WPF Gauge Value changed via System.Timers.Timer

//cs
using System;
using System.Windows;
using System.Windows.Controls.Primitives;
using System.Windows.Media;

namespace WPFDevelopers.Controls
{
    public class Gauge : RangeBase
    {
        public string Title
        {
            get { return (string)GetValue(TitleProperty); }
            set { SetValue(TitleProperty, value); }
        }

        public static readonly DependencyProperty TitleProperty =
            DependencyProperty.Register("TitleProperty", typeof(string), typeof(Gauge), new PropertyMetadata("WD"));

        public static readonly DependencyProperty ValueFormatProperty =
       DependencyProperty.Register("ValueFormat", typeof(string), typeof(Gauge),
           new PropertyMetadata("{0:0}%", OnValueFormatChanged));

        private static void OnValueFormatChanged(DependencyObject d, DependencyPropertyChangedEventArgs e)
        {
            var gauge = d as Gauge;
            gauge?.InvalidateVisual();
        }

        public string ValueFormat
        {
            get { return (string)GetValue(ValueFormatProperty); }
            set { SetValue(ValueFormatProperty, value); }
        }
        public double Thickness
        {
            get { return (double)GetValue(ThicknessProperty); }
            set { SetValue(ThicknessProperty, value); }
        }

        public static readonly DependencyProperty ThicknessProperty =
            DependencyProperty.Register("Thickness", typeof(double), typeof(Gauge), new PropertyMetadata(10.0, OnValueFormatChanged));


        static Gauge()
        {
            DefaultStyleKeyProperty.OverrideMetadata(typeof(Gauge), new FrameworkPropertyMetadata(typeof(Gauge)));
        }

        public Gauge()
        {
            SetValue(ValueProperty, 0.0);
            SetValue(MinimumProperty, 0.0);
            SetValue(MaximumProperty, 100.0);
        }

        protected override void OnValueChanged(double oldValue, double newValue)
        {
            InvalidateVisual();
        }

        protected override void OnMinimumChanged(double oldValue, double newValue)
        {
            InvalidateVisual();
        }

        protected override void OnMaximumChanged(double oldValue, double newValue)
        {
            InvalidateVisual();
        }
        protected override void OnRender(DrawingContext drawingContext)
        {
            base.OnRender(drawingContext);
            if (Background == null)
                Background = new SolidColorBrush((Color)ColorConverter.ConvertFromString("#293950"));
            var width = ActualWidth;
            var height = ActualHeight;
            var radius = Math.Min(width, height) / 2;
            drawingContext.DrawEllipse(Background, new Pen(Background, Thickness), new Point(width / 2, height / 2), radius, radius);
            var normalizedValue = (Value - Minimum) / (Maximum - Minimum);
            var mappedAngle = -220 + normalizedValue * 260;
            var angleInRadians = mappedAngle * Math.PI / 180;
            var pointerLength = radius * 0.7;
            var pointerX = width / 2 + pointerLength * Math.Cos(angleInRadians);
            var pointerY = height / 2 + pointerLength * Math.Sin(angleInRadians);
            drawingContext.DrawLine(new Pen(Brushes.Red, 2), new Point(width / 2, height / 2), new Point(pointerX, pointerY));
            drawingContext.DrawEllipse(Brushes.White, new Pen(Brushes.Red, 2), new Point(width / 2, height / 2), width / 20, width / 20);
            var pathGeometry = new PathGeometry();
            var startAngle = -220;
            angleInRadians = startAngle * Math.PI / 180;
            var startX = width / 2 + radius * Math.Cos(angleInRadians);
            var startY = height / 2 + radius * Math.Sin(angleInRadians);

            var pathFigure = new PathFigure()
            {
                StartPoint = new Point(startX, startY),
            };

            var endAngle = 40;
            angleInRadians = endAngle * Math.PI / 180;
            var endX = width / 2 + radius * Math.Cos(angleInRadians);
            var endY = height / 2 + radius * Math.Sin(angleInRadians);

            var isLargeArc = (endAngle - startAngle > 180);
            var arcSegment = new ArcSegment()
            {
                Point = new Point(endX, endY),
                Size = new Size(radius, radius),
                RotationAngle = 0,
                SweepDirection = SweepDirection.Clockwise,
                IsLargeArc = isLargeArc,
            };

