linux源码安装slurm以及mung和openssl
一、源码安装munge
1、编译安装munge
(1)下载munge地址:https://github.com/dun/munge/releases(2)解压编译安装:
tar -Jxvf munge-0.5.15.tar.xz ./bootstrap ./configure --prefix=/usr/local/munge \ --sysconfdir=/usr/local/munge/etc \ --localstatedir=/usr/local/munge/local \ --with-runstatedir=/usr/local/munge/run \ --libdir=/usr/local/munge/lib64 make && make install
2、创建用户并修改权限
useradd -s /sbin/nologin -u 601 munge sudo -u munge mkdir -p /usr/local/munge/run/munge // sudo -u munge mkdir /usr/local/munge/var/munge /usr/local/munge/var/run // sudo -u munge mkdir /usr/local/munge/var/run/munge chown -R munge.munge /usr/local/munge/ chmod 700 /usr/local/munge/etc/ chmod 711 /usr/local/munge/local/ chmod 755 /usr/local/munge/run chmod 711 /usr/local/munge/lib
3、配置文件及服务
(1)创建munge.key文件
执行以下命令完成以后,在/usr/local/munge/etc/munge/下面会生成munge.key,需修改munge.key的权限
sudo -u munge /usr/local/munge/sbin/mungekey --verbose chmod 600 /usr/local/munge/etc/munge/munge.key
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406210700707-746491196.png)
【注意】:如果有多台服务器,需将服务端的munge.key发给客户端,客户端无需自己生成
(2)生成链接文件并启动服务
ln -s /usr/local/munge/lib/systemd/system/munge.service /usr/lib/systemd/system/munge.service (cp /usr/local/munge/lib/systemd/system/munge.service /usr/lib/systemd/system/) systemctl daemon-reload systemctl start munge systemctl status munge
创建脚本链接(或者直接拷贝文件),通过'service munge start'启动服务,如下图: ln -fs /usr/local/munge/etc/rc.d/init.d/munge /etc/init.d/munge 创建命令链接(或者直接拷贝文件),通过'munged'启动服务,如下图: ln -fs /usr/local/munge/sbin/munged /usr/sbin/munged
4、安装中会出现的问题
(1)configure报错![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406210700691-555916108.png)
【解决方式】:apt -y install openssl-devel openssl
这里采用符合GPL许可的Open SSL加密库,如果是源码编译的此库环境,编译时需要通过--with-crypto-lib选择指定
或者源码安装openssl后--with-openssl-prefix=/usr/local/openssl
(2)文件权限和所有者有问题
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406210700732-1020401073.png)
/usr/local的文件权限和所有者有问题
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406210700720-821623282.png)
【解决方式】:修改/usr/local的文件权限和所有者
chown -R root.root /usr/local chmod -R 755 /usr/local
二、源码安装slurm
apt-get install make hwloc libhwloc-dev libmunge-dev libmunge2 munge mariadb-server libmysalclient-dey -y
1、下载并安装
(1)下载地址:https://www.schedmd.com/downloads.phptar -jxvf slurm-22.05.8.tar.bz2 // find . -name "config.guess" cp /usr/share/misc/config.* auxdir/ // cp /usr/share/libtool/build-aux/config.* .
(2)编译安装
./configure --prefix=/usr/local/slurm \ --with-munge=/usr/local/munge \ sysconfdir=/usr/local/slurm/etc \ --localstatedir=/usr/local/slurm/local \ --runstatedir=/usr/local/slurm/run \ --libdir=/usr/local/slurm/lib64
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406213906849-1615662493.png)
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406213906848-284123922.png)
如果下面显示no,则需要重新./configure并指定,--with-mysql_config=/usr/bin
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406213906842-147663957.png)
make -j && make install
2、配置数据库
