Jmeter-测试报告模板分享
1、jmeter-results-detail-report_21
<?xml version="1.0"?> <!-- ~ Licensed to the Apache Software Foundation (ASF) under one or more ~ contributor license agreements. See the NOTICE file distributed with ~ this work for additional information regarding copyright ownership. ~ The ASF licenses this file to you under the Apache License, Version 2.0 ~ (the "License"); you may not use this file except in compliance with ~ the License. You may obtain a copy of the License at ~ ~ http://www.apache.org/licenses/LICENSE-2.0 ~ ~ Unless required by applicable law or agreed to in writing, software ~ distributed under the License is distributed on an "AS IS" BASIS, ~ WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. ~ See the License for the specific language governing permissions and ~ limitations under the License. --> <xsl:stylesheet xmlns:xsl="http://www.w3.org/1999/XSL/Transform" version="1.0"> <!-- Licensed to the Apache Software Foundation (ASF) under one or more contributor license agreements. See the NOTICE file distributed with this work for additional information regarding copyright ownership. The ASF licenses this file to You under the Apache License, Version 2.0 (the "License"); you may not use this file except in compliance with the License. You may obtain a copy of the License at http://www.apache.org/licenses/LICENSE-2.0 Unless required by applicable law or agreed to in writing, software distributed under the License is distributed on an "AS IS" BASIS, WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the License for the specific language governing permissions and limitations under the License. --> <!-- Stylesheet for processing 2.1 output format test result files To uses this directly in a browser, add the following to the JTL file as line 2: <?xml-stylesheet type="text/xsl" href="../extras/jmeter-results-detail-report_21.xsl"?> and you can then view the JTL in a browser --> <xsl:output method="html" indent="yes" encoding="UTF-8" doctype-public="-//W3C//DTD HTML 4.01 Transitional//EN" /> <!-- Defined parameters (overrideable) --> <xsl:param name="showData" select="'n'"/> <xsl:param name="titleReport" select="'Load Test Results'"/> <xsl:param name="dateReport" select="'date not defined'"/> <xsl:template match="testResults"> <html> <head> <title><xsl:value-of select="$titleReport" /></title> <style type="text/css"> body { font:normal 68% verdana,arial,helvetica; color:#000000; } table tr td, table tr th { font-size: 68%; } table.details tr th{ color: #ffffff; font-weight: bold; text-align:center; background:#2674a6; white-space: nowrap; } table.details tr td{ background:#eeeee0; white-space: nowrap; } h1 { margin: 0px 0px 5px; font: 165% verdana,arial,helvetica } h2 { margin-top: 1em; margin-bottom: 0.5em; font: bold 125% verdana,arial,helvetica } h3 { margin-bottom: 0.5em; font: bold 115% verdana,arial,helvetica } .Failure { font-weight:bold; color:red; } img { border-width: 0px; } .expand_link { position=absolute; right: 0px; width: 27px; top: 1px; height: 27px; } .page_details { display: none; } .page_details_expanded { display: block; display/* hide this definition from IE5/6 */: table-row; } </style> <script language="JavaScript"><![CDATA[ function expand(details_id) { document.getElementById(details_id).className = "page_details_expanded"; } function collapse(details_id) { document.getElementById(details_id).className = "page_details"; } function change(details_id) { if(document.getElementById(details_id+"_image").src.match("expand")) { document.getElementById(details_id+"_image").src = "collapse.png"; expand(details_id); } else { document.getElementById(details_id+"_image").src = "expand.png"; collapse(details_id); } } ]]></script> </head> <body> <xsl:call-template name="pageHeader" /> <xsl:call-template name="summary" /> <hr size="1" width="95%" align="center" /> <xsl:call-template name="pagelist" /> <hr size="1" width="95%" align="center" /> <xsl:call-template name="detail" /> </body> </html> </xsl:template> <xsl:template name="pageHeader"> <h1><xsl:value-of select="$titleReport" /></h1> <table width="100%"> <tr> <td align="left">Date report: <xsl:value-of select="$dateReport" /></td> <td align="right">Designed for use with <a href="http://jmeter.apache.org/">JMeter</a> and <a href="http://ant.apache.org">Ant</a>.