MQTT

安装

服务端

# 配置 EMQX Yum 源
curl -s https://assets.emqx.com/scripts/install-emqx-rpm.sh | sudo bash
#安装 EMQX
yum install emqx -y
#启动 EMQX,开放端口
systemctl start emqx
#在浏览器输入服务器公网ip:18083，访问，进入登录界面admin/public
#配置文件：
/etc/emqx/emqx.conf

Ubuntu安装

curl -s https://assets.emqx.com/scripts/install-emqx-deb.sh | sudo bash
sudo apt-get install emqx
sudo emqx start

客户端

MQTTX

Java集成SrpingBoot

pom.xml

<!-- MQTT -->
<dependency>
	<groupId>org.springframework.integration</groupId>
	<artifactId>spring-integration-mqtt</artifactId>
	<version>5.5.12</version>
</dependency>
<dependency>
	<groupId>org.eclipse.paho</groupId>
	<artifactId>org.eclipse.paho.client.mqttv3</artifactId>
	<version>1.2.5</version>
</dependency>

application.yml

mqtt:
  broker:
    # 设备MQTT应用配置
    url: tcp://your_server_ip:1883
    username: your_username
    password: your_password
    # 自定义约定client_id
    clientId: your_client_id
  topics:
    # 默认监听
    default: your/default_topic
    # 自定义监听
    subscriptions:
      - your/topic1
      - your/topic2

# application.properties配置如下
# MQTT 设备应用配置
# mqtt.broker.url=tcp://your_server_ip:1883
# mqtt.broker.username=your_username
# mqtt.broker.password=your_password
# mqtt.broker.clientId=terminalTcpServer
# MQTT 监听的默认主题和自定义订阅主题
# mqtt.topics.default=your/default_topic
# mqtt.topics.subscriptions=your/topic1,your/topic2

MqttConfig配置类

import com.baoer.terminaltcpserver.mqtt.utils.MqttUtil;
import org.eclipse.paho.client.mqttv3.MqttConnectOptions;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.integration.annotation.ServiceActivator;
import org.springframework.integration.channel.DirectChannel;
import org.springframework.integration.core.MessageProducer;
import org.springframework.integration.mqtt.core.DefaultMqttPahoClientFactory;
import org.springframework.integration.mqtt.core.MqttPahoClientFactory;
import org.springframework.integration.mqtt.inbound.MqttPahoMessageDrivenChannelAdapter;
import org.springframework.integration.mqtt.outbound.MqttPahoMessageHandler;
import org.springframework.messaging.MessageChannel;
import org.springframework.messaging.MessageHandler;
import org.springframework.beans.factory.annotation.Autowired;

@Configuration
public class MqttConfig {

//    @Autowired
//    private MqttUtil mqttUtil;

    @Value("${mqtt.broker.url}")
    private String brokerUrl;

    @Value("${mqtt.broker.username}")
    private String username;

    @Value("${mqtt.broker.password}")
    private String password;

    @Value("${mqtt.broker.clientId}")
    private String clientId;

    @Value("${mqtt.topics.default}")
    private String defaultTopic;

    @Value("${mqtt.topics.subscriptions}")
    private String[] topics;

    // 配置MQTT客户端工厂
    @Bean
    public MqttPahoClientFactory mqttClientFactory() {
        DefaultMqttPahoClientFactory factory = new DefaultMqttPahoClientFactory();
        MqttConnectOptions options = new MqttConnectOptions();
        options.setServerURIs(new String[]{brokerUrl});
        options.setUserName(username);
        options.setPassword(password.toCharArray());

        // 设置自动重连
        options.setAutomaticReconnect(true);
        // 设置连接超时，单位为秒
        options.setConnectionTimeout(10);
        // 设置心跳时间，单位为秒
        options.setKeepAliveInterval(60);
        // Clean Start（会话清理），设置为 true 表示每次客户端连接服务器时清理会话
        options.setCleanSession(false);
        // 设置最大重连间隔时间，单位为秒
        options.setMaxReconnectDelay(60);

        factory.setConnectionOptions(options);
        return factory;
    }

    // （接收消息:步骤一）定义一个消息通道，用于接收消息
    @Bean
    public MessageChannel mqttInputChannel() {
        return new DirectChannel();
    }

    // （接收消息:步骤二）配置消息驱动通道适配器，用于接收指定主题的消息
    @Bean
    public MessageProducer inbound() {
        MqttPahoMessageDrivenChannelAdapter adapter =
                new MqttPahoMessageDrivenChannelAdapter(clientId + MqttClient.generateClientId(), mqttClientFactory(), topics);
        adapter.setOutputChannel(mqttInputChannel());
        return adapter;
    }

    // （接收消息:步骤三）配置消息处理器，用于处理接收到的消息
    @Bean
    @ServiceActivator(inputChannel = "mqttInputChannel")
    public MessageHandler handler(MqttUtil mqttUtil) {
        return message -> {
            String topic = message.getHeaders().get("mqtt_receivedTopic").toString();
            String payload = message.getPayload().toString();
            System.out.println("接收到消息: 主题 = " + topic + ", 内容 = " + payload);

