WPF Circle rotate image source defined as usercontrol

复制代码
<Ellipse x:Name="elp"
         Panel.ZIndex="2"
         Grid.Row="1"
         Grid.Column="0"
         Grid.ColumnSpan="2"
         Width="{Binding ActualHeight,RelativeSource={RelativeSource Mode=FindAncestor,AncestorType={x:Type UserControl}},
         Converter={StaticResource sizeConverter},
         ConverterParameter=1.5}"
         Height="{Binding ActualHeight,RelativeSource={RelativeSource Mode=FindAncestor,AncestorType={x:Type UserControl}},
         Converter={StaticResource sizeConverter},
         ConverterParameter=1.5}"
         MouseDown="elp_MouseDown"
         MouseMove="elp_MouseMove"
         MouseUp="elp_MouseUp"
         RenderTransformOrigin="0.5,0.5">
    <Ellipse.RenderTransform>
        <RotateTransform x:Name="rotateTransform"/>
    </Ellipse.RenderTransform>
    <!--<Ellipse.Fill>
        <LinearGradientBrush StartPoint="0,0"
                     EndPoint="0,1">
            <GradientStop Color="Orange" Offset="0.0"/>
            <GradientStop Color="Orange" Offset="0.2"/>
            <GradientStop Color="Yellow" Offset="0.2"/>
            <GradientStop Color="Yellow" Offset="0.4"/>
            <GradientStop Color="Green" Offset="0.4"/>
            <GradientStop Color="Green" Offset="0.495"/>
            <GradientStop Color="Red" Offset="0.495"/>
            <GradientStop Color="Red" Offset="0.505"/>
            <GradientStop Color="Green" Offset="0.505"/>
            <GradientStop Color="Green" Offset="0.6"/>
            <GradientStop Color="Cyan" Offset="0.6"/>
            <GradientStop Color="Cyan" Offset="0.8"/>
            <GradientStop Color="Blue" Offset="0.8"/>
            <GradientStop Color="Blue" Offset="1.0"/>
        </LinearGradientBrush>
    </Ellipse.Fill>-->
    <Ellipse.Fill>
        <ImageBrush ImageSource="{Binding UCImgSource,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"/>
    </Ellipse.Fill>
</Ellipse>


//cs
public ImageSource UCImgSource
{
    get { return (ImageSource)GetValue(UCImgSourceProperty); }
    set { SetValue(UCImgSourceProperty, value); }
}

// Using a DependencyProperty as the backing store for UCImgSource.  This enables animation, styling, binding, etc...
public static readonly DependencyProperty UCImgSourceProperty =
    DependencyProperty.Register("UCImgSource", typeof(ImageSource),
        typeof(UCRotateCircle), new PropertyMetadata(GetImgSourceViaUrl()));


private static ImageSource GetImgSourceViaUrl(string imgUrl = @"../../../Images/1.jpg")
{
    if (!File.Exists(imgUrl))
    {
        return null;
    }
    BitmapImage bmi = new BitmapImage();
    bmi.BeginInit();
    bmi.UriSource = new Uri(imgUrl, UriKind.RelativeOrAbsolute);
    bmi.EndInit();
    if (bmi.CanFreeze)
    {
        bmi.Freeze();
    }
    return bmi;
}
复制代码





