循环计数器/循环栅栏/循环屏障 CyclicBarrier

CyclicBarrier

和 CountDownLatch 有点类似，主要区别是 CyclicBarrier 可以重用，常用方法如下：

CyclicBarrier barrier = new CyclicBarrier(3); // 表示条件为：要有 3 个线程达到屏障（未指定屏障动作）
barrier.await(); // 如果没有 3 个线程到达屏障，当前线程就阻塞，直到有 3 个线程达到才恢复

// 指定屏障动作
CyclicBarrier barrier = new CyclicBarrier(3, new Runnable() {
    @Override
    public void run() {
        System.out.println("All parties have arrived at the barrier, let's continue.");
    }
});

await() 底层是让 state - 1，达到栅栏的线程数量足够时，state 会重置，这样来体现可重用的。CountDown 不会重置 state

如果要使用线程池，线程池数量要和 CyclicBarrier 计数器一致

用法示例1

import java.util.concurrent.CyclicBarrier;
import java.util.concurrent.BrokenBarrierException;
import java.util.concurrent.TimeoutException;

public class CyclicBarrierExample {
    public static void main(String[] args) {
        // 创建一个 CyclicBarrier，设定需要3个线程到达屏障
        CyclicBarrier barrier = new CyclicBarrier(3, new Runnable() {
            @Override
            public void run() {
                // 当 3 个线程到达屏障，执行屏障动作
                System.out.println("All threads have reached the barrier, resuming execution.");
            }
        });

        // 启动3个线程，它们都会到达屏障
        for (int i = 0; i < 3; i++) {
            new Thread(new Worker(barrier)).start();
        }
    }
}

class Worker implements Runnable {
    private CyclicBarrier barrier;

    public Worker(CyclicBarrier barrier) {
        this.barrier = barrier;
    }

    @Override
    public void run() {
        try {
            System.out.println(Thread.currentThread().getName() + " is waiting at the barrier.");
            barrier.await(); // 当前线程挂起了，下面这行不会打印，直到 3 个线程达到屏障，当前线程恢复运行
            System.out.println(Thread.currentThread().getName() + " has passed the barrier.");
        } catch (InterruptedException | BrokenBarrierException e) {
            Thread.currentThread().interrupt();
        }
    }
}

用法示例2

执行两次，第二次执行的时候没有重新创建 CyclicBarrier，体现可重用

import java.util.concurrent.CyclicBarrier;
import java.util.concurrent.BrokenBarrierException;
import java.util.concurrent.TimeoutException;

public class CyclicBarrierReusableExample {
    public static void main(String[] args) {
        final int numberOfThreads = 3;
        final CyclicBarrier barrier = new CyclicBarrier(numberOfThreads, new Runnable() {
            @Override
            public void run() {
                System.out.println("Barrier reached! All threads completed the phase.");
            }
        });

        Runnable task = () -> {
            try {
                System.out.println(Thread.currentThread().getName() + " is performing task.");
                Thread.sleep((long) (Math.random() * 1000));
                System.out.println(Thread.currentThread().getName() + " finished task and waiting at the barrier.");
                barrier.await();
                // Phase complete, proceed to the next phase
                System.out.println(Thread.currentThread().getName() + " moving to the next phase.");
            } catch (InterruptedException | BrokenBarrierException e) {
                Thread.currentThread().interrupt();
            }
        };

        // Launch threads for phase 1
        for (int i = 0; i < numberOfThreads; i++) {
            new Thread(task).start();
        }

        // Wait for all threads to complete phase 1 and then start phase 2
        try {
            Thread.sleep(2000); // Simulate some delay between phases
        } catch (InterruptedException e) {
            Thread.currentThread().interrupt();
        }

        System.out.println("Starting next phase...");

        // Launch threads for phase 2, using the same barrier
        for (int i = 0; i < numberOfThreads; i++) {
            new Thread(task).start();
        }
    }
}

改成 CountDown，因为 CountDown 的计数器不会重置，所以要创建多个 CountDown

import java.util.concurrent.CountDownLatch;
import java.util.concurrent.BrokenBarrierException;

public class CountDownLatchExample {
    public static void main(String[] args) {
        final int numberOfThreads = 3;

        // Define a task
        Runnable task = new Runnable() {
            private CountDownLatch latch;

            public Runnable withLatch(CountDownLatch latch) {
                this.latch = latch;
                return this;
            }

            @Override
            public void run() {
                try {
                    System.out.println(Thread.currentThread().getName() + " is performing task.");
                    // Simulate some work
                    Thread.sleep((long) (Math.random() * 1000));
                    System.out.println(Thread.currentThread().getName() + " finished task and waiting at the latch.");
                    latch.await();  // Wait until the latch count reaches zero
                    // Phase complete, proceed to the next phase
                    System.out.println(Thread.currentThread().getName() + " moving to the next phase.");
                } catch (InterruptedException e) {
                    Thread.currentThread().interrupt();
                }
            }
        };

        // Method to start threads with a CountDownLatch
        void startPhase(int numberOfThreads) {
            CountDownLatch latch = new CountDownLatch(numberOfThreads);

            // Start threads
            for (int i = 0; i < numberOfThreads; i++) {
                new Thread(task.withLatch(latch)).start();
            }

            // Release the latch after all threads have started
            new Thread(() -> {
                try {
                    Thread.sleep(2000); // Simulate some delay before releasing the latch
                    System.out.println("Releasing the latch!");
                    latch.countDown();  // Count down the latch to zero
                } catch (InterruptedException e) {
                    Thread.currentThread().interrupt();
                }
            }).start();
        }

        // Start phase 1
        startPhase(numberOfThreads);

        // Wait for some time before starting the next phase
        try {
            Thread.sleep(3000); // Simulate some delay between phases
        } catch (InterruptedException e) {
            Thread.currentThread().interrupt();
        }

        System.out.println("Starting next phase...");

        // Start phase 2
        startPhase(numberOfThreads);
    }
}