mysql -u root -p 登录到数据库进行下面操作// 生成slurm用户,以便该用户操作slurm_acct_db数据库,其密码是123456 create user 'slurm'@'localhost' identified by '123456'; // 生成账户数据库slurm_acct_db create database slurm_acct_db; // 赋予slurm从本机localhost采用密码123456登录具备操作slurm_acct_db数据下所有表的全部权限 grant all on slurm_acct_db.* TO 'slurm'@'localhost' identified by '123456' with grant option; // 赋予slurm从system0采用密码123456登录具备操作slurm_acct_db数据下所有表的全部权限 grant all on slurm_acct_db.* TO 'slurm'@'system0' identified by '123456' with grant option; // 生成作业信息数据库slurm_jobcomp_db create database slurm_jobcomp_db; // 赋予slurm从本机localhost采用密码123456登录具备操作slurm_jobcomp_db数据下所有表的全部权限 // GRANT ALL PRIVILEGES ON slurm_jobcomp_db.* TO 'slurm'@'localhost'; grant all on slurm_jobcomp_db.* TO 'slurm'@'localhost' identified by '123456' with grant option; // 赋予slurm从system0采用密码123456登录具备操作slurm_jobcomp_db数据下所有表的全部权限 grant all on slurm_jobcomp_db.* TO 'slurm'@'system0' identified by '123456' with grant option;
3、配置slurm文件及服务
(1)编辑配置文件(示例配置文件在源码包中的etc下)
cp slurm.conf.example /usr/local/slurm/etc/slurm.conf cp slurmdbd.conf.example /usr/local/slurm/etc/ slurmdbd.conf cp cgroup.conf.example /usr/local/slurm/etc/cgroup.conf chmod 600 slurmdbd.conf cd /usr/local/slurm mkdir run slurm log
(2)配置环境变量
vim /etc/profile.d/slurm.sh export PATH=$PATH:/usr/local/slurm/bin:/usr/local/slurm/sbin export LD_LIBRARY_PATH=/usr/local/slurm/lib64:$LD_LIBRARY_PATH
(3)启动服务(服务启动文件在源码包中的etc下)
// cp etc/slurmctld.service etc/slurmdbd.service etc/slurmd.service /etc/systemd/system/ cp etc/slurmctld.service etc/slurmdbd.service etc/slurmd.service /usr/lib/systemd/system/ systemctl daemon-reload // 重新加载systemd守护进程配置文件 systemctl start slurmctld slurmd slurmdbd // 开启服务 systemctl enable slurmctld slurmd slurmdbd // 开机自启动
【注意】:客户端只需要slurmd
正常情况下显示绿色的active状态;如果失败,则用下面命令查看错误日志
slurmctld -Dvvvvv slurmdbd -Dvvvvv slurmd -Dvvvvv
scontrol update nodename=sw01 state=idle
4、slurm排错
重启slurmctld服务systemctl restart slurmctld scp -r /usr/local/slurm test10:/usr/local/ scp /etc/profile.d/slurm.sh test10:/etc/profile.d/ scp /etc/systemd/system/slurmd.service test10:/etc/systemd/system/
![](https://img2024.cnblogs.com/blog/2173981/202405/2173981-20240524172834744-1519892253.png)
数据库连接失败
查看3306端口是否开放远程连接
![](https://img2024.cnblogs.com/blog/2173981/202405/2173981-20240524173016996-1076647785.png)
没有开放3306端口
修改vim /etc/my.cnf,添加port=3306,然后重启mysql;
(2)slurm_load_partitions: Zero Bytes were transmitted or received
客户端sinfo查看时出现x上面错误,一般是时间不一致,可用date查看时间日期。
解决:节点时间未同步,安装NTP后,启动ntpd服务即可。
三、openssl源码安装
1、下载安装openssl
(1)查看openssl版本
openssl version
(2)下载相应版本openssl
下载地址:https://www.openssl.org/source/old/
tar -zxvf openssl-1.1.1s.tar.gz ./config --prefix=/usr/local/openssl ./config -t make & make install
2、测试验证
/usr/local/openssl/bin/openssl version
openssl: symbol lookup error: openssl: undefined symbol: EVP_mdc2, version OPENSSL_1_1_0
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406213906830-1872912976.png)
// 此时需要配置下系统库: // echo “/usr/local/openssl/lib” >> /etc/ld.so.conf.d/libc.conf && ldconfig // 最后将/usr/local/openssl/bin/openssl添加到系统路径 // ln -s /usr/local/openssl/bin/openssl /bin/openssl
3、切换openssl版本
// mv /usr/bin/openssl /usr/bin/openssl.bak // mv /usr/include/openssl /usr/include/openssl.bak // ln -s /usr/local/openssl/bin/openssl /usr/bin/openssl // ln -s /usr/local/openssl/include/openssl /usr/include/openssl // echo "/usr/local/openssl/lib" >> /etc/ld.so.conf ldconfig -v // ln -s /usr/local/openssl/lib/libssl.so.1.1 /usr/lib64/libssl.so.1.1 // ln -s /usr/local/openssl/lib/libcrypto.so.1.1 /usr/lib64/libcrypto.so.1.1 // 【注意】:不能直接删除软链接 // 如需使用新版本开发,则需替换原来的软链接指向,即替换原动态库,进行版本升级。 // 替换/lib(lib64)和/usr/lib(lib64)和/usr/local/lib(lib64)存在的相应动态库: // ln -sf /usr/local/openssl/lib/libssl.so.1.1 /usr/lib64/libssl.so // ln -sf /usr/local/openssl/lib/libcrypto.so.1.1 /usr/lib64/libcrypto.so
4、解决openssl报错