//All

复制代码
//usercontrol.xaml
<UserControl x:Class="WpfApp159.UCRotateCircle"
             xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
             xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
             xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
             xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
             xmlns:local="clr-namespace:WpfApp159"
             xmlns:behavior="http://schemas.microsoft.com/xaml/behaviors"
             mc:Ignorable="d"
             d:DesignHeight="450" d:DesignWidth="800">
    <UserControl.Resources>
        <local:SizeConverter x:Key="sizeConverter"/>
    </UserControl.Resources>
    <Grid>
        <Grid.RowDefinitions>
            <RowDefinition/>
            <RowDefinition Height="10*"/>
        </Grid.RowDefinitions>
        <Grid.ColumnDefinitions>
            <ColumnDefinition/>
            <ColumnDefinition/>
        </Grid.ColumnDefinitions>
        <TextBlock Grid.Row="0"
                   Grid.Column="0"
                   Grid.ColumnSpan="2"
                   FontSize="15"
                   Foreground="Red"
                   FontWeight="Bold"
                   HorizontalAlignment="Center"
                   Text="{Binding UCRotatedAngleStr,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"/>
        <Ellipse x:Name="elp"
                 Panel.ZIndex="2"
                 Grid.Row="1"
                 Grid.Column="0"
                 Grid.ColumnSpan="2"
                 Width="{Binding ActualHeight,RelativeSource={RelativeSource Mode=FindAncestor,AncestorType={x:Type UserControl}},
                 Converter={StaticResource sizeConverter},
                 ConverterParameter=1.5}"
                 Height="{Binding ActualHeight,RelativeSource={RelativeSource Mode=FindAncestor,AncestorType={x:Type UserControl}},
                 Converter={StaticResource sizeConverter},
                 ConverterParameter=1.5}"
                 MouseDown="elp_MouseDown"
                 MouseMove="elp_MouseMove"
                 MouseUp="elp_MouseUp"
                 RenderTransformOrigin="0.5,0.5">
            <Ellipse.RenderTransform>
                <RotateTransform x:Name="rotateTransform"/>
            </Ellipse.RenderTransform>
            <!--<Ellipse.Fill>
                <LinearGradientBrush StartPoint="0,0"
                             EndPoint="0,1">
                    <GradientStop Color="Orange" Offset="0.0"/>
                    <GradientStop Color="Orange" Offset="0.2"/>
                    <GradientStop Color="Yellow" Offset="0.2"/>
                    <GradientStop Color="Yellow" Offset="0.4"/>
                    <GradientStop Color="Green" Offset="0.4"/>
                    <GradientStop Color="Green" Offset="0.495"/>
                    <GradientStop Color="Red" Offset="0.495"/>
                    <GradientStop Color="Red" Offset="0.505"/>
                    <GradientStop Color="Green" Offset="0.505"/>
                    <GradientStop Color="Green" Offset="0.6"/>
                    <GradientStop Color="Cyan" Offset="0.6"/>
                    <GradientStop Color="Cyan" Offset="0.8"/>
                    <GradientStop Color="Blue" Offset="0.8"/>
                    <GradientStop Color="Blue" Offset="1.0"/>
                </LinearGradientBrush>
            </Ellipse.Fill>-->
            <Ellipse.Fill>
                <ImageBrush ImageSource="{Binding UCImgSource,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"/>
            </Ellipse.Fill>
        </Ellipse>
        <Border Grid.Row="1"
                Grid.Column="0"
                Grid.ColumnSpan="2"
                Panel.ZIndex="1"
                HorizontalAlignment="Stretch"
                VerticalAlignment="Center"
                Background="Black"
                Width="{Binding ActualHeight,RelativeSource={RelativeSource Mode=FindAncestor,AncestorType={x:Type UserControl}},
                Converter={StaticResource sizeConverter},
                ConverterParameter=1.2}"
                Height="20"
                RenderTransformOrigin="0.5,0.5" >
            <Border.RenderTransform>
                <RotateTransform x:Name="borderRotateTransform"
                                 Angle="{Binding UCBorderAnge,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"/>
            </Border.RenderTransform>
        </Border>
        <Grid Grid.Row="1"
              Grid.RowSpan="2"
              Grid.Column="0"
              Panel.ZIndex="0"
              Background="LightCyan">
            <behavior:Interaction.Triggers>
                <behavior:EventTrigger EventName="MouseLeftButtonDown">
                    <behavior:InvokeCommandAction Command="{Binding UCLeftClickCommand}"/>
                </behavior:EventTrigger>
            </behavior:Interaction.Triggers>
        </Grid>
        <Grid Grid.Row="1"
              Grid.RowSpan="2"
              Grid.Column="1"
              Panel.ZIndex="0"
              Background="LightBlue">
            <behavior:Interaction.Triggers>
                <behavior:EventTrigger EventName="MouseLeftButtonDown">
                    <behavior:InvokeCommandAction Command="{Binding UCRightClickCommand}"/>
                </behavior:EventTrigger>
            </behavior:Interaction.Triggers>
        </Grid>
    </Grid>
</UserControl>