</td> </tr> </table> <hr size="1" /> </xsl:template> <xsl:template name="summary"> <h2>Summary</h2> <table align="center" class="details" border="0" cellpadding="5" cellspacing="2" width="95%"> <tr valign="top"> <th># Samples</th> <th>Failures</th> <th>Success Rate</th> <th>Average Time</th> <th>Min Time</th> <th>Max Time</th> </tr> <tr valign="top"> <xsl:variable name="allCount" select="count(/testResults/*)" /> <xsl:variable name="allFailureCount" select="count(/testResults/*[attribute::s='false'])" /> <xsl:variable name="allSuccessCount" select="count(/testResults/*[attribute::s='true'])" /> <xsl:variable name="allSuccessPercent" select="$allSuccessCount div $allCount" /> <xsl:variable name="allTotalTime" select="sum(/testResults/*/@t)" /> <xsl:variable name="allAverageTime" select="$allTotalTime div $allCount" /> <xsl:variable name="allMinTime"> <xsl:call-template name="min"> <xsl:with-param name="nodes" select="/testResults/*/@t" /> </xsl:call-template> </xsl:variable> <xsl:variable name="allMaxTime"> <xsl:call-template name="max"> <xsl:with-param name="nodes" select="/testResults/*/@t" /> </xsl:call-template> </xsl:variable> <xsl:attribute name="class"> <xsl:choose> <xsl:when test="$allFailureCount > 0">Failure</xsl:when> </xsl:choose> </xsl:attribute> <td align="center"> <xsl:value-of select="$allCount" /> </td> <td align="center"> <xsl:value-of select="$allFailureCount" /> </td> <td align="center"> <xsl:call-template name="display-percent"> <xsl:with-param name="value" select="$allSuccessPercent" /> </xsl:call-template> </td> <td align="center"> <xsl:call-template name="display-time"> <xsl:with-param name="value" select="$allAverageTime" /> </xsl:call-template> </td> <td align="center"> <xsl:call-template name="display-time"> <xsl:with-param name="value" select="$allMinTime" /> </xsl:call-template> </td> <td align="center"> <xsl:call-template name="display-time"> <xsl:with-param name="value" select="$allMaxTime" /> </xsl:call-template> </td> </tr> </table> </xsl:template> <xsl:template name="pagelist"> <h2>Pages</h2> <table align="center" class="details" border="0" cellpadding="5" cellspacing="2" width="95%"> <tr valign="top"> <th>URL</th> <th># Samples</th> <th>Failures</th> <th>Success Rate</th> <th>Average Time</th> <th>Min Time</th> <th>Max Time</th> <th></th> </tr> <xsl:for-each select="/testResults/*[not(@lb = preceding::*/@lb)]"> <xsl:variable name="label" select="@lb" /> <xsl:variable name="count" select="count(../*[@lb = current()/@lb])" /> <xsl:variable name="failureCount" select="count(../*[@lb = current()/@lb][attribute::s='false'])" /> <xsl:variable name="successCount" select="count(../*[@lb = current()/@lb][attribute::s='true'])" /> <xsl:variable name="successPercent" select="$successCount div $count" /> <xsl:variable name="totalTime" select="sum(../*[@lb = current()/@lb]/@t)" /> <xsl:variable name="averageTime" select="$totalTime div $count" /> <xsl:variable name="minTime"> <xsl:call-template name="min"> <xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" /> </xsl:call-template> </xsl:variable> <xsl:variable name="maxTime"> <xsl:call-template name="max"> <xsl:with-param name="nodes" select="../*[@lb = current()/@lb]/@t" /> </xsl:call-template> </xsl:variable> <tr valign="top"> <xsl:attribute name="class"> <xsl:choose> <xsl:when test="$failureCount > 0">Failure</xsl:when> </xsl:choose> </xsl:attribute> <td> <xsl:if test="$failureCount > 0"> <a><xsl:attribute name="href">#<xsl:value-of select="$label" /></xsl:attribute> <xsl:value-of select="$label" /> </a> </xsl:if> <xsl:if test="0 >= $failureCount"> <xsl:value-of select="$label" /> </xsl:if> </td> <td align="center"> <xsl:value-of select="$count" /> </td> <td align="center"> <xsl:value-of select="$failureCount" /> </td> <td align="right"> <xsl:call-template name="display-percent"> <xsl:with-param