ?= 0

export IBRT_DUAL_ANT_CTRL ?= 0

export BT_XTAL_SYNC ?= 1

export BTADDR_FOR_DEBUG ?= 1

export POWERKEY_I2C_SWITCH ?=0

AUTO_TEST ?= 0

BES_AUTOMATE_TEST ?= 0

export DUMP_LOG_ENABLE ?= 0

SUPPORT_BATTERY_REPORT ?= 1

SUPPORT_HF_INDICATORS ?= 0

SUPPORT_SIRI ?= 1

BES_AUDIO_DEV_Main_Board_9v0 ?= 0

APP_USE_LED_INDICATE_IBRT_STATUS ?= 0

export BT_EXT_LNA_PA ?=0
export BT_EXT_LNA ?=0
export BT_EXT_PA ?=0

#For ble feture verification
BLE ?= 0
export BLE_AUDIO_ENABLED ?= 0
export BLE_AOB_UX_ENABLED ?= 0
CUSTOMER_DEFINE_ADV_DATA ?= 0
export BLE_CONNECTION_MAX ?= 3

#For free tws pairing feature
FREE_TWS_PAIRING_ENABLED ?= 0

APP_UART_MODULE ?= 0

ifeq ($(A2DP_LHDC_ON),1)
AUDIO_BUFFER_SIZE ?= 140*1024
else
AUDIO_BUFFER_SIZE ?= 150*1024
endif

export AUDIO_OUTPUT_DC_AUTO_CALIB ?= 1
ifeq ($(AUDIO_OUTPUT_DC_AUTO_CALIB), 1)
export AUDIO_OUTPUT_DC_CALIB := 1
export AUDIO_OUTPUT_DC_CALIB_ANA := 0
export AUDIO_OUTPUT_SET_LARGE_ANA_DC ?= 1
export DAC_DRE_ENABLE ?= 1
export CODEC_DAC_DC_NV_DATA ?= 1
export CODEC_DAC_DC_DYN_BUF ?= 1
endif

export TRACE_BUF_SIZE ?= 32*1024
export TRACE_BAUD_RATE ?= 10*115200
export BTM_MAX_LINK_NUMS ?= 3
export BT_DEVICE_NUM ?= 2

#CODEC_VAD_CFG_BUF_SIZE ?= 0x18000

init-y :=
core-y := platform/ services/ apps/ utils/cqueue/ utils/list/ services/multimedia/ utils/intersyshci/ utils/sha256/

KBUILD_CPPFLAGS += \
    -Iplatform/cmsis/inc \
    -Iservices/audioflinger \
    -Iplatform/hal

KBUILD_CPPFLAGS += \
    -DAPP_AUDIO_BUFFER_SIZE=$(AUDIO_BUFFER_SIZE) \
    -DCHARGER_PLUGINOUT_RESET=0

KBUILD_CPPFLAGS += \
    -DBTM_MAX_LINK_NUMS=$(BTM_MAX_LINK_NUMS) \
    -DBT_DEVICE_NUM=$(BT_DEVICE_NUM)

ifeq ($(BES_AUDIO_DEV_Main_Board_9v0),1)
KBUILD_CPPFLAGS += -DBES_AUDIO_DEV_Main_Board_9v0
endif

ifeq ($(TPORTS_KEY_COEXIST),1)
KBUILD_CPPFLAGS += -DTPORTS_KEY_COEXIST
endif

ifeq ($(AUDIO_HEARING_COMPSATN),1)
HEARING_USE_STATIC_RAM := 1
ifeq ($(HEARING_MOD),HWFIR)
HW_FIR_EQ_PROCESS := 1
HEARING_MOD_VAL := 0
USE_CMSIS_FFT_LEN_1024 := 1
else
ifeq ($(HEARING_MOD),SWIIR)
SW_IIR_EQ_PROCESS := 1
HEARING_MOD_VAL := 1
else
HW_DAC_IIR_EQ_PROCESS := 1
HEARING_MOD_VAL := 2
endif
endif
endif