            // 发布接收到的消息事件
            mqttUtil.publishReceivedMessage(topic, payload);
        };
    }

    // 配置MQTT消息发送处理器
    @Bean
    @ServiceActivator(inputChannel = "mqttOutboundChannel")
    public MessageHandler mqttOutbound() {
        MqttPahoMessageHandler messageHandler =
                new MqttPahoMessageHandler(clientId + MqttClient.generateClientId(), mqttClientFactory());
        messageHandler.setAsync(true);
        messageHandler.setDefaultTopic(defaultTopic); // 设置默认主题
        return messageHandler;
    }

    // 定义一个消息通道，用于发送消息
    @Bean
    public MessageChannel mqttOutboundChannel() {
        return new DirectChannel();
    }
}

MqttUtil 工具类

import com.baoer.terminaltcpserver.mqtt.config.MqttMessageEvent;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.context.ApplicationEventPublisher;
import org.springframework.messaging.MessageChannel;
import org.springframework.messaging.support.MessageBuilder;
import org.springframework.stereotype.Component;

@Component
public class MqttUtil {

    @Autowired
    private MessageChannel mqttOutboundChannel;

    @Autowired
    private ApplicationEventPublisher eventPublisher;

    /**
     * 发送消息到默认主题
     * @param payload 消息内容
     */
    public void sendMessage(String payload) {
        mqttOutboundChannel.send(MessageBuilder.withPayload(payload).build());
    }

    /**
     * 发送消息到指定主题
     * @param topic 主题
     * @param payload 消息内容
     */
    public void sendMessage(String topic, String payload) {
        mqttOutboundChannel.send(MessageBuilder.withPayload(payload)
                .setHeader("mqtt_topic", topic)
                .build());
    }

    /**
     * （接收消息:步骤四）发布接收到的MQTT消息事件
     * @param topic 主题
     * @param payload 消息内容
     */
    public void publishReceivedMessage(String topic, String payload) {
        MqttMessageEvent event = new MqttMessageEvent(this, topic, payload);
        eventPublisher.publishEvent(event);
    }
}

MqttMessageEvent消息事件类

import org.springframework.context.ApplicationEvent;

public class MqttMessageEvent extends ApplicationEvent {

    private final String topic;
    private final String payload;

    public MqttMessageEvent(Object source, String topic, String payload) {
        super(source);
        this.topic = topic;
        this.payload = payload;
    }

    public String getTopic() {
        return topic;
    }

    public String getPayload() {
        return payload;
    }
}

MqttMessageListener消息监听器

import org.springframework.context.event.EventListener;
import org.springframework.stereotype.Component;

@Component
public class MqttMessageListener {

    /**
     * （接收消息:步骤五）事件监听器中处理消息
     * 说明：此方法将接收到上方 MqttUtil.publishReceivedMessage() 发布的事件并处理这些消息
     *
     * @param event 接收到的事件
     */
    @EventListener
    public void handleMqttMessage(MqttMessageEvent event) {
        String topic = event.getTopic();
        String payload = event.getPayload();
        System.out.println("处理接收到的消息: 主题 = " + topic + ", 内容 = " + payload);

        // 根据不同的主题进行不同的处理
        if ("your/topic1".equals(topic)) {
            handleTopic1Message(payload);
        } else if ("your/topic2".equals(topic)) {
            handleTopic2Message(payload);
        }
    }

    private void handleTopic1Message(String payload) {
        // 处理来自 topic1 的消息
        System.out.println("处理 topic1 消息: " + payload);
    }

    private void handleTopic2Message(String payload) {
        // 处理来自 topic2 的消息
        System.out.println("处理 topic2 消息: " + payload);
    }
}

测试

import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;
import org.springframework.web.bind.annotation.RestController;

@RestController
@RequestMapping("/mqtt")
public class MqttController {

    @Autowired
    private MqttUtil mqttUtil;

    @RequestMapping("/send")
    @ResponseBody
    public String sendMessage() {
        mqttUtil.sendMessage("your/topic1", "Hello from Spring Boot");
        return "Message sent!";
    }
}

调用接口发送成功

使用MQTT X查看是否接受成功,并发送测试

查看EMQX Dashboard中MQTTX工具的连接

运行流程

1.在件中配置MQTT服务器的URL、用户名、密码、client_id、默认主题和订阅的主题。
2.启动MQTT Broker。
3.确保硬件设备连接到MQTT Broker，并发布和订阅消息。
4.启动Spring Boot应用程序，确保它可以发送和接收MQTT消息。
5.在控制台中查看接收到的消息，并根据不同的主题进行处理(设备上行消息要用不同的topic主题发布)。

遇到问题

o.s.i.m.outbound.MqttPahoMessageHandler : Lost connection

线上程序持续报错,有时能收到消息,能收到订阅的某些订阅消息,还有些订阅消息重启开始时能收到,但是发送指令后就没有了.后查验发现是发送消息的clientId和订阅消息时的客户端clientid不能一致,需要加上MqttClient.generateClientId()客户端代码

参考:
https://blog.csdn.net/weixin_43822632/article/details/141194093