//usercontrol.xaml.cs
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Globalization;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;
using System.IO;

namespace WpfApp159
{
    /// <summary>
    /// Interaction logic for UCRotateCircle.xaml
    /// </summary>
    public partial class UCRotateCircle : UserControl, INotifyPropertyChanged
    {
        public UCRotateCircle()
        {
            InitializeComponent();
            this.DataContext = this;
        }

        Point originPt { get; set; }
        Point currentPt { get; set; }

        protected override void OnRenderSizeChanged(SizeChangedInfo sizeInfo)
        {
            base.OnRenderSizeChanged(sizeInfo);
            Point tempPt = new Point(elp.ActualWidth / 2, elp.ActualHeight / 2);
            originPt = elp.TranslatePoint(tempPt, this);
        }


        public double UCConverterParameter
        {
            get { return (double)GetValue(UCConverterParameterProperty); }
            set { SetValue(UCConverterParameterProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCConverterParameter.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCConverterParameterProperty =
            DependencyProperty.Register("UCConverterParameter", typeof(double),
                typeof(UCRotateCircle), new PropertyMetadata(2.0d));




        public string UCRotatedAngleStr
        {
            get { return (string)GetValue(UCRotatedAngleStrProperty); }
            set { SetValue(UCRotatedAngleStrProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCRotatedAngleStr.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCRotatedAngleStrProperty =
            DependencyProperty.Register("UCRotatedAngleStr", typeof(string),
                typeof(UCRotateCircle), new PropertyMetadata("0"));

        public event PropertyChangedEventHandler? PropertyChanged;
        private void OnPropertyChanged(string propName)
        {
            var handler = PropertyChanged;
            if (handler != null)
            {
                handler?.Invoke(this, new PropertyChangedEventArgs(propName));
            }
        }

        private double convertPara = 2.0d;
        public double ConvertPara
        {
            get
            {
                return convertPara;
            }
            set
            {
                if (value != convertPara)
                {
                    convertPara = value;
                    OnPropertyChanged(nameof(ConvertPara));
                }
            }
        }

        private void elp_MouseDown(object sender, MouseButtonEventArgs e)
        {
            if (e.LeftButton == MouseButtonState.Pressed)
            {
                currentPt = e.GetPosition(this);
                elp.CaptureMouse();
            }
        }

        private void elp_MouseMove(object sender, MouseEventArgs e)
        {
            if (e.LeftButton == MouseButtonState.Pressed)
            {
                Vector prevVec = Point.Subtract(currentPt, originPt);
                Point newPt = e.GetPosition(this);
                Vector newVec = Point.Subtract(newPt, originPt);
                double deltaAngle = Vector.AngleBetween(prevVec, newVec);
                rotateTransform.Angle += deltaAngle;
                currentPt = newPt;
                UCRotatedAngleStr = Math.Round(rotateTransform.Angle, 2).ToString();
                System.Diagnostics.Debug.WriteLine($"{deltaAngle},{rotateTransform.Angle}");
            }
        }

        private void elp_MouseUp(object sender, MouseButtonEventArgs e)
        {
            if (e.LeftButton == MouseButtonState.Released)
            {
                elp.ReleaseMouseCapture();
            }
        }