源码安装完OpenSSL后,打开一个新的窗口执行openssl version命令报错(一定要新开窗口执行openssl version)(i)error while loading shared libraries: libssl.so.1.1: cannot open shared object file: No such file or directory
(ii)error while loading shared libraries: libcrypto.so.1.1: cannot open shared object file: No such file or directory
![](https://img2023.cnblogs.com/blog/2173981/202305/2173981-20230517112348561-1644000883.png)
(1)方法一:
链接或拷贝/lib(lib64)和/usr/lib(lib64)和/usr/local/lib(lib64)存在的相应动态库
ln -s /usr/local/openssl/lib/libssl.so.1.1 /usr/lib/libssl.so.1.1 ln -s /usr/local/openssl/lib/libcrypto.so.1.1 /usr/lib/libcrypto.so.1.1
不指定安装目录,一般so会存放在/usr/local/lib这个目录底下,去这个目录底下找,果然发现自己所需要的.so文件
![](https://img2023.cnblogs.com/blog/2173981/202305/2173981-20230517114235957-820168885.png)
所以,在/etc/ld.so.conf中加入/usr/local/lib这一行,保存之后,再运行:/sbin/ldconfig -v更新一下配置即可。
/sbin/ldconfig -v ldconfig
四、连网yum安装munge
1、配置并安装munge
(1)添加munge用户
groupadd -g 972 munge useradd -g 972 -u 972 munge
(2)安装munge
apt-get install munge -y
(3)执行以下命令,创建munge.key文件:
create-munge-key
2、修改文件权限
执行完以后,在/etc/munge/下面会生成munge.key,需修改munge.key的权限以及所属用户,把所属用户改成munge(/etc和/usr应为root权限)chown -R munge: /etc/munge/ /var/log/munge/ /var/lib/munge/ /var/run/munge/ chmod 400 /etc/munge/munge.key
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406213906918-217227045.png)
ps -ef | grep munge kill -9 16730
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230406213906890-306563775.png)
五、Slurm常用命令以及基本用法
1、查看可用资源sinfo
idle |
节点空闲,可接受作业 |
alloacted |
该节点已经分配作业且所有核心用满,在作业释放前不能再被分配作业 |
mix |
使用部分核心,仍可以被分配作业 |
drain |
对应节点已经下线 |
drng |
节点已下线但仍有作业在运行 |
2、slurm提交作业命令
(1)交互式作业srun
srun命令属于交互式提交作业,有屏幕输出,但容易受网络波动影响,断网或关闭窗口会导致作业中断。
srun -n 4 hostname
-N 2 指定使用2个节点; -n 12 指定运行的任务数为12, 默认情况下一个CPU核一个任务 -p debug 指定提交作业到debug队列; -w x86[13-16] 指定使用节点x86[13-16]; -x x86[11-12] 排除x8611、x8612节点; -o out.log 指定标准输出到out.log文件; -e err.log 指定重定向错误输出到err.log文件; -J JOBNAME 指定作业名为JOBNAME; -t 20 指定作业运行时间限制为20分钟; --gres=gpu:2 为作业分配2块GPU显卡资源(最大值为8);
(2)批处理作业脚本sbatch
sbatch一般情况下与srun一起提交作业到后台运行,需要将srun写到脚本中,再用sbatch 提交脚本。这种方式不受本地网络波动影响,提交作业后可以关闭本地电脑。sbatch命令没有屏幕输出,默认输出日志为提交目录下的slurm-xxx.out文件,可以使用tail -f slurm-xxx.out实时查看日志,其中xxx为作业号。
<i、一个简单的Slurm脚本(job_run.sh)如下:
#!/bin/bash #SBATCH -J xujb #指定作业名 #SBATCH -p q_x86 #指定队列 #SBATCH -N 2 #请求节点总数 #SBATCH -n 24 #请求进程总数 #SBATCH -w x86b,x86c #指定运行作业的节点 #SBATCH -x x86a #指定不使用x86a运行作业 #SBATCH -o slurm-%j.out #标准输出文件 #SBATCH -e slurm-%j.log #错误输出文件 # 设置运行环境 #module load mpich/4.1.1 export PATH=/usr/local/mpich-4.1.1/bin:$PATH export LD_LIBRARY_PATH=/usr/local/mpich-4.1.1/lib:$LD_LIBRARY_PATH echo ${SLURM_JOB_NODELIST} #作业占用节点列表 echo start on $(date) #开始时间 # 输入要执行的命令 srun ../funs9/main #mpirun -n ${SLURM_NTASKS} ../funs9/main echo end on $(date) #结束时间
<ii、sbatch提交作业
sbatch -n 2 ./job.sh
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230419110124434-1557273090.png)
3、查看作业状态squeue
![](https://img2023.cnblogs.com/blog/2173981/202304/2173981-20230419110419843-767760850.png)
# 参数示例 squeue l:以长列表显示更多信息。 squeue -u username:仅显示属于用户username的任务。 squeue -t state:仅显示处于state状态的任务。 squeue -n job name:仅显示名称为job name的作业。 squeue -p partition:仅显示partition分区的任务。 squeue -jobs job id:仅显示作业id为job id的作业。
4、删除作业scancel
scancel 17
# 参数示例 scancel jobid:删除jobid的作业。 scancel -u username:删除username的全部作业。 scancel -s state:删除处于state状态的作业。 scancel -p partition:仅显示partition分区的任务
5、查看任务信息scontrol
# 参数示例 scontrol show partition partition_name:详细显示partition name分区的信息。 scontrol show node node_name:详细显示node name节点信息。 scontrol show job job_id:详细显示job id作业的信息。
scontrol命令可以管理Slurm集群中的节点,例如关机、重启和修改属性等操作。例如,要关闭节点x86b,可以使用以下命令:
scontrol update NodeName=x86b State=DOWN
scontrol命令可以管理Slurm队列,例如修改队列的最大CPU数、最大内存大小等属性。例如,要将q_x86队列最大CPU数更改为48,可以使用以下命令:
scontrol update PartitionName=q_x86 MaxCPUs=48
6、查询包括已完成作业信息sacct
输出内容会包括,作业号,作业名,分区,计费账户,申请的CPU数量,状态,结束代码# 参数示例 -b,--brief:显示简要信息,主要包含: 作业号jobid、状态status和退出码exitcode。 -c,--completion:显示作业完成信息而非记账信息。 -e,--helpformat:显示当采用 --format指定格式化输出的可用格式。 -E end_time,--endtime-end time:显示在end time时间之前(不限作业状态)的作业。 -i,--nnodes=N:显示在特定节点数上运行的作业。 -j job(step),--jobs=job(.step):限制特定作业号(步)的信息,作业号(步)可以以,分隔. -l,--long:显示详细信息。 -N node list,--nodelist-node list:显示运行在特定节点的作业记账信息。 -R reason list,-reason=reason list:显示由于XX原因没有被调度的作业记账信息。 -s state_list,-state-state list:显示state list(以,分隔)状态的作业记账信息。 -S,--starttime:显示特定时间之后开始运行的作业记账信息,有效时间格式参见
7、调度配置信息sacctmgr
主要负责管理账号,用户,集群分区等资源
# 管理账户 sacctmgr show account # 直询账户信息 sacctmgr add account new_account # 添加账户信息 sacctmgr modify account new_account set Parent=slurmtest01 # 修改账户信息 sacctmgr delete account new_account # 删除账户信息 #管理QOS sacctmgr show qos # 查询QOS sacctmgr add qos new_qos # 添加QOS sacctmgr modify qos new_gos set MaxJobsPerUser=4 # 修改QOS,如用户使用核心数,作业数 sacctmgr delete qos new_qos # 删除QOS #用户管理 sacctmgr show user (withassoc) # 查询用户 sacctmgr add user testslurm # 添加用户 sacctmgr -i add user test1 account=test # 增加test1用户属于test账户 sacctmgr update user testslurm set QOS=new_qos # 修改用户信息 sacctmgr delete user testslurm # 删除用户信
六、slurm配置文件
(1)slurm.conf配置文件
######################################################## # Configuration file for Slurm - 2021-08-20T10:27:23 # ######################################################## # # # ################################################ # CONTROL # ################################################ ClusterName=Sunway # 集群名 SlurmUser=root # 主节点管理账号 SlurmctldHost=sw01 # 主节点名 #SlurmctldHost=psn2 #备控制器的主机名 SlurmctldPort=6817 SlurmdPort=6818 SlurmdUser=root # ################################################ # LOGGING & OTHER PATHS # ################################################ SlurmctldLogFile=/usr/local/slurm/log/slurmctld.log # 主节点log文件 SlurmdLogFile=/usr/local/slurm/log/slurmd.log # 子节点log文件 SlurmdPidFile=/usr/local/slurm/run/slurmd.pid # 子节点进程文件 SlurmdSpoolDir=/usr/local/slurm/slurm/d # 子节点状态文件夹 #SlurmSchedLogFile= SlurmctldPidFile=/usr/local/slurm/run/slurmctld.pid # 主服务进程文件 StateSaveLocation=/usr/local/slurm/slurm/state # 主节点状态文件夹 # ################################################ # ACCOUNTING # ################################################ #AccountingStorageBackupHost=psn2 #slurmdbd备机 AccountingStorageEnforce=associations,limits,qos AccountingStorageHost=sw01 # 主节点 AccountingStoragePort=6819 AccountingStorageType=accounting_storage/slurmdbd #AccountingStorageUser= #AccountingStoreJobComment=Yes AcctGatherEnergyType=acct_gather_energy/none AcctGatherFilesystemType=acct_gather_filesystem/none AcctGatherInterconnectType=acct_gather_interconnect/none AcctGatherNodeFreq=0 #AcctGatherProfileType=acct_gather_profile/none ExtSensorsType=ext_sensors/none ExtSensorsFreq=0 JobAcctGatherFrequency=30 JobAcctGatherType=jobacct_gather/linux # ################################################ # SCHEDULING & ALLOCATION # ################################################ PreemptMode=OFF PreemptType=preempt/none PreemptExemptTime=00:00:00 PriorityType=priority/basic #SchedulerParameters= SchedulerTimeSlice=30 