Python-turtle库绘制蚊香、走动的时钟和数码管日期
源码:
1 import turtle #导入turtle库,turtle库是python的基础绘图库 2 3 turtle.pensize(30) #设置画笔粗细 4 for i in range(30): 5 turtle.circle(i*10,60) #循环画圆30次,每次画60度并且半径增加10,也就是说画了30×60度的圆形,1800度,即5圈 6 turtle.done() #画完之后,使面板停留,否则画笔画完将自动关闭
效果图:
源码:
1 # -*- coding:utf-8 –*- 2 # 用turtlr画时钟 3 # 以自定义shape的方式实现 4 import turtle as t 5 import datetime as d 6 def skip(step): # 抬笔,跳到一个地方 7 t.penup() 8 t.forward(step) 9 t.pendown() 10 def drawClock(radius): # 画表盘 11 t.speed(0) 12 t.mode("logo") # 以Logo坐标、角度方式 13 t.hideturtle() 14 t.pensize(7) 15 t.home() # 回到圆点 16 for j in range(60): 17 skip(radius) 18 if (j % 5 == 0): 19 t.forward(20) 20 skip(-radius - 20) 21 else: 22 t.dot(5) 23 skip(-radius) 24 t.right(6) 25 def makePoint(pointName, len): # 钟的指针,时针、分针、秒针 26 t.penup() 27 t.home() 28 t.begin_poly() 29 t.back(0.1 * len) 30 t.forward(len * 1.1) 31 t.end_poly() 32 poly = t.get_poly() 33 t.register_shape(pointName, poly) # 注册为一个shape 34 def drawPoint(): # 画指针 35 global hourPoint, minPoint, secPoint, fontWriter 36 makePoint("hourPoint", 100) 37 makePoint("minPoint", 120) 38 makePoint("secPoint", 140) 39 hourPoint = t.Pen() # 每个指针是一只新turtle 40 hourPoint.shape("hourPoint") 41 hourPoint.shapesize(1, 1, 6) 42 minPoint = t.Pen() 43 minPoint.shape("minPoint") 44 minPoint.shapesize(1, 1, 4) 45 secPoint = t.Pen() 46 secPoint.shape("secPoint") 47 secPoint.pencolor('red') 48 fontWriter = t.Pen() 49 fontWriter.pencolor('gray') 50 fontWriter.hideturtle() 51 def getWeekName(weekday): 52 weekName = ['星期一', '星期二', '星期三', '星期四', '星期五', '星期六', '星期日'] 53 return weekName[weekday] 54 def getDate(year, month, day): 55 return "%s-%s-%s" % (year, month, day) 56 def realTime(): 57 curr = d.datetime.now() 58 curr_year = curr.year 59 curr_month = curr.month 60 curr_day = curr.day 61 curr_hour = curr.hour 62 curr_minute = curr.minute 63 curr_second = curr.second 64 curr_weekday = curr.weekday() 65 t.tracer(False) 66 secPoint.setheading(360 / 60 * curr_second) 67 minPoint.setheading(360 / 60 * curr_minute) 68 hourPoint.setheading(360 / 12 * curr_hour + 30 / 60 * curr_minute) 69 fontWriter.clear() 70 fontWriter.home() 71 fontWriter.penup() 72 fontWriter.forward(80) 73 # 用turtle写文字 74 fontWriter.write(getWeekName(curr_weekday), align="center", font=("Courier", 14, "bold")) 75 fontWriter.forward(-160) 76 fontWriter.write(getDate(curr_year, curr_month, curr_day), align="center", font=("Courier", 14, "bold")) 77 t.tracer(True) 78 print(curr_second) 79 t.ontimer(realTime, 100) # 每隔100毫秒调用一次realTime() 80 def main(): 81 t.tracer(False) 82 drawClock(160) 83 drawPoint() 84 realTime() 85 t.tracer(True) 86 t.mainloop() 87 if __name__ == '__main__': 88 main()
效果图:
源码:
1 import turtle as t 2 import datetime 3 def drawGap(): #绘制数码管间隔 4 t.penup() 5 t.fd(5) 6 def drawLine(draw): #绘制单段数码管 7 drawGap() 8 t.pendown() if draw else t.penup() 9 t.fd(40) 10 drawGap() 11 t.right(90) 12 def drawDigit(d): #根据数字绘制七段数码管 13 drawLine(True) if d in [2,3,4,5,6,8,9] else drawLine(False) 14 drawLine(True) if d in [0,1,3,4,5,6,7,8,9] else drawLine(False) 15 drawLine(True) if d in [0,2,3,5,6,8,9] else drawLine(False) 16 drawLine(True) if d in [0,2,6,8] else drawLine(False) 17 t.left(90) 18 drawLine(True) if d in [0,4,5,6,8,9] else drawLine(False) 19 drawLine(True) if d in [0,2,3,5,6,7,8,9] else drawLine(False) 20 drawLine(True) if d in [0,1,2,3,4,7,8,9] else drawLine(False) 21 t.left(180) 22 t.penup() 23 t.fd(20) 24 def drawDate(date): 25 t.pencolor("red") 26 for i in date: 27 if i == '-': 28 t.write('年', font=("Arial", 18, "normal")) 29 t.pencolor("green") 30 t.fd(40) 31 elif i == '=': 32 t.write('月', font=("Arial", 18, "normal")) 33 t.pencolor("blue") 34 t.fd(40) 35 elif i == '+': 36 t.write('日', font=("Arial", 18, "normal")) 37 else: 38 drawDigit(eval(i)) 39 def main(): 40 t.setup(800, 350, 200, 200) 41 t.penup() 42 t.fd(-350) 43 t.pensize(5) 44 drawDate(datetime.datetime.now().strftime('%Y-%m=%d+')) 45 t.hideturtle() 46 t.exitonclick() 47 main()