        public double UCBorderAnge
        {
            get { return (double)GetValue(UCBorderAngeProperty); }
            set { SetValue(UCBorderAngeProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCBorderAnge.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCBorderAngeProperty =
            DependencyProperty.Register("UCBorderAnge", typeof(double),
                typeof(UCRotateCircle), new PropertyMetadata(45.0d));




        public ICommand UCLeftClickCommand
        {
            get { return (ICommand)GetValue(UCLeftClickCommandProperty); }
            set { SetValue(UCLeftClickCommandProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCLeftClickCommand.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCLeftClickCommandProperty =
            DependencyProperty.Register("UCLeftClickCommand", typeof(ICommand),
                typeof(UCRotateCircle), new PropertyMetadata(null));





        public ICommand UCRightClickCommand
        {
            get { return (ICommand)GetValue(UCRightClickCommandProperty); }
            set { SetValue(UCRightClickCommandProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCRightClickCommand.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCRightClickCommandProperty =
            DependencyProperty.Register("UCRightClickCommand", typeof(ICommand),
                typeof(UCRotateCircle), new PropertyMetadata(null));





        public ImageSource UCImgSource
        {
            get { return (ImageSource)GetValue(UCImgSourceProperty); }
            set { SetValue(UCImgSourceProperty, value); }
        }

        // Using a DependencyProperty as the backing store for UCImgSource.  This enables animation, styling, binding, etc...
        public static readonly DependencyProperty UCImgSourceProperty =
            DependencyProperty.Register("UCImgSource", typeof(ImageSource),
                typeof(UCRotateCircle), new PropertyMetadata(GetImgSourceViaUrl()));


        private static ImageSource GetImgSourceViaUrl(string imgUrl = @"../../../Images/1.jpg")
        {
            if (!File.Exists(imgUrl))
            {
                return null;
            }
            BitmapImage bmi = new BitmapImage();
            bmi.BeginInit();
            bmi.UriSource = new Uri(imgUrl, UriKind.RelativeOrAbsolute);
            bmi.EndInit();
            if (bmi.CanFreeze)
            {
                bmi.Freeze();
            }
            return bmi;
        }
    }

    public class SizeConverter : IValueConverter
    {
        public object Convert(object value, Type targetType, object parameter, CultureInfo culture)
        {
            double dValue = 0.0, dPara = 0.0;
            if (double.TryParse(value?.ToString(), out dValue)
                && double.TryParse(parameter?.ToString(), out dPara)
                && dPara > 0)
            {
                return dValue / dPara;
            }
            return dValue;
        }

        public object ConvertBack(object value, Type targetType, object parameter, CultureInfo culture)
        {
            throw new NotImplementedException();
        }
    }


    public class DelCommand : ICommand
    {
        private Action<object?> execute;
        private Predicate<object?> canExecute;
        public DelCommand(Action<object?> executeValue, Predicate<object?> canExecuteValue = null)
        {
            execute = executeValue;
            canExecute = canExecuteValue;
        }

        public event EventHandler? CanExecuteChanged
        {
            add
            {
                CommandManager.RequerySuggested += value;
            }
            remove
            {
                CommandManager.RequerySuggested -= value;
            }
        }

        public bool CanExecute(object? parameter)
        {
            if (canExecute == null)
            {
                return true;
            }
            return canExecute(parameter);
        }

        public void Execute(object? parameter)
        {
            execute(parameter);
        }
    }
}