SchedulerType=sched/backfill #SelectType=select/cons_tres SelectType=select/linear #SelectTypeParameters=CR_CPU SlurmSchedLogLevel=0 # ################################################ # TOPOLOGY # ################################################ TopologyPlugin=topology/none # ################################################ # TIMERS # ################################################ BatchStartTimeout=10 CompleteWait=0 EpilogMsgTime=2000 GetEnvTimeout=2 InactiveLimit=0 KillWait=30 MinJobAge=300 SlurmctldTimeout=60 SlurmdTimeout=60 WaitTime=0 # ################################################ # POWER # ################################################ #ResumeProgram= ResumeRate=300 ResumeTimeout=60 #SuspendExcNodes= #SuspendExcParts= #SuspendProgram= SuspendRate=60 SuspendTime=NONE SuspendTimeout=30 # ################################################ # DEBUG # ################################################ DebugFlags=NO_CONF_HASH SlurmctldDebug=info SlurmdDebug=info # ################################################ # EPILOG & PROLOG # ################################################ #Epilog=/usr/local/etc/epilog #Prolog=/usr/local/etc/prolog #SrunEpilog=/usr/local/etc/srun_epilog #SrunProlog=/usr/local/etc/srun_prolog #TaskEpilog=/usr/local/etc/task_epilog #TaskProlog=/usr/local/etc/task_prolog # ################################################ # PROCESS TRACKING # ################################################ ProctrackType=proctrack/pgid # ################################################ # RESOURCE CONFINEMENT # ################################################ #TaskPlugin=task/none #TaskPlugin=task/affinity #TaskPlugin=task/cgroup #TaskPluginParam= # ################################################ # OTHER # ################################################ #AccountingStorageExternalHost= #AccountingStorageParameters= AccountingStorageTRES=cpu,mem,energy,node,billing,fs/disk,vmem,pages AllowSpecResourcesUsage=No #AuthAltTypes= #AuthAltParameters= #AuthInfo= AuthType=auth/munge #BurstBufferType= #CliFilterPlugins= #CommunicationParameters= CoreSpecPlugin=core_spec/none #CpuFreqDef= CpuFreqGovernors=Performance,OnDemand,UserSpace CredType=cred/munge #DefMemPerNode= #DependencyParameters= DisableRootJobs=No EioTimeout=60 EnforcePartLimits=NO #EpilogSlurmctld= #FederationParameters= FirstJobId=1 #GresTypes= GpuFreqDef=high,memory=high GroupUpdateForce=1 GroupUpdateTime=600 #HealthCheckInterval=0 #HealthCheckNodeState=ANY #HealthCheckProgram= InteractiveStepOptions=--interactive #JobAcctGatherParams= JobCompHost=localhost JobCompLoc=/var/log/slurmjobcomp.log JobCompPort=0 JobCompType=jobcomp/mysql JobCompUser=slurm JobCompPass=123456 JobContainerType=job_container/none #JobCredentialPrivateKey= #JobCredentialPublicCertificate= #JobDefaults= JobFileAppend=0 JobRequeue=1 #JobSubmitPlugins= #KeepAliveTime= KillOnBadExit=0 #LaunchParameters= LaunchType=launch/slurm #Licenses= LogTimeFormat=iso8601_ms #MailDomain= #MailProg=/bin/mail MaxArraySize=1001 MaxDBDMsgs=20012 MaxJobCount=10000 #最大的作业数 MaxJobId=67043328 MaxMemPerNode=UNLIMITED MaxStepCount=40000 MaxTasksPerNode=512 MCSPlugin=mcs/none #MCSParameters= MessageTimeout=10 MpiDefault=pmi2 ##启用MPI #MpiParams= #NodeFeaturesPlugins= OverTimeLimit=0 PluginDir=/usr/local/slurm/lib64/slurm #PlugStackConfig= #PowerParameters= #PowerPlugin= #PrEpParameters= PrEpPlugins=prep/script #PriorityParameters= #PrioritySiteFactorParameters= #PrioritySiteFactorPlugin= PrivateData=none #PrologEpilogTimeout=65534 #PrologSlurmctld= #PrologFlags= PropagatePrioProcess=0 PropagateResourceLimits=ALL #PropagateResourceLimitsExcept= #RebootProgram= #ReconfigFlags= #RequeueExit= #RequeueExitHold= #ResumeFailProgram= #ResvEpilog= ResvOverRun=0 #ResvProlog= ReturnToService=0 RoutePlugin=route/default #SbcastParameters= #ScronParameters= #SlurmctldAddr= #SlurmctldSyslogDebug= #SlurmctldPrimaryOffProg= #SlurmctldPrimaryOnProg= #SlurmctldParameters= #SlurmdParameters= #SlurmdSyslogDebug= #SlurmctldPlugstack= SrunPortRange=0-0 SwitchType=switch/none TCPTimeout=2 TmpFS=/tmp #TopologyParam= TrackWCKey=No TreeWidth=50 UsePam=No #UnkillableStepProgram= UnkillableStepTimeout=60 VSizeFactor=0 #X11Parameters= # ################################################ # NODES # ################################################ #NodeName=Intel Sockets=2 CoresPerSocket=16 ThreadsPerCore=1 RealMemory=480000 #NodeName=Dell Sockets=2 CoresPerSocket=24 ThreadsPerCore=1 RealMemory=100000 #NodeName=swa CPUS=16 CoresPerSocket=1 ThreadsPerCore=1 Sockets=16 RealMemory=48000 State=UNKNOWN #NodeName=swb CPUS=64 CoresPerSocket=32 ThreadsPerCore=1 Sockets=2 RealMemory=100000 State=UNKNOWN #NodeName=sw5a0[1-3] CPUS=4 Sockets=4 CoresPerSocket=1 ThreadsPerCore=1 RealMemory=1 NodeName=sw01 CPUs=1 Sockets=1 CoresPerSocket=1 ThreadsPerCore=1 State=UNKNOWN # ################################################ # PARTITIONS # ################################################ #PartitionName=x86 AllowGroups=all MinNodes=0 Nodes=Dell Default=YES State=UP #PartitionName=multicore AllowGroups=all MinNodes=0 Nodes=swa,swb,swc,swd State=UP #PartitionName=manycore Default=YES AllowGroups=all MinNodes=0 Nodes=sw5a0[1-3] State=UP PartitionName=Manycore AllowGroups=all MinNodes=0 Nodes=sw01 State=UP Default=YES
(2)slurmdbd.conf配置文件
# # Example slurmdbd.conf file. # # See the slurmdbd.conf man page for more information. # # Archive info #ArchiveJobs=yes #ArchiveDir="/tmp" #ArchiveSteps=yes #ArchiveScript= #JobPurge=12 #StepPurge=1 # # Authentication info AuthType=auth/munge #AuthInfo=/var/run/munge/munge.socket.2 # # slurmDBD info为启用slurmdbd的管理服务器,与slurm.conf中的AccountingStorageHost一致 DbdHost=sw01 #DbdBackupAddr=172.17.0.2 #DbdBackupHost=mn02 DbdPort=6819 SlurmUser=root MessageTimeout=30 DebugLevel=7 #DefaultQOS=normal,standby LogFile=/usr/local/slurm/log/slurmdbd.log PidFile=/usr/local/slurm/run/slurmdbd.pid #PluginDir=/usr/lib/slurm #PrivateData=accounts,users,usage,jobs PrivateData=jobs #TrackWCKey=yes # # Database info StorageType=accounting_storage/mysql StorageHost=localhost #StorageBackupHost=mn02 StoragePort=3306 StoragePass=123456 StorageUser=slurm StorageLoc=slurm_acct_db CommitDelay=1
(2)
######################################################## # Configuration file for Slurm - 2021-08-20T10:27:23 # ######################################################## # # # ################################################ # CONTROL # ################################################ ClusterName=Sunway #集群名称 SlurmUser=root SlurmctldHost=Dell #主控制器的主机名 #SlurmctldHost=Intel #备控制器的主机名 SlurmctldPort=6817 #slurctld的监听端口 SlurmdPort=6818 #slurmd的通信端口 SlurmdUser=root # ################################################ # LOGGING & OTHER PATHS # ################################################ SlurmctldLogFile=/var/log/slurmctld.log SlurmdLogFile=/var/log/slurmd.log SlurmdPidFile=/var/run/slurmd.pid SlurmdSpoolDir=/var/spool/slurmd #SlurmSchedLogFile= SlurmctldPidFile=/var/run/slurmctld.pid StateSaveLocation=/var/spool/slurmctld #集群状态文件存放位置(全局文件系统) # ################################################ # ACCOUNTING # ################################################ #AccountingStorageBackupHost=Intel #slurmdbd备机 #AccountingStorageEnforce=none AccountingStorageEnforce=associations,limits,qos AccountingStorageHost=Dell #slurmdbd主机,为数据库管理服务器,即slurmdbd运行的服务器 AccountingStoragePort=6819 AccountingStorageType=accounting_storage/slurmdbd #AccountingStorageUser= #AccountingStoreJobComment=Yes AcctGatherEnergyType=acct_gather_energy/none AcctGatherFilesystemType=acct_gather_filesystem/none AcctGatherInterconnectType=acct_gather_interconnect/none AcctGatherNodeFreq=0 AcctGatherProfileType=acct_gather_profile/none ExtSensorsType=ext_sensors/none ExtSensorsFreq=0 JobAcctGatherFrequency=30 JobAcctGatherType=jobacct_gather/linux # ################################################ # SCHEDULING & ALLOCATION # ################################################ PreemptMode=OFF PreemptType=preempt/none PreemptExemptTime=00:00:00 PriorityType=priority/basic #SchedulerParameters= SchedulerTimeSlice=30 SchedulerType=sched/backfill SelectType=select/cons_tres #SelectType=select/linear #为资源选择类型,参见资源选择说明 SelectTypeParameters=CR_CPU #CR_Core_Memory SlurmSchedLogLevel=0 # ################################################ # TOPOLOGY # ################################################ TopologyPlugin=topology/none # ################################################ # TIMERS # ################################################ BatchStartTimeout=10 CompleteWait=0 EpilogMsgTime=2000 GetEnvTimeout=2 InactiveLimit=0 KillWait=30 MinJobAge=300 SlurmctldTimeout=60 #控制器通信超时 SlurmdTimeout=60 #slurmd通信超时 WaitTime=0 # ################################################ # POWER # ################################################ #ResumeProgram= ResumeRate=300 ResumeTimeout=60 #SuspendExcNodes= #SuspendExcParts= #SuspendProgram= SuspendRate=60 SuspendTime=NONE SuspendTimeout=30 # ################################################ # DEBUG # ################################################ DebugFlags=NO_CONF_HASH SlurmctldDebug=info SlurmdDebug=info # ################################################ # EPILOG & PROLOG # ################################################ #Epilog=/usr/local/etc/epilog #Prolog=/usr/local/etc/prolog #SrunEpilog=/usr/local/etc/srun_epilog #SrunProlog=/usr/local/etc/srun_prolog #TaskEpilog=/usr/local/etc/task_epilog #TaskProlog=/usr/local/etc/task_prolog # ################################################ # PROCESS TRACKING # ################################################ ProctrackType=proctrack/pgid # ################################################ # RESOURCE CONFINEMENT # ################################################ TaskPlugin=task/affinity #TaskPlugin=task/cgroup #TaskPluginParam=verbose #TaskPluginParam=Sched # ################################################ # OTHER # ################################################ #AccountingStorageExternalHost= #AccountingStorageParameters= AccountingStorageTRES=cpu,mem,energy,node,billing,fs/disk,vmem,pages AllowSpecResourcesUsage=No #AuthAltTypes= #AuthAltParameters= #AuthInfo= AuthType=auth/munge #BurstBufferType= #CliFilterPlugins= #CommunicationParameters= CoreSpecPlugin=core_spec/none #CpuFreqDef= CpuFreqGovernors=Performance,OnDemand,UserSpace CredType=cred/munge #DefMemPerNode= #DependencyParameters= DisableRootJobs=No EioTimeout=60 EnforcePartLimits=NO #EpilogSlurmctld= #FederationParameters= FirstJobId=1 #GresTypes= GpuFreqDef=high,memory=high GroupUpdateForce=1 GroupUpdateTime=600 HealthCheckInterval=0 HealthCheckNodeState=ANY #HealthCheckProgram= InteractiveStepOptions=--interactive #JobAcctGatherParams= JobCompHost=localhost JobCompLoc=/var/log/slurm_jobcomp.log JobCompPort=0 #JobCompType=jobcomp/none JobCompType=jobcomp/mysql JobCompUser=slurm JobCompPass=Nvmetest@123 JobContainerType=job_container/none #JobCredentialPrivateKey= #JobCredentialPublicCertificate= #JobDefaults= JobFileAppend=0 JobRequeue=1 #JobSubmitPlugins= #KeepAliveTime= KillOnBadExit=0 #LaunchParameters= LaunchType=launch/slurm #Licenses= LogTimeFormat=iso8601_ms #MailDomain= MailProg=/bin/mail MaxArraySize=1001 MaxDBDMsgs=20012 MaxJobCount=10000 #最大的作业数 MaxJobId=67043328 MaxMemPerNode=UNLIMITED MaxStepCount=40000 MaxTasksPerNode=512 MCSPlugin=mcs/none #MCSParameters= MessageTimeout=10 MpiDefault=pmi2 ##启用MPI #MpiParams= #NodeFeaturesPlugins= OverTimeLimit=0 PluginDir=/usr/local/lib/slurm #PlugStackConfig= #PowerParameters= #PowerPlugin= #PrEpParameters= PrEpPlugins=prep/script #PriorityParameters= #PrioritySiteFactorParameters= #PrioritySiteFactorPlugin= PrivateData=none PrologEpilogTimeout=65534 #PrologSlurmctld= #PrologFlags= PropagatePrioProcess=0 PropagateResourceLimits=ALL #PropagateResourceLimitsExcept= #RebootProgram= #ReconfigFlags= #RequeueExit= #RequeueExitHold= #ResumeFailProgram= #ResvEpilog= ResvOverRun=0 #ResvProlog= ReturnToService=0 RoutePlugin=route/default #SbcastParameters= #ScronParameters= #SlurmctldAddr= #SlurmctldSyslogDebug= #SlurmctldPrimaryOffProg= #SlurmctldPrimaryOnProg= #SlurmctldParameters= #SlurmdParameters= #SlurmdSyslogDebug= #SlurmctldPlugstack= SrunPortRange=0-0 SwitchType=switch/none TCPTimeout=2 TmpFS=/tmp #TopologyParam= TrackWCKey=No TreeWidth=50 UsePam=No #UnkillableStepProgram= UnkillableStepTimeout=60 VSizeFactor=0 #X11Parameters= # ################################################ # NODES # ################################################ NodeName=intel CPUs=32 Sockets=2 CoresPerSocket=16 ThreadsPerCore=1 State=UNKNOWN #NodeName=Dell Sockets=2 CoresPerSocket=24 ThreadsPerCore=1 RealMemory=100000 #NodeName=sw5a0[1-3] CPUS=4 Sockets=4 CoresPerSocket=1 ThreadsPerCore=1 RealMemory=1 NodeName=phytium CPUs=128 SocketsPerBoard=2 CoresPerSocket=64 ThreadsPerCore=1 State=UNKNOWN NodeName=swa CPUS=16 Sockets=16 CoresPerSocket=1 ThreadsPerCore=1 State=UNKNOWN NodeName=sw2cpu CPUs=64 Sockets=2 CoresPerSocket=32 ThreadsPerCore=1 State=UNKNOWN NodeName=mcn[01-02] CPUs=6 Sockets=6 CoresPerSocket=1 ThreadsPerCore=1 State=UNKNOWN NodeName=x86a,x86b,x86c CPUs=32 Sockets=2 CoresPerSocket=8 ThreadsPerCore=2 State=UNKNOWN # ################################################ # PARTITIONS # ################################################ #PartitionName=manycore Default=YES AllowGroups=all MinNodes=0 Nodes=sw5a0[1-3] State=UP PartitionName=q_Intel AllowGroups=all MinNodes=0 Nodes=intel State=UP PartitionName=q_Kylin AllowGroups=all MinNodes=0 Nodes=phytium State=UP PartitionName=q_sw6a AllowGroups=all MinNodes=0 Nodes=swa State=UP PartitionName=q_sw6b AllowGroups=all MinNodes=0 Nodes=sw2cpu State=UP PartitionName=q_sw9a AllowGroups=all MinNodes=0 Nodes=mcn[01-02] State=UP DEFAULT=YES PartitionName=q_x86 AllowGroups=all MinNodes=0 Nodes=x86a,x86b,x86c State=UP
-
