Society-HiSciTech-BigDataAIML+ICEE-Sensor-产业升级 + 应用: 自动/数字/智慧化: Temperature+Humidity+Pressure:温度/湿度/气/液体压强 传感器: TI + NXP+ Bosc环境感知传感器方案 + Sensiron 另外 传感器参数指标: 温度、湿度、气压、气流速、大气颗粒物浓度，CO₂/O₂浓度

  • 数字气象站:
    能提供 温度、湿度、气压、气流速、大气颗粒物浓度，CO₂/O₂浓度
  • 环境采集:
    室内: 温、湿、光、CO2采集,土壤温湿、PH、EC采集,
    户外: 雨雪、降雨量等气象采集;以及定时定量施肥灌溉系列。



行业应用

69



数字压力传感器:
MS5837-30BA @TE Connectivity Corporation
带有 I2C 总线接口的新一代高分辨率压力传感器，水深分辨率为 2 mm，适用于深度测量系统。
https://www.te.com.cn/chn-zh/product-CAT-BLPS0017.html

液/气体压强：
例如 NXP 的
https://www.nxp.com/docs/en/data-sheet/MPL3150A2.pdf

  • MPL3150A2
  • MPX5100, 0 to 100 kPa, Differential, Gauge, and Absolute, Integrated, Pressure Sensors

TI:

TI德仪的传感器
https://www.ti.com.cn/zh-cn/sensors/overview.html

Pressure

https://www.ti.com/lit/an/snaa127/snaa127.pdf

Humidity

https://www.ti.com.cn/zh-cn/sensors/humidity-sensors/products.html

Product Part No. Relative humidity
accuracy (typ.) (%RH)		 Relative humidity
operating range (typ.) (%RH)		 Temperature
accuracy (typ.) (°C)		 Price/Quantity (USD)
HDC3022-Q1 0.5 0 to 100 0.1 1.724



Bosch

https://www.bosch-sensortec.com/products/environmental-sensors/

  • BME280 : Humidity sensor: 3-in-1. 10 years delivery
    • barometric pressure
    • ambient temperature
    • Humidity sensor measuring relative humidity
  • BMP280 : an absolute barometric pressure sensor, Flexible. Stable performance.
    Parameter Technical data
    Operation range Pressure: 300...1100 hPa
    Temperature: -40…85°C
    Absolute accuracy: ±1 hPa, (950...1050 hPa, 0…+40°C)~
    Relative accuracy: ± 0.12 hPa (typical), p = 700…900hPa(Temp. @ 25°C), equivalent to ±1 m
    Average typical current consumption (1 Hz data rate): 3.4 μA @ 1 Hz
    Average current consumption (1 Hz data refresh rate): 2.74 μA, typical(ultra-low power mode)
    Average current consumption in sleep mode: 0.1 μA

Pressure

BMP585 Barometric pressure sensor
https://www.bosch-sensortec.com/products/environmental-sensors/pressure-sensors/bmp585/
With its extreme accuracy, BMP585 measures a change in height of just a few centimeters.
It can therefore detect movements in fitness training down to the level of individual pull-ups or push-ups.
At the same time, users do not have to worry about environmental conditions - thanks to its extreme ruggedness.

The BMP585 has a gel-filled cavity that allows highest protection against water and other liquids such as chemicals with the suitable integration concept. The sensor can be used for applications like height measurement, water-level detection and navigation with a maximum absolute accuracy of ±50 Pa and an temperature coefficient offset (TCO) of ±0.5 Pa/K.

Humidity

BME280Combined humidity and pressure sensor
BME280 Digital humidity, pressure and temperature sensor
Key features
• Package 2.5 mm x 2.5 mm x 0.93 mm metal lid LGA
• Digital interface I²C (up to 3.4 MHz) and SPI (3 and 4 wire, up to 10 MHz)
• Supply voltage
VDD main supply voltage range: 1.71 V to 3.6 V
VDDIO interface voltage range: 1.2 V to 3.6 V
• Current consumption
1.8 µA @ 1 Hz humidity and temperature
2.8 µA @ 1 Hz pressure and temperature
3.6 µA @ 1 Hz humidity, pressure and temperature
0.1 µA in sleep mode
• Operating range -40…+85 °C, 0…100 % rel. humidity, 300…1100 hPa
• Humidity sensor and pressure sensor can be independently enabled / disabled
• Register and performance compatible to Bosch Sensortec BMP280 digital pressure sensor
• RoHS compliant, halogen-free, MSL1

Key parameters for humidity sensor
• Response time (𝜏𝜏63%) 1 s
• Accuracy tolerance ±3 % relative humidity
• Hysteresis ±1% relative humidity

Key parameters for pressure sensor
• RMS Noise 0.2 Pa, equiv. to 1.7 cm
• Offset temperature coefficient ±1.5 Pa/K, equiv. to ±12.6 cm at 1 °C temperature change

BME688: https://www.bosch-sensortec.com/products/environmental-sensors/gas-sensors/bme688/
Key parameters for gas sensor
F1 score for H2S scanning 0.94
Standard scan speed 10.8 s / scan 
Electric charge for standard scan 0.18 mAh (5 scans ~ 1 min)
Power consumption < 0.1 mA in ultra-low power mode
Output data processing Major direct outputs: Index for Air Quality (IAQ), bVOC- & CO2-equivalents (ppm), Gas scan result (%) & Intensity level (all listed in Table 20: BSEC outputs)

Key parameters for humidity sensor
Response time (𝜏0−63%) ~8 s
Accuracy tolerance ±3% r.H.
Hysteresis ±1.5% r.H.

Key parameters for pressure sensor
RMS Noise 0.12 Pa, equiv. to 1.7 cm
Offset temperature coefficient ±1.3 Pa/K, equiv. to ±10.9 cm at 1 °C temperature change

Key parameters for temperature sensor
Absolute accuracy ±0.5 °C (0 - 65°C)



Sensirion

Humidity

https://sensirion.com/cn/products/product-catalog?page=1&perPage=12&category=湿度&status=new&class=sensor

SEN68
即将到来
Available Q3 2025
PM, RH/T, VOC, Nox和HCHO测量传感器平台
通过小巧而强大的SEN68传感器平台体验空气质量传感的未来。SEN65以前所未有的紧凑外形集成了多个传感器，可以测量多达9种环境参数(PM1, PM2.5, PM4, PM10, T, RH, VOC指数，NOx指数，HCHO)，其核心组件是一颗全新小型化的，基于mems技术的颗粒物传感器——SPS6x。创新的设计大大简化了集成，降低了成本，并支持定制。

SEN68适配于需要符合不同室内空气质量标准的应用，如RESET®，WELL建筑标准™和California Title 24建筑能效标准。

点击这里了解更多SEN6x系列

规范

微粒物质
质量浓度范围 0 - 1000 μg/m³

温度
典型温度精度 0.45 °C

湿度
典型的相对湿度精度 4.5 %RH

VOC
传感器输出 0-500 VOC Index

甲醛
测量范围 0 - 1000 ppb
准确度 ±20 % m.v.

Generic
接口 I²C
尺寸 (长x宽x高) 55.5 x 25.6 x 21.5 mm³

下载