//window.xaml
<Window x:Class="WpfApp159.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
        xmlns:local="clr-namespace:WpfApp159"
        mc:Ignorable="d"
        Title="MainWindow" Height="450" Width="800">
    <Grid>
        <Grid.RowDefinitions>
            <RowDefinition/>
            <RowDefinition/>
        </Grid.RowDefinitions>
        <Grid.ColumnDefinitions>
            <ColumnDefinition/>
            <ColumnDefinition/>
        </Grid.ColumnDefinitions>
        <local:UCRotateCircle Grid.Row="0"
                              Grid.Column="0"
                              x:Name="firstRotateCircle"
                              UCImgSource="{Binding DataContext.FirstImgSource,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                              UCBorderAnge="{Binding DataContext.FirstBorderAnge,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                              UCLeftClickCommand="{Binding DataContext.FirstLeftClickCommand,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=OneWay,UpdateSourceTrigger=PropertyChanged}"
                              UCRightClickCommand="{Binding DataContext.FirstRightClickCommand,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=OneWay,UpdateSourceTrigger=PropertyChanged}"/>
        <local:UCRotateCircle Grid.Row="0"
                              Grid.Column="1"
                              x:Name="secondRotateCircle"
                              UCImgSource="{Binding DataContext.SecondImgSource,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                              UCBorderAnge="{Binding DataContext.SecondBorderAnge,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                              UCLeftClickCommand="{Binding DataContext.SecondToggleBorderAngleCommand,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=OneWay,UpdateSourceTrigger=PropertyChanged}"
                              UCRightClickCommand="{Binding DataContext.SecondToggleBorderAngleCommand,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=OneWay,UpdateSourceTrigger=PropertyChanged}"/>
        <local:UCRotateCircle Grid.Row="1"
                              Grid.Column="0"
                              x:Name="thirdRotateCircle"
                              UCImgSource="{Binding DataContext.ThirdImgSource,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                              UCBorderAnge="{Binding DataContext.ThirdBorderAnge,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                              UCLeftClickCommand="{Binding DataContext.ThirdToggleBorderAngleCommand,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=OneWay,UpdateSourceTrigger=PropertyChanged}"
                              UCRightClickCommand="{Binding DataContext.ThirdToggleBorderAngleCommand,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=OneWay,UpdateSourceTrigger=PropertyChanged}"/>
        <local:UCRotateCircle Grid.Row="1"
                              Grid.Column="1"
                              x:Name="forthRotateCircle"
                              UCImgSource="{Binding DataContext.ForthImgSource,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                              UCBorderAnge="{Binding DataContext.ForthBorderAnge,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"
                              UCLeftClickCommand="{Binding DataContext.ForthToggleBorderAngleCommand,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=OneWay,UpdateSourceTrigger=PropertyChanged}"
                              UCRightClickCommand="{Binding DataContext.ForthToggleBorderAngleCommand,RelativeSource={RelativeSource Mode=FindAncestor,
                              AncestorType={x:Type Window}},Mode=OneWay,UpdateSourceTrigger=PropertyChanged}"/>
    </Grid>
</Window>



//window.cs
using System.ComponentModel;
using System.IO;
using System.Text;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Converters;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;

namespace WpfApp159
{
    /// <summary>
    /// Interaction logic for MainWindow.xaml
    /// </summary>
    public partial class MainWindow : Window
    {
        public MainWindow()
        {
            InitializeComponent();
            var vm = new MainVM(this);
            this.DataContext = vm;
        }
    }

    public class MainVM : INotifyPropertyChanged
    {
        public event PropertyChangedEventHandler? PropertyChanged;
        private void OnPropertyChanged(string propName)
        {
            var handler = PropertyChanged;
            if (handler != null)
            {
                handler?.Invoke(this, new PropertyChangedEventArgs(propName));
            }
        }

        public Window win { get; set; }
        public MainVM(Window winValue)
        {
            win = winValue;
            InitImgSource();
        }

        private void InitImgSource()
        {
            FirstImgSource = GetImgSourceViaUrl(@"../../../Images/1.jpg");
            SecondImgSource= GetImgSourceViaUrl(@"../../../Images/2.jpg");
            ThirdImgSource=GetImgSourceViaUrl(@"../../../Images/3.jpg");
            ForthImgSource = GetImgSourceViaUrl(@"../../../Images/4.jpg");
        }