#-DIBRT_LINK_LOWLAYER_MONITOR

#-D_AUTO_SWITCH_POWER_MODE__
#-D__APP_KEY_FN_STYLE_A__
#-D__APP_KEY_FN_STYLE_B__
#-D__EARPHONE_STAY_BOTH_SCAN__
#-D__POWERKEY_CTRL_ONOFF_ONLY__
#-DAUDIO_LINEIN

ifeq ($(BT_RAMRUN),1)
KBUILD_CPPFLAGS += -D__BT_RAMRUN__
endif

ifeq ($(CURRENT_TEST),1)
export SMALL_RET_RAM ?= 1
export CORE_SLEEP_POWER_DOWN ?= 1
#INTSRAM_RUN ?= 1
endif
ifeq ($(INTSRAM_RUN),1)
LDS_FILE := best1000_intsram.lds
else
LDS_FILE := best1000.lds
endif

export OTA_SUPPORT_SLAVE_BIN ?= 0
ifeq ($(OTA_SUPPORT_SLAVE_BIN),1)
export SLAVE_BIN_FLASH_OFFSET ?= 0x100000
export SLAVE_BIN_TARGET_NAME ?= anc_usb
endif

ifeq ($(GATT_OVER_BR_EDR),1)
export GATT_OVER_BR_EDR ?= 1
KBUILD_CPPFLAGS += -D__GATT_OVER_BR_EDR__
endif

ifeq ($(BES_OTA),1)
# enabled when 1501 flash remap is ready
FLASH_REMAP ?= 0
NEW_IMAGE_FLASH_OFFSET ?= OTA_REMAP_OFFSET
endif

ifneq ($(A2DP_DECODER_VER), )
KBUILD_CPPFLAGS += -DA2DP_DECODER_VER=$(A2DP_DECODER_VER)
endif

ifeq ($(HOST_GEN_ECDH_KEY),1)
KBUILD_CPPFLAGS += -D__HOST_GEN_ECDH_KEY__
endif

ifeq ($(SW_TRIG),1)
KBUILD_CPPFLAGS += -D__SW_TRIG__
endif
ifeq ($(MCU_HIGH_PERFORMANCE_MODE),1)
KBUILD_CPPFLAGS += -DMCU_HIGH_PERFORMANCE_MODE
endif

KBUILD_CPPFLAGS += -DHAL_TRACE_RX_ENABLE

ifeq ($(AUDIO_OUTPUT_DC_AUTO_CALIB),1)
KBUILD_CPPFLAGS += -DAUDIO_OUTPUT_DC_AUTO_CALIB
endif

ifeq ($(CODEC_DAC_DC_NV_DATA), 1)
KBUILD_CPPFLAGS += -DCODEC_DAC_DC_NV_DATA
endif

ifeq ($(REPORT_CONNECTIVITY_LOG),1)
KBUILD_CPPFLAGS += -D__CONNECTIVITY_LOG_REPORT__
KBUILD_CPPFLAGS += -D__AUDIO_RETRIGGER_REPORT__
endif

ifeq ($(SNYC_FOUND_CHECK_HECERROR),1)
KBUILD_CPPFLAGS += -D__SNYC_FOUND_CHECK_HECERROR__
endif

KBUILD_CFLAGS +=

LIB_LDFLAGS += -lstdc++ -lsupc++

OPNE_DUAL_MIC_RECORDING_SRC ?= 0

DUAL_MIC_RECORDING ?= 0
RECORDING_USE_SCALABLE ?= 0
RECORDING_USE_OPUS ?= 0
RECORDING_USE_OPUS_LOWER_BANDWIDTH ?= 0

# mutex for power on tws pairing and freeman pairing
POWER_ON_ENTER_TWS_PAIRING_ENABLED ?= 0
POWER_ON_ENTER_FREEMAN_PAIRING_ENABLED ?= 0

OS_THREAD_TIMING_STATISTICS_ENABLE ?= 0

# enabled if wanna use sensor hub module
# export SENSOR_HUB ?= 1

# if VAD enabled, sensor hub always use large ram memory
ifeq ($(VOICE_DETECTOR_SENS_EN),1)
LARGE_SENS_RAM ?= 1
export SENSOR_HUB ?= 1
endif



#### skywalker specific macro
export SKYWALKER_IMPLEMENTATION ?= 1
ifeq ($(SKYWALKER_IMPLEMENTATION),1)
KBUILD_CPPFLAGS += -DSKYWALKER_IMPLEMENTATION
endif
#CFLAGS_IMAGE += -u _printf_float -u _scanf_float

#LDFLAGS_IMAGE += --wrap main