            pathFigure.Segments.Add(arcSegment);
            pathGeometry.Figures.Add(pathFigure);
            if (BorderBrush == null)
            {
                var gradientBrush = new LinearGradientBrush
                {
                    StartPoint = new Point(0, 0),
                    EndPoint = new Point(1, 0)
                };
                gradientBrush.GradientStops.Add(new GradientStop((Color)ColorConverter.ConvertFromString("#37D2C2"), 0.0));
                gradientBrush.GradientStops.Add(new GradientStop((Color)ColorConverter.ConvertFromString("#5AD2B2"), 0.01));
                gradientBrush.GradientStops.Add(new GradientStop((Color)ColorConverter.ConvertFromString("#B77D29"), 0.49));
                gradientBrush.GradientStops.Add(new GradientStop(Colors.Red, 1.0));
                gradientBrush.Freeze();
                BorderBrush = gradientBrush;
            }
            drawingContext.DrawGeometry(null, new Pen(BorderBrush, Thickness), pathGeometry);
            var tickLength = radius * 0.1;
            var step = (Maximum - Minimum) / 10;
            for (int i = 0; i <= 10; i++)
            {
                var angle = startAngle + (i * (endAngle - startAngle) / 10);
                var tickStartX = width / 2 + (radius - tickLength) * Math.Cos(angle * Math.PI / 180);
                var tickStartY = height / 2 + (radius - tickLength) * Math.Sin(angle * Math.PI / 180);
                var tickEndX = width / 2 + (radius + Thickness / 2) * Math.Cos(angle * Math.PI / 180);
                var tickEndY = height / 2 + (radius + Thickness / 2) * Math.Sin(angle * Math.PI / 180);
                drawingContext.DrawLine(new Pen(Brushes.White, 2), new Point(tickStartX, tickStartY), new Point(tickEndX, tickEndY));

                var labelValue = Minimum + step * i;
                var formattedText = DrawingContextHelper.GetFormattedText(labelValue.ToString(),Brushes.White, FlowDirection.LeftToRight,FontSize);

                var labelRadius = radius - tickLength * 2;
                var labelX = width / 2 + labelRadius * Math.Cos(angle * Math.PI / 180) - formattedText.Width / 2;
                var labelY = height / 2 + labelRadius * Math.Sin(angle * Math.PI / 180) - formattedText.Height / 2;
                drawingContext.DrawText(formattedText, new Point(labelX, labelY));
            }
            var formattedValue = "{0:0}%";
            try
            {
                formattedValue = string.Format(ValueFormat, Value);
            }
            catch (FormatException ex)
            {
                throw new InvalidOperationException("Formatting failed ", ex);
            }
            var currentValueText = DrawingContextHelper.GetFormattedText(formattedValue, Brushes.White, FlowDirection.LeftToRight, FontSize * 2);
            var valueX = width / 2 - currentValueText.Width / 2;
            var valueY = height / 2 + radius * 0.4;
            drawingContext.DrawText(currentValueText, new Point(valueX, valueY));
            var titleValue = DrawingContextHelper.GetFormattedText(Title, Brushes.White, FlowDirection.LeftToRight, FontSize);
            valueX = width / 2 - titleValue.Width / 2;
            valueY = height / 2 + radius * 0.8;
            drawingContext.DrawText(titleValue, new Point(valueX, valueY));
        }

    }
}




//xaml

<Window x:Class="WpfApp141.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
        xmlns:local="clr-namespace:WpfApp141"
        WindowState="Maximized"
        mc:Ignorable="d"
        Title="MainWindow" Height="450" Width="800">
    <Grid>
        <local:Gauge
            x:Name="gauge1"
            Width="800"
            Height="800"
            Minimum="0"
            Maximum="100"
            Background="Cyan"
            BorderBrush="Blue"
            BorderThickness="5"
            FontSize="20"
            ValueFormat="{}{0:0}"
            Value="{Binding GaugeValue,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}"/>
    </Grid>
</Window>



//xaml.cs
using System;
using System.Collections.Generic;
using System.ComponentModel;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;

namespace WpfApp141
{
    /// <summary>
    /// Interaction logic for MainWindow.xaml
    /// </summary>
    public partial class MainWindow : Window, INotifyPropertyChanged
    {
        Random rnd { get; set; }

        public MainWindow()
        {
            InitializeComponent();
            this.DataContext = this;
            rnd = new Random();
            System.Timers.Timer tmr = new System.Timers.Timer();
            tmr.Elapsed += Tmr_Elapsed;
            tmr.Interval = 1000;
            tmr.Start();
        }

        private void Tmr_Elapsed(object sender, System.Timers.ElapsedEventArgs e)
        {
            GaugeValue = rnd.NextDouble() * 100;
        }

        public event PropertyChangedEventHandler PropertyChanged;
        private void OnPropertyChanged(string propertyName)
        {
            var handler = PropertyChanged;
            if (handler != null)
            {
                handler?.Invoke(this, new PropertyChangedEventArgs(propertyName));
            }
        }

        private double gaugeValue;
        public double GaugeValue
        {
            get
            {
                return gaugeValue;
            }
            set
            {
                if(value!=gaugeValue)
                {
                    gaugeValue = value;
                    OnPropertyChanged(nameof(GaugeValue));
                }
            }
        }
    }
}