        private ImageSource GetImgSourceViaUrl(string imgUrl = @"../../../Images/1.jpg")
        {
            if (!File.Exists(imgUrl))
            {
                return null;
            }
            BitmapImage bmi = new BitmapImage();
            bmi.BeginInit();
            bmi.UriSource = new Uri(imgUrl, UriKind.RelativeOrAbsolute);
            bmi.EndInit();
            if (bmi.CanFreeze)
            {
                bmi.Freeze();
            }
            return bmi;
        }

        private void ToggleBorderTransform(string ucRotateCircleName)
        {
            var rotateCircle = win.FindName(ucRotateCircleName) as UCRotateCircle;
            if (rotateCircle != null)
            {
                var borderTransform = rotateCircle.FindName("borderRotateTransform") as RotateTransform;
                if (borderTransform != null)
                {
                    borderTransform.Angle = borderTransform.Angle == 45 ? 135 : 45;
                }
            }
        }

        #region First Rotate Circle

        private ImageSource firstImgSource;
        public ImageSource FirstImgSource
        {
            get
            {
                return firstImgSource;
            }
            set
            {
                if(value!=firstImgSource)
                {
                    firstImgSource = value;
                    OnPropertyChanged(nameof(FirstImgSource));
                }
            }
        }

        private double firstBorderAnge = 45.0d;
        public double FirstBorderAnge
        {
            get
            {
                return firstBorderAnge;
            }
            set
            {
                if (value != firstBorderAnge)
                {
                    firstBorderAnge = value;
                    OnPropertyChanged(nameof(FirstBorderAnge));
                }
            }
        }

        private ICommand firstLeftClickCommand;
        public ICommand FirstLeftClickCommand
        {
            get
            {
                if (firstLeftClickCommand == null)
                {
                    firstLeftClickCommand = new DelCommand(FirstLeftClickCommandExecuted, FirstLeftClickCommandCanExecute);
                }
                return firstLeftClickCommand;
            }
        }

        private bool FirstLeftClickCommandCanExecute(object? obj)
        {
            return true;
        }

        private void FirstLeftClickCommandExecuted(object? obj)
        {
            ToggleBorderTransform("firstRotateCircle");
        }



        private ICommand firstRightClickCommand;
        public ICommand FirstRightClickCommand
        {
            get
            {
                if (firstRightClickCommand == null)
                {
                    firstRightClickCommand = new DelCommand(FirstRightClickCommandExecuted,
                        FirstRightClickCommandCanExecute);
                }
                return firstRightClickCommand;
            }
        }

        private bool FirstRightClickCommandCanExecute(object? obj)
        {
            return true;
        }

        private void FirstRightClickCommandExecuted(object? obj)
        {
            ToggleBorderTransform("firstRotateCircle");
        }
        #endregion

        #region Second Rotate Circle

        private ImageSource seoncdImgSource;
        public ImageSource SecondImgSource
        {
            get
            {
                return seoncdImgSource;
            }
            set
            {
                if (value != seoncdImgSource)
                {
                    seoncdImgSource = value;
                    OnPropertyChanged(nameof(SecondImgSource));
                }
            }
        }

        private double secondBorderAnge = 45.0d;
        public double SecondBorderAnge
        {
            get
            {
                return secondBorderAnge;
            }
            set
            {
                if (value != secondBorderAnge)
                {
                    secondBorderAnge = value;
                    OnPropertyChanged(nameof(SecondBorderAnge));
                }
            }
        }

        private ICommand secondToggleBorderAngleCommand;
        public ICommand SecondToggleBorderAngleCommand
        {
            get
            {
                if (secondToggleBorderAngleCommand == null)
                {
                    secondToggleBorderAngleCommand = new DelCommand(SecondToggleBorderAngleCommandExecuted,
                        SecondToggleBorderAngleCommandCanExecute);
                }
                return secondToggleBorderAngleCommand;
            }
        }

        private bool SecondToggleBorderAngleCommandCanExecute(object? obj)
        {
            return true;
        }

        private void SecondToggleBorderAngleCommandExecuted(object? obj)
        {
            ToggleBorderTransform("secondRotateCircle");
        }
        #endregion

