WPF ListBox ItemTemplate DataTemplate

复制代码
<Window x:Class="WpfApp137.MainWindow"
        xmlns="http://schemas.microsoft.com/winfx/2006/xaml/presentation"
        xmlns:x="http://schemas.microsoft.com/winfx/2006/xaml"
        xmlns:d="http://schemas.microsoft.com/expression/blend/2008"
        xmlns:mc="http://schemas.openxmlformats.org/markup-compatibility/2006"
        xmlns:local="clr-namespace:WpfApp137"
        WindowState="Maximized"
        mc:Ignorable="d"
        Title="MainWindow" Height="450" Width="800">
    <Window.Resources>
        <Style TargetType="{x:Type TextBlock}" x:Key="tbkStyle">
            <Setter Property="FontSize" Value="30"/>
            <Setter Property="HorizontalAlignment" Value="Stretch"/>
            <Setter Property="VerticalAlignment" Value="Center"/>
            <Style.Triggers>
                <Trigger Property="IsMouseOver" Value="True">
                    <Setter Property="FontSize" Value="50"/>
                </Trigger>
            </Style.Triggers>
        </Style>
    </Window.Resources>
    <Grid>
        <ListBox x:Name="lbx"
                 ItemsSource="{Binding BooksCollection,Mode=TwoWay,UpdateSourceTrigger=PropertyChanged}">
            <ListBox.ItemTemplate>
                <DataTemplate>
                    <Grid Height="200">
                        <Grid.RowDefinitions>
                            <RowDefinition/>
                            <RowDefinition/>
                        </Grid.RowDefinitions>
                        <Grid.ColumnDefinitions>
                            <ColumnDefinition/>
                            <ColumnDefinition/>
                        </Grid.ColumnDefinitions>
                        <TextBlock Text="{Binding Id}" Grid.Row="0" Grid.Column="0" Style="{StaticResource tbkStyle}" />
                        <TextBlock Text="{Binding Name}" Grid.Row="0" Grid.Column="1" Style="{StaticResource tbkStyle}"/>
                        <TextBlock Text="{Binding ISBN}" Grid.Row="1" Grid.Column="0" Grid.ColumnSpan="2" Style="{StaticResource tbkStyle}"/>
                    </Grid>
                </DataTemplate>
            </ListBox.ItemTemplate>
        </ListBox>
    </Grid>
</Window>



//cs
using System;
using System.Collections.Generic;
using System.Linq;
using System.Text;
using System.Threading.Tasks;
using System.Windows;
using System.Windows.Controls;
using System.Windows.Data;
using System.Windows.Documents;
using System.Windows.Input;
using System.Windows.Media;
using System.Windows.Media.Imaging;
using System.Windows.Navigation;
using System.Windows.Shapes;

namespace WpfApp137
{
    /// <summary>
    /// Interaction logic for MainWindow.xaml
    /// </summary>
    public partial class MainWindow : Window
    {
        public MainWindow()
        {
            InitializeComponent();
            this.Loaded += MainWindow_Loaded;
        }

        private void MainWindow_Loaded(object sender, RoutedEventArgs e)
        {
            System.Timers.Timer tmr = new System.Timers.Timer();
            tmr.Elapsed += Tmr_Elapsed;
            tmr.Interval = 1000;
            tmr.Start();
        }

        int idx = 0;
        private void Tmr_Elapsed(object sender, System.Timers.ElapsedEventArgs e)
        {
            Application.Current.Dispatcher.BeginInvoke(new Action(() =>
            {
                Book bk = new Book();
                bk.Id = ++idx;
                bk.ISBN = $"{idx}_{Guid.NewGuid().ToString("N")}";
                bk.Name = $"{idx}_Name";
                lbx.Items.Add(bk);
            }));
        }
    }

    public class Book
    {
        public int Id { get; set; }
        public string Name { get; set; }
        public string ISBN { get; set; }
    }
    }
复制代码