name="value" select="$successPercent" /> </xsl:call-template> </td> <td align="right"> <xsl:call-template name="display-time"> <xsl:with-param name="value" select="$averageTime" /> </xsl:call-template> </td> <td align="right"> <xsl:call-template name="display-time"> <xsl:with-param name="value" select="$minTime" /> </xsl:call-template> </td> <td align="right"> <xsl:call-template name="display-time"> <xsl:with-param name="value" select="$maxTime" /> </xsl:call-template> </td> <td align="center"> <a href=""> <xsl:attribute name="href"><xsl:text/>javascript:change('page_details_<xsl:value-of select="position()" />')</xsl:attribute> <img src="expand.png" alt="expand/collapse"><xsl:attribute name="id"><xsl:text/>page_details_<xsl:value-of select="position()" />_image</xsl:attribute></img> </a> </td> </tr> <tr class="page_details"> <xsl:attribute name="id"><xsl:text/>page_details_<xsl:value-of select="position()" /></xsl:attribute> <td colspan="8" bgcolor="#FF0000"> <div align="center"> <b>Details for Page "<xsl:value-of select="$label" />"</b> <table bordercolor="#000000" bgcolor="#2674A6" border="0" cellpadding="1" cellspacing="1" width="95%"> <tr> <th>Thread</th> <th>Iteration</th> <th>Time (milliseconds)</th> <th>Bytes</th> <th>Success</th> </tr> <xsl:for-each select="../*[@lb = $label and @tn != $label]"> <tr> <td><xsl:value-of select="@tn" /></td> <td align="center"><xsl:value-of select="position()" /></td> <td align="right"><xsl:value-of select="@t" /></td> <!-- TODO allow for missing bytes field --> <td align="right"><xsl:value-of select="@by" /></td> <td align="center"><xsl:value-of select="@s" /></td> </tr> </xsl:for-each> </table> </div> </td> </tr> </xsl:for-each> </table> </xsl:template> <xsl:template name="detail"> <xsl:variable name="allFailureCount" select="count(/testResults/*[attribute::s='false'])" /> <xsl:if test="$allFailureCount > 0"> <h2>Failure Detail</h2> <xsl:for-each select="/testResults/*[not(@lb = preceding::*/@lb)]"> <xsl:variable name="failureCount" select="count(../*[@lb = current()/@lb][attribute::s='false'])" /> <xsl:if test="$failureCount > 0"> <h3><xsl:value-of select="@lb" /><a><xsl:attribute name="name"><xsl:value-of select="@lb" /></xsl:attribute></a></h3> <table align="center" class="details" border="0" cellpadding="5" cellspacing="2" width="95%"> <tr valign="top"> <th>Response</th> <th>Failure Message</th> <xsl:if test="$showData = 'y'"> <th>Response Data</th> </xsl:if> </tr> <xsl:for-each select="/testResults/*[@lb = current()/@lb][attribute::s='false']"> <tr> <td><xsl:value-of select="@rc | @rs" /> - <xsl:value-of select="@rm" /></td> <td><xsl:value-of select="assertionResult/failureMessage" /></td> <xsl:if test="$showData = 'y'"> <td><xsl:value-of select="./binary" /></td> </xsl:if> </tr> </xsl:for-each> </table> </xsl:if> </xsl:for-each> </xsl:if> </xsl:template> <xsl:template name="min"> <xsl:param name="nodes" select="/.." /> <xsl:choose> <xsl:when test="not($nodes)">NaN</xsl:when> <xsl:otherwise> <xsl:for-each select="$nodes"> <xsl:sort data-type="number" /> <xsl:if test="position() = 1"> <xsl:value-of select="number(.)" /> </xsl:if> </xsl:for-each> </xsl:otherwise> </xsl:choose> </xsl:template> <xsl:template name="max"> <xsl:param name="nodes" select="/.." /> <xsl:choose> <xsl:when test="not($nodes)">NaN</xsl:when> <xsl:otherwise> <xsl:for-each select="$nodes"> <xsl:sort data-type="number" order="descending" /> <xsl:if test="position() = 1"> <xsl:value-of select="number(.)" /> </xsl:if> </xsl:for-each> </xsl:otherwise> </xsl:choose> </xsl:template> <xsl:template name="display-percent"> <xsl:param name="value" /> <xsl:value-of select="format-number($value,'0.00%')" /> </xsl:template> <xsl:template name="display-time"> <xsl:param name="value" /> <xsl:value-of select="format-number($value,'0 ms')" /> </xsl:template> </xsl:stylesheet>
样式概览：
2、jmeter.results.shanhe.me
样式概览：
3、jmeter.results.shanhe.lm
样式概览：
补充：如果想在报告详情打印 Response Data，需要在Jmeter安装目录下找到 jmeter.properties 文件，搜索 jmeter.save.saveservice.response_data 属性，并将其设置为 true
4、jmeter.results.shanhe.mk
样式概览：
注：格式为.xsl
如果有更好的报告模板欢迎分享！(*^▽^*)