        #region Third Rotate Circle
        private ImageSource thirdImgSource;
        public ImageSource ThirdImgSource
        {
            get
            {
                return thirdImgSource;
            }
            set
            {
                if (value != thirdImgSource)
                {
                    thirdImgSource = value;
                    OnPropertyChanged(nameof(ThirdImgSource));
                }
            }
        }

        private double thirdBorderAnge = 45.0d;
        public double ThirdBorderAnge
        {
            get
            {
                return thirdBorderAnge;
            }
            set
            {
                if (value != thirdBorderAnge)
                {
                    thirdBorderAnge = value;
                    OnPropertyChanged(nameof(ThirdBorderAnge));
                }
            }
        }

        private ICommand thirdToggleBorderAngleCommand;
        public ICommand ThirdToggleBorderAngleCommand
        {
            get
            {
                if(thirdToggleBorderAngleCommand == null)
                {
                    thirdToggleBorderAngleCommand = new DelCommand(ThirdToggleBorderAngleCommandExecuted,
                        ThirdToggleBorderAngleCommandCanExecute);
                }
                return thirdToggleBorderAngleCommand;
            }
        }

        private bool ThirdToggleBorderAngleCommandCanExecute(object? obj)
        {
            return true;
        }

        private void ThirdToggleBorderAngleCommandExecuted(object? obj)
        {
            ToggleBorderTransform("thirdRotateCircle");
        }

        #endregion

        #region Forth Rotate Circle
        private ImageSource forthImgSource;
        public ImageSource ForthImgSource
        {
            get
            {
                return forthImgSource;
            }
            set
            {
                if (value != forthImgSource)
                {
                    forthImgSource = value;
                    OnPropertyChanged(nameof(ForthImgSource));
                }
            }
        }

        private double forthBorderAnge;
        public double ForthBorderAnge
        {
            get
            {
                return forthBorderAnge;
            }
            set
            {
                if(value!= forthBorderAnge)
                {
                    forthBorderAnge = value;
                    OnPropertyChanged(nameof (ForthBorderAnge));
                }
            }
        }

        private ICommand forthToggleBorderAngleCommand;
        public ICommand ForthToggleBorderAngleCommand
        {
            get
            {
                if(forthToggleBorderAngleCommand == null)
                {
                    forthToggleBorderAngleCommand = new DelCommand(ForthToggleBorderAngleCommandExecuted,
                        ForthToggleBorderAngleCommandCanExecute);
                }
                return forthToggleBorderAngleCommand;
            }
        }

        private bool ForthToggleBorderAngleCommandCanExecute(object? obj)
        {
            return true;
        }

        private void ForthToggleBorderAngleCommandExecuted(object? obj)
        {
            ToggleBorderTransform("forthRotateCircle");
        }


        #endregion
    }
}
复制代码

































posted @   FredGrit  阅读(2)  评论(0)  编辑  收藏  举报
相关博文：
·  WPF define Command in usercontrol and used in mvvm, Rotated circle as usercontrol and used in multiple times
·  WPF Rotated Ellipse as usercontrol and reuse in window
·  WPF学习 - 用鼠标移动、缩放、旋转图片（1）
·  WPF学习 - 用鼠标移动、缩放、旋转图片（1）
·  WPF学习 - 用鼠标移动、缩放、旋转图片（2）- 使用MatrixTransform
阅读排行：
· 分享一个免费、快速、无限量使用的满血 DeepSeek R1 模型，支持深度思考和联网搜索！
· 基于 Docker 搭建 FRP 内网穿透开源项目（很简单哒）
· ollama系列01：轻松3步本地部署deepseek，普通电脑可用
· 25岁的心里话
· 按钮权限的设计及实现
历史上的今天：
2021-03-02 C# 8 using declarations
点击右上角即可分享
微信分享提示
