oem 135安装

空间需求：

[oracle@prdb19 ~]$ df -h
Filesystem                      Size  Used Avail Use% Mounted on
/dev/mapper/rhel_redhat76-root  6.2G  5.7G  542M  92% /
devtmpfs                        5.8G     0  5.8G   0% /dev
tmpfs                           5.8G     0  5.8G   0% /dev/shm
tmpfs                           5.8G   49M  5.8G   1% /run
tmpfs                           5.8G     0  5.8G   0% /sys/fs/cgroup
/dev/sda1                      1014M  148M  867M  15% /boot
/dev/mapper/vgu01-lvu01         150G   45G  106G  30% /u01
/dev/mapper/vgu01-lvdiag         10G   33M   10G   1% /diaglog
tmpfs                           1.2G     0  1.2G   0% /run/user/2100
D_DRIVE                         725G  650G   75G  90% /media/sf_D_DRIVE
tmpfs                           1.2G     0  1.2G   0% /run/user/0
[oracle@prdb19 ~]$







[oracle@prdb19 ~]$ emctl status oms -details
Oracle Enterprise Manager Cloud Control 13c Release 5
Copyright (c) 1996, 2021 Oracle Corporation.  All rights reserved.
Console Server Host        : prdb19
HTTP Console Port          : 7788
HTTPS Console Port         : 7803
HTTP Upload Port           : 4889
HTTPS Upload Port          : 4903
EM Instance Home           : /u01/gc_inst/em/EMGC_OMS1
OMS Log Directory Location : /u01/gc_inst/em/EMGC_OMS1/sysman/log
OMS is not configured with SLB or virtual hostname
Agent Upload is locked.
OMS Console is locked.
Active CA ID: 1
Console URL: https://prdb19:7803/em
Upload URL: https://prdb19:4903/empbs/upload

WLS Domain Information
Domain Name            : GCDomain
Admin Server Host      : prdb19
Admin Server HTTPS Port: 7102
Admin Server is RUNNING

Oracle Management Server Information
Managed Server Instance Name: EMGC_OMS1
Oracle Management Server Instance Host: prdb19
WebTier is Up
Oracle Management Server is Up

[oracle@prdb19 ~]$ /u01/agentapp/agent_13.5.0.0.0/bin/emctl status agent
Oracle Enterprise Manager Cloud Control 13c Release 5
Copyright (c) 1996, 2021 Oracle Corporation. All rights reserved.
---------------------------------------------------------------
Agent Version : 13.5.0.0.0
OMS Version : 13.5.0.0.0
Protocol Version : 12.1.0.1.0
Agent Home : /u01/agentapp/agent_inst
Agent Log Directory : /u01/agentapp/agent_inst/sysman/log
Agent Binaries : /u01/agentapp/agent_13.5.0.0.0
Core JAR Location : /u01/agentapp/agent_13.5.0.0.0/jlib
Agent Process ID : 4612
Parent Process ID : 4423
Agent URL : https://prdb19:3872/emd/main/
Local Agent URL in NAT : https://prdb19:3872/emd/main/
Repository URL : https://prdb19:4903/empbs/upload
Started at : 2024-04-22 13:12:50
Started by user : oracle
Operating System : Linux version 3.10.0-957.el7.x86_64 (amd64)
Number of Targets : 37
Last Reload : (none)
Last successful upload : 2024-04-22 13:22:47
Last attempted upload : 2024-04-22 13:22:47
Total Megabytes of XML files uploaded so far : 0.1
Number of XML files pending upload : 0
Size of XML files pending upload(MB) : 0
Available disk space on upload filesystem : 70.22%
Collection Status : Collections enabled
Heartbeat Status : Ok
Last attempted heartbeat to OMS : 2024-04-22 13:22:42
Last successful heartbeat to OMS : 2024-04-22 13:22:42
Next scheduled heartbeat to OMS : 2024-04-22 13:23:42

---------------------------------------------------------------

Agent is Running and Ready
